Wavetronix SmartSensor Matrix User Manual page 72

Delay Ignores outputs that are
shorter than the specified
delay time.
Extend Continues a channel
output until the time
specified runs out.
DI Allows you to map inputs
to the intersection phase
(Detector in the controller. The
Input) default is "00," which
means the detector input
is unassigned.
Φ Allows you to enter the
phase the sensor is
(Phase) monitoring. The default
is "00," which means the
phase is unassigned.
Invert Allows the channel output
to be inverted.
Min Speed Lets you set a minimum
speed for the channel.
Max Speed Lets you set a maximum
speed for the channel.
Click anywhere in the
white box and use the up/
down arrows to change
the delay setting in the
Output Settings window.
Click anywhere in the
white box and use the up/
down arrows to change
the extend setting in the
Output Settings window.
Purely for reference—
does not affect sensor or
controller performance.
Purely for reference—
does not affect sensor or
controller performance.
When checked, the
channel output will remain
on until a vehicle is
detected.
Select a minimum speed
from the drop-down list.
Select a maximum speed
from the drop-down list.
Chapter 7: Configuring Zones & Channels
71
•
