Lopi 21 DV Wilmington Face User Manual

Compatibility:

• 21DV Fireplace

Aromatherapy Option

This face is compatible with the aromatherapy tray (SKU 98500385). If using this option, make the necessary
modifications to the face prior to installing the face (see page 2 of this instruction sheet for details).

Installation

! Make sure the fireplace is cool while installing the face.

PLATED SURFACES:

Make sure the plated surfaces are clean before starting
the fireplace. Any marks left on plated surfaces may
become etched in place. Clean plated surfaces with
denatured alcohol and a soft cloth.
Plated Surfaces
Use denatured alcohol and a soft cloth to clean plated surfaces. Marks
left on the surface may damage the face.
Page 1 of 3
21 DV Wilmington Face
Pewter 98500340

Packing List:

• Face
Lift and rotate the face forward
until the top brackets lock into the
upper slots.
The bottom of the face is 1-1/4" below the
base of the fireplace when installed.
8/19/05
Black 98500341
b
36-3/4"
a
Tilt the face back
and insert the
bottom brackets
into the lower
slots until they
lock in place.
22-1/8"
Soft Cloth
© Travis Industries, Inc.
Denatured
Alcohol
