1) DNR
2D
3D
SMART NR
LEVEL
2) MOTION
SELECT
DISPLAY
SENSITIVITY
MOTION VIEW
DEFAULT
3) PRIVACY
SELECT
DISPLAY
COLOR
TRANS
DEFAULT
4) DEFECT DET
LIVE DPC
STATIC DPC
START
LEVEL
SENS-UP
AGC
< FUNCTION >
MAIN MANU
LENS DC
EXPOSURE
BACK LIGHT OFF
WHITE BAL ATW
DAY&NIGHT AUTO
FUNCTION
SYSTEM
RESET
EXIT
Select Digital Noise Reduction.
▶ ON, OFF
▶ ON, OFF
▶ ON, OFF (Sensitivity 0 - 100)
Adjust the 3DNR level ▶ 0 - 100
Detects the Motioned Object in the image. ▶ ON, OFF
Select the Motion area ▶ AREA1 - AREA4
Adjust the Motion area window position & size
Adjust the Motion sensitivity level ▶ 0 - 60
Select the Motion view ▶ ON, OFF
Initialize the setting values
Hide an area you want to hide on the screen.
Select the privacy zone ▶ AREA1 - AREA8
Adjust the Privacy window type, position & size
▶ OFF, INV., MOSAIC, COLOR
Select the privacy zone color ▶ 0 - 15
Select the privacy zone transparency ▶ 0 - 3
Initialize the setting values
Compensates for bad pixels.
Select the Live DPC mode ▶OFF, ON, AUTO
▶ ON, OFF
Start the bad pixels correction
Select the Static DPC level ▶ 0 - 60
Select the Sens-up level ▶ x2 - x30
Select the AGC level ▶ 0 - 8
FUNCTION
DNR
MOTION
PRIVACY
DEFECT DET
RETURN
OFF
OFF
16
