Syscom Video XD1000B Instruction Manual page 15

SYSTEM
The IMAGE menu provides the ability to adjust the CAM TITLE, RS485, MONITOR, CVBS CROP,
VIDEO OUT, LANGUAGE and, VERSION functions of the camera.
1) CAM TITLE
2) MONITOR
LCD
GAMMA
ADAPT. LEVEL
BLUE GAIN
RED GAIN
CRT
BLACK LEVEL
BLUE GAIN
RED GAIN
3) CVBS CROP
4) VIDEO OUT
5) LANGUAGE
6) VERSION
< SYSTEM >
MAIN MANU
LENS DC
EXPOSURE
BACK LIGHT OFF
WHITE BAL ATW
DAY&NIGHT AUTO
FUNCTION
SYSTEM
RESET
EXIT
< CAM TITLE >
SYSTEM
CAM TITLE
MONITOR
CVBS CROP
VIDEO OUT
LANGUAGE
VERSION
RETURN
Maximum of 15 characters are allowed.
Select the Monitor type ▶ LCD, CRT
Select the Gamma level ▶ AUTO, USER. USER+Y, 0.45 -1.0
Adjust the Adaptive level ▶ 0 - 100
Adjust the Blue gain level ▶ 0 - 100
Adjust the Red gain level ▶ 0 - 100
Select the Gamma level ▶ AUTO, USER. USER+Y, 0.45 -1.0
Adjust the Blue gain level ▶ -50 ~ +50
Adjust the Red gain level ▶ -50 ~ +50
▶ ON, OFF
Select the video out type ▶ NTSC, PAL
OSD menu LANGUAGE (16ea) ▶ ENGLISH etc.
Firmware VERSION
