Lopi 864 Instruction Manual

Lopi 864 Instruction Manual

Coolsmart tv
Hide thumbs Also See for 864:
Table of Contents

Advertisement

Quick Links

Download this manual
Compatibility
864 Fireplaces (2018 or later) with EmberBed Feature
•
ProBuilder 42 Linear Fireplace
•
NOTE: A power heat duct kit may also be available for this appliance. If so, you may use either the power
heat vent kit(s) or the CoolSmart TV kit, but not both. See appliance installation manual for details.

Table of Contents

Compatibility .............................................................................................................................................................. 1
Packing List ............................................................................................................................................................... 1
864 - Details .............................................................................................................................................................. 2
864 - Installation Overview ..................................................................................................................................... 2
864 - Installation Requirements ............................................................................................................................. 3
864 - Framing the Chase ....................................................................................................................................... 4
864 - Fireplace Preparation ................................................................................................................................... 5
864 - Mantel Clearances ....................................................................................................................................... 7
PB 42 Linear - Details ............................................................................................................................................... 8
PB 42 Linear - Overview ........................................................................................................................................ 8
PB 42 Linear - Installation Requirements .............................................................................................................. 9
PB 42 Linear - Combustible "Over-Facing" (Optional) ......................................................................................... 10
PB 42 Linear - Framing the Chase ...................................................................................................................... 11
PB 42 Linear - Fireplace Preparation .................................................................................................................. 12
PB 42 Linear - Mantel Clearances ...................................................................................................................... 14
4415 HO Linear - Details ........................................................................................................................................ 21
4415 HO Linear - Installation Overview ............................................................................................................... 21
4415 HO - Installation Requirements ................................................................................................................... 22
4415 HO - Combustible "Over-Facing" (Optional) ............................................................................................... 23
4415 HO - Flush Facing Header Configuration and Facing ................................................................................ 24
4415 HO - Framing the Chase ............................................................................................................................. 25
4415 HO - Fireplace Preparation ......................................................................................................................... 26
4415 HO - Mantel Clearances ............................................................................................................................. 30
CoolSmart TV Installation (864, PB 42 Linear, 4415HO) ........................................................................................ 31
Using oval pipe to get past an obstruction ........................................................................................................... 35
Custom Valance to Disguise Outlet - (Optional) ................................................................................................. 36
Packing List
• Convection Manifold (with grill and mounting brackets pre-attached)
• (4) 5" Diameter Aluminum Flex Ducts
• (4) Starter Collars
• (36) Self-Drilling Tek Screws
• (2) Extended Support Brackets
Page 1 of 30
CoolSmart TV
864, PB 42 Linear, 4415 HO
Sku# 98900779
4415 HO (sn# 3212-011710 or later)
•
17602029-10/25/2021


























© Travis Industries, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 864 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lopi 864

Summary of Contents for Lopi 864

  • Page 1: Table Of Contents

    4415 HO - Fireplace Preparation ......................... 26   4415 HO – Mantel Clearances ..........................30   CoolSmart TV Installation (864, PB 42 Linear, 4415HO) ..................31   Using oval pipe to get past an obstruction ......................35   Custom Valance to Disguise Outlet – (Optional) ....................36  ...

  • Page 2: 864 - Details

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 864 – Details 864 - Installation Overview The CoolSmart system is designed to redirect the convective heat of the fireplaces from the front of the unit, just above the glass, to a location higher on the wall. The use of this kit allows for reduced clearances to televisions and a recessed cavity above the fireplace.

  • Page 3: 864 - Installation Requirements

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 864 - Installation Requirements Grill and Manifold Dimensions The grill may be installed over the facing to provide an aesthetic opening for the convection outlet. (2) 8-32 x 1-1/2” screws attach the trim to the upper manifold.

  • Page 4: 864 - Framing The Chase

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 864 - Framing the Chase 24-1/4" 616mm Braces for Manifold Support Brackets 3-3/4" Bottom of Upper 96mm Manifold Framing 8-1/2" Max. 120" 216mm 3048mm Min. 77" 1956mm 864 (31K,40K) 864 CleanFace (31K,40K) 43-1/2”...

  • Page 5: 864 - Fireplace Preparation

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 864 - Fireplace Preparation 1. Remove the right cover plate (with the single knockout ) from the top of the fireplace and discard it. Remove and discard 2. Remove the (4) screws that secure the two circular cover plates on the next layer of the fireplace.
  • Page 6 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4. Remove the left, top layer, cover plate. Turn it over and then reinstall it in place of the right cover plate removed in step 1. Replace all screws so there are no holes left in the top of the fireplace.

  • Page 7: 864 - Mantel Clearances

    8. Install the fireplace into the framed chase. See section “Installation” in the manual. 864 – Mantel Clearances 864 alternative mantel clearances are yet to be determined. Abide by the mantel clearances in the appliance manual. Page 7 of 30 17602029-10/25/2021 ©...

  • Page 8: Pb 42 Linear - Details

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear – Details PB 42 Linear - Overview The CoolSmart system is designed to redirect the convective heat of the fireplaces from the front of the unit, just above the glass, to a location higher on the wall.

  • Page 9: Pb 42 Linear - Installation Requirements

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear - Installation Requirements Grill and Manifold Dimensions The grill may be installed over the facing to provide an aesthetic opening for the convection outlet. (2) 8-32 x 1-1/2” screws attach the trim to the upper manifold.

  • Page 10: Pb 42 Linear - Combustible "Over-Facing" (Optional)

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear - Combustible “Over-Facing” (Optional) WARNING When using the CoolSmart TV kit, Combustible material can be installed over the non-combustible board on the front of the fireplace. To be clear, there will be (2) layers of board over the front of the appliance, one non- combustible that covers the entire front of the fireplace, and a second layer that can be combustible material that is placed on top of the non-combustible board.

