Tsun TSOL-MP3000 Quick Installation Manual

TITAN MICROINVERTER
QUICK INSTALLATION GUIDE
Check the Installation Environment and Position
When choosing the position of installation, comply with the following
conditions:
· To avoid unwanted power derating due to an increase in the
sunlight.
may be present.
correct operation of electronic equipment.
· It's recommended to install microinverter on structures
underneath the photovoltaic modules so that they work in the
shade without touching the rooftop.
· Use a mobile phone to check the Wi-Fi signal strength at the
microinverter installation position. If the Wi-Fi signal is weak,
try to install the micro inverter in another place with better signal,
or move the Wi-Fi router or repeater closer.
Installation Steps
DANGER
clearances.
incorrect installation and operation may lead to serious safety and
shock hazards or equipment damage.
·Be aware that installation of this equipment includes risk of electric
shock.
DANGER
Do not install the equipment in adverse environment conditions such
and humid.
WARNING
with good ventilation and no directly sunshine.
CAUTION
There are no screws and nuts in the package.
Choose the best installation position. Use two pairs of screws and
nuts to fix the microinverter on the frame. Make sure that the label
of microinverter should be upside.
The micro inverter can also be mounted on the wall (vertically)
using the optional support. In this case, first fix the bracket to the
wall with a pair of screws and then fix the micro inverter to the
bracket with one pair of nut screws.
Step 2. Connect the ground cable
WARNING
·Ensure that all
·Use φ6 screw for .
Step 3. Connect the AC cable
DANGER
from the system.
disconnected from the home distribution network and the AC breaker
is open.
WARNING
·Ensure that all AC cables are correctly wired and that none of the
wires are pinched or damaged.
·Use AWG 12 ( 4 mm²) cable for AC end cable.
CAUTION
·The installation technician is responsible for selecting a kind of AC
distribution network correctly.
Take out the AC connector from the package. Get the AC cable
through the shell of AC connecter and connect the cable to the
L: Live
N: Neutral
PE: Ground
(Brown/Red)
(Blue/Black)
(Yellow-Green)
11061400301 V1.2
