BOLTS/NUTS
Definition of the fasteners on following pages.
ADDITIONAL SYMBOLS
The following symbols are used in addition to
those shown above to describe part design.
Low Tensilock Lock
When this symbol appears
during assembly, parts must
be lubricated before installa-
tion. Lubricate affected parts
with universal grease.
This symbol describes the
sawing direction and reappears
during assembly.
Shoulder bolt
Cross screw
Slotted screw
Set screw
Hex nut
Flange nut
Flat washer
Counter- Dome
sunk
DIMENSIONS/LENGTH
The dimensions of the fasteners are printed as a
diameter dimension (M) ISO 68-1. This is followed by
a length dimensions for bolts/screws; the dimension
of a bolt/screw is the part of the bolt/screw that
disappears into the material in which it is mounted.
(Diameter)
M8 x
This symbol describes the
recommended lifting point for
heavy lifts.
Make the joint finger-tight.
B751 PRO
Allen screw
Allen screw
(partially threaded)
Hex bolt
Hex bolt
(partially threaded)
Flange screw
Flange screw
(partially threaded)
Carriage bolt
(Length)
20