  • Page 11: Pb 42 Linear - Framing The Chase

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear - Framing the Chase PB42 Linear 24-1/4"(616mm) Braces for Manifold 3-3/4" Support Brackets 96mm Bottom of Upper Manifold Framing Max. 120" 3048mm 8-1/2" Min. 66-1/2" 216mm 1690mm 34-1/2"...

  • Page 12: Pb 42 Linear - Fireplace Preparation

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear - Fireplace Preparation 1. Use snips or diagonal cutters to snip the tab on the knockouts. Press on the far side away from the tap to pop the edge of the knockout up.
  • Page 13 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4. Insert a starter collar into each of the holes that were uncovered in the previous step and bend the tabs to secure the starter collar to the fireplace.. Seal the joints with silicone caulk or aluminum (U.L. 181A-P)

  • Page 14: Pb 42 Linear - Mantel Clearances

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 PB 42 Linear – Mantel Clearances When using this kit, disregard the combustible mantel requirements in the manual and follow the requirements shown to the right. If you wish to place a TV above the mantel, it must meet the following requirements: ...

  • Page 15: 4415 Ho Linear - Details

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO Linear – Details 4415 HO Linear - Installation Overview The CoolSmart system is designed to redirect the convective heat of the fireplaces from the front of the unit, just above the glass, to a location higher on the wall.

  • Page 16: 4415 Ho - Installation Requirements

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO - Installation Requirements Grill and Manifold Dimensions The grill may be installed over the facing to provide an aesthetic opening for the convection outlet. (2) 8-32 x 1-1/2” screws attach the trim to the upper manifold.

  • Page 17: 4415 Ho - Combustible "Over-Facing" (Optional)

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO - Combustible “Over-Facing” (Optional) WARNING When using the CoolSmart TV kit, Combustible material can be installed over the non-combustible board on the front of the fireplace. To be clear, there will be (2) layers of board over the front of the appliance, one non- combustible that covers the entire front of the fireplace, and a second layer that can be combustible material that is placed on top of the non-combustible board.

  • Page 18: 4415 Ho - Flush Facing Header Configuration And Facing

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO - Flush Facing Header Configuration and Facing For installations were only non-combustible facing will cover the front of the appliance, the metal header can be moved back ½” to accommodate drywall installed flush with the front of the fireplace The drywall can contact the top ½”...

  • Page 19: 4415 Ho - Framing The Chase

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO - Framing the Chase 24-1/4" (616mm) Braces for Manifold Support Brackets 3-3/4" Bottom of Upper (96mm) Manifold Framing Max. 120" (3048mm) 8-1/2" (216mm) Min. 67-1/4” (1709mm) Min. 37-5/8"...

  • Page 20: 4415 Ho - Fireplace Preparation

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO - Fireplace Preparation  When using the CoolSmart TV kit, you may discard the metal framing members included with the fireplace (3615 and 4415 have (3) and 6015 has (4)).
  • Page 21 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 WARNING: In order to extract the heat properly from around the firebox, you will must remove (4) layers of cover plates for each of the (4) flex attachment points on the top of the fireplace. Not removing all of the cover plates can create hazardous conditions.
  • Page 22 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 Third Layer  Under the second layer of knockout plates, you will find cover plates held in place with (2) ¼” screws. Use a nut driver or drill with an extension to remove the (2) screws. Reach in and remove the cover plate. You may discard the plates.
  • Page 23 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 Fourth (final) Layer  Once the third layer is removed, a final cover plate will be visible. Use a ¼” nutdriver to loosen the screw securing the plate. Reach in and rotate the cover plate to uncover the final hole.

  • Page 24: 4415 Ho - Mantel Clearances

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4415 HO – Mantel Clearances When using this kit, disregard the combustible mantel requirements in the manual and follow the requirements shown to the right. If you wish to place a TV above the mantel, it must meet the following requirements: ...

  • Page 25: Coolsmart Tv Installation (864, Pb 42 Linear, 4415Ho)

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 CoolSmart TV Installation 1. Remove the grill from the manifold (2 screws hold it in place). 2. Remove the rear-mounting brackets by loosening 1/4" screws and sliding it out of the keyhole slots.
  • Page 26 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 4. Hold the upper convection manifold with the outlet facing the back of the framing members installed in the previous step. Tilt the outlet of the manifold downward until the outlet of the manifold and the two mounting tabs can fit between to two framing members.
  • Page 27 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 6. Re-attach the two rear mounting brackets (removed in step 6) to the bottom of the convection manifold. Leave the screws loose so the brackets can be positioned to the back of the chase. Secure the brackets to the chase using screws (not included).
  • Page 28 CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 8. Cover the face of the fireplace and the outlet of the manifold to ensure no construction debris or sheetrock dust enters the unit. 9. Once all finish work is complete around the outlet of the manifold, install the outlet grill assembly using the two included screws (one at each end).

  • Page 29: Using Oval Pipe To Get Past An Obstruction

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 Using oval pipe to get past an obstruction 5” Flex to CoolSmart 5” 7-3/4” Manifold If a situation arises that obstructs the 5” round to 6” CoolSmart flex vent runs (such as...

  • Page 30: Custom Valance To Disguise Outlet - (Optional)

    CoolSmart TV 864, PB 42 Linear, 4415 HO Sku# 98900779 Custom Valance to Disguise Outlet – (Optional) A custom valance may be constructed to obscure the view of the manifold outlet. If using a valance it must meet the following requirements.
