Part Number: 70-105
71-213-xx & 71-223-xx
Mobile Day by the Hour Display Kits

Required Tools:

• 4 mm hex wrench
• 5 mm hex wrench
• 6 mm hex wrench (ball end)
• Phillips screwdriver
• Flat head screwdriver
• Rubber mallet

Recommendations:

Time to assemble: 1-2 hours
Assembly area: 10' x 10' or larger open floor space.
To prevent scratching, use cardboard or other protective
underlayment.
Contact Information:
Parker Hannifin Corporation
Electromechanical Automation Division
email ipsorders@parker.com
www.parker.com/ips
Two Locations to Serve You:
135 Quadral Drive
Wadsworth, OH 44281
Phone 800.333.4932
Fax 330.334.2350
5500 Business Park Drive
Rohnert Park, CA 94928
Phone 800.358.9070
Fax 707.584.8029
MULTIBLOCK
ORIENTATION
PANEL SHOULD BE INSTALLED
IN "FLUSH MOUNT" ORIENTATION
71-213-xx with
Andon Post Option

Display Board

Size (ft)
H x W
Display Board Material
Clear Poly Board
3 x 3
Black Trespa Board
No Board
Clear Poly Board
3 x 3
Black Trespa Board
No Board
24-225-6
FHCS
24-225-6
FHCS
71-223-xx
Kit
Part Number
71-213-WK
71-213-PK
71-213-NK
71-223-WK
71-223-PK
71-223-NK
22-100
MULTIBLOCK
22-100
MULTIBLOCK
