Compatibility:
•
1250 Wood Stove
•
Answer
Packing List:
•
Pedestal
•
(2) 3/8-16 x 3/4" Bolts w Washers
•
(2) 5/16" x 3" Lag Bolts w Washers
•
Screen with (6) Staples
•
Insulation
•
Cover Plate Assembly
Pedestal Attachment
NOTE: If using outside air, install it prior to attaching the pedestal (see Outside Air Installation on page 2 and 3).
Two pedestal bolts
attach the pedestal to
the bottom of the
stove.
Page 1 of 4
Small Pedestal (1250 / Answer)
99200122
Stove
9/4/08
The lag bolts and washers
may be inserted through
these holes to anchor the
pedestal to the floor.
Pedestal
© Travis Industries, Inc.
Advertisement
Table of Contents
Related Manuals for Lopi 99200122
Summary of Contents for Lopi 99200122
- Page 1 Small Pedestal (1250 / Answer) 99200122 Compatibility: • 1250 Wood Stove • Answer Packing List: • Pedestal • (2) 3/8-16 x 3/4” Bolts w Washers • (2) 5/16” x 3” Lag Bolts w Washers • Screen with (6) Staples •...
- Page 2 Small Pedestal (1250 / Answer) 99200122 Outside Air Installation – Using the Outside Air Kit (99200139) Tuck insulation (included with the pedestal) under both sides of the pedestal and under the holes on the base of the pedestal. This prevents air...
- Page 3 Small Pedestal (1250 / Answer) 99200122 Outside Air Installation – Through the Pedestal into the Crawl Space This pedestal has an internal air duct that may be used to direct air to the firebox. Outside air is then drawn from the crawl space under the stove (check with local building codes for requirements in your area).
- Page 4 Small Pedestal (1250 / Answer) 99200122 Attach the included screen over the hole (staples are included with the pedestal). Place the pedestal in place and tuck insulation under both sides of the pedestal and under the holes in the base of the pedestal (see step “a”...
