Lopi PEWTER 9850034 User Manual

Compatibility:

• 21DV Fireplace

Aromatherapy Option

This face is compatible with the aromatherapy tray (SKU 98500385). If using this option, make the necessary
modifications to the face prior to installing the face (see page 2 of this instruction sheet for details).

Hand-Rubbed Patina Finishes

The optional patina finish is hand applied by a skilled artisan to permanently alter the metal colors and texture
of the face. Each face is individually hand-polished and fired in an oven which imparts unique color subtleties
with no two finishes alike. The patina finish on your face is a "living" color and will age and antique over time.
Enjoy the timeless, rich luster of your beautiful new face.

Installation

! Make sure the fireplace is cool while installing the face.
PLATED SURFACES:
Make sure the plated surfaces are clean before starting
the fireplace. Any marks left on plated surfaces may
become etched in place. Clean plated surfaces with
denatured alcohol and a soft cloth.
Page 1 of 3
21 DV Wilmington Face
Pewter 98500340
17601413 3/30/12
Black 98500341 Carbon Patina 95700101

Packing List:

• Face
b
Lift and rotate the face forward
until the top brackets lock into the
upper slots.
22-1/8"
The bottom of the face is 1-1/4" below the
base of the fireplace when installed.
36-3/4"
a
Tilt the face back
and insert the
bottom brackets
into the lower
slots until they
lock in place.
© Travis Industries, Inc.
