Zero Clearance Box Installation Manual
Australia Only
Suitable for Lopi Flush Wood Medium &
Lopi Flush Wood Large Hybrid-Fyre™ Inserts
Lopi DVL, DVS GS2 & Radiant Plus Large Gas Inserts
Dragon Wholesaling Pty Ltd
4/16 Lexington Drive,
Bella Vista
NSW 2153 Australia
© Copyright 2019
w w w . l op i . c o m. a u
Dragon Wholesaling Pty Ltd | 2/16 Lexington Drive, Bella Vista NSW 2153 | Phone. (02) 8824 9122 Fax. (02) 8824 6487
Advertisement
Related Manuals for Lopi Zero Clearance Box
Summary of Contents for Lopi Zero Clearance Box
- Page 1 Zero Clearance Box Installation Manual Australia Only Suitable for Lopi Flush Wood Medium & Lopi Flush Wood Large Hybrid-Fyre™ Inserts Lopi DVL, DVS GS2 & Radiant Plus Large Gas Inserts Dragon Wholesaling Pty Ltd 4/16 Lexington Drive, Bella Vista NSW 2153 Australia ©...
-
Page 2: Section View
Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large The Zero clearance box allows all models listed above to be installed into a combustible wall with minimum clearances and without brick or block work using the framing dimensions and clearances included in this manual. - Page 3 Screw inner top panel in place (Lopi DVL Gas Insert Installation Only) For all other fireboxes skip this step If installing the Lopi DVL gas insert into the ZC Box it is necessary to remove the following two perforated sections of the inner top panel (highlighted in blue) to allow for successful installation.
- Page 4 Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Zero Clearance Box Assembly Details Step 5 (Wood Firebox Installation Only) Step 6 Screw 200mm collar in place Screw outer left, outer right and outer rear...
- Page 5 NOTE 3: (Wood Firebox Installation Only) riple skin flue must be installed from zero clearance box as per Australian Standards. A 25mm clearance from the outer 10” casing to any combustible material must be maintained.
- Page 6 Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Knock-Outs for GreenStart™ Ignitor - Wood Inserts Only When using the GreenStart™ Ignitor, the knock-outs on the inner and outer walls of the zero clearance box will need to be removed.
-
Page 7: Flue Assembly
Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Gas Inserts Flue Set-up Using ZC Box When using the ZC Box to install either the gas inserts the following installation methods are to be used: Lopi Radiant Plus Large &... - Page 8 Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Gas Inserts Flue Set-up Using ZC Box When using the ZC Box to install either the gas inserts the following installation methods are...
- Page 9 NOTE: or timber floor. Lopi DVS - MUST Use Large 1 Piece Panel - SKU 96100324 Finishing panels covers frame opening width SEE HEARTH REQUIREMENTS Lopi DVL - Use Standard 1 Piece Panel - SKU 96100323 &...
- Page 10 Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Hearth Requirements for Zero Clearance Box Lopi DVS, DVL & Radiant Plus Large Models Only TIMBER & CONCRETE FLOORS Isometric View 1 Piece Panel...
- Page 11 Zero Clearance Box Flush Wood Medium, Flush Wood Large Hybrid-Fyre™ Lopi DVL, DVS GS2, Radiant Plus Large Minimum Clearances & Hearth Requirements Lopi DVS, DVL & Radiant Plus Large Models Only Section View Plaster Wall 4 x 6-5/8 (168mm) Flue FOR SPECIFIC MANTEL &...
