User Manual
EE4003011M
Oven

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EE4003011M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AEG EE4003011M

  • Page 1 User Manual EE4003011M Oven...
  • Page 2: Table Of Contents

    12. ENERGY EFFICIENCY..................... 28 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 3 ENGLISH damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety This appliance can be used by children aged from 8 •...
  • Page 4: Safety Instructions

    Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. Do not use a steam cleaner to clean the appliance. • Do not use harsh abrasive cleaners or sharp metal •...
  • Page 5 ENGLISH • Do not let mains cables touch or • Open the appliance door carefully. come near the appliance door, The use of ingredients with alcohol especially when the door is hot. can cause a mixture of alcohol and air. •...
  • Page 6: Product Description

    Contact the Authorised Service • Before replacing the lamp, disconnect Centre. the appliance from the power supply. • Be careful when you remove the door • Only use lamps with the same from the appliance. The door is specifications.
  • Page 7: Before First Use

    ENGLISH 3.2 Accessories For cakes and biscuits. Combi pan Wire shelf For cakes and biscuits. To bake and roast For cookware, cake tins, roasts. or as a pan to collect fat. Baking tray 4. BEFORE FIRST USE WARNING! Refer to "Care and Refer to Safety chapters.
  • Page 8 5.2 Activating and 1. Turn the knob for the oven functions to select an oven function. deactivating the appliance 2. Turn the knob for the temperature to select a temperature. It depends on the model if 3. To deactivate the appliance turn the...
  • Page 9 ENGLISH The lamp may automatically deactivate at a temperature below 60 °C during some oven functions. 5.4 Display A. Function indicators B. Time display C. Function indicator 5.5 Buttons Button Function Description MINUS To set the time. CLOCK To set a clock function. PLUS To set the time.
  • Page 10: Clock Functions

    6. CLOCK FUNCTIONS 6.1 Clock functions table Clock function Application TIME OF DAY To set, change or check the time of day. DURATION To set how long the appliance operates. To set when the appliance deactivates. TIME DELAY To combine DURATION and END function.
  • Page 11: Using The Accessories

    ENGLISH Appliance turns on automatically later The Minute Minder starts automatically on, works for the set DURATION time after 5 seconds. and stops at the set END time. At the set 3. When the set time ends, an acoustic time an acoustic signal sounds. signal sounds.
  • Page 12: Additional Functions

    8. ADDITIONAL FUNCTIONS 8.1 Cooling fan If you deactivate the appliance, the cooling fan can continue to operate until When the appliance operates, the the appliance cools down. cooling fan activates automatically to keep the surfaces of the appliance cool.
  • Page 13 ENGLISH 9.2 Inner side of the door • If you cannot find the settings for a special recipe, look for the one that is In some models, on the inner side of almost the same. the door you can find: •...
  • Page 14 Baking results Possible cause Remedy The cake is not ready in the The oven temperature is too The next time you bake, set baking time given. low. a slightly higher oven tem- perature. 9.5 Baking on one level: Baking in tins...
  • Page 15 ENGLISH Food Function Temperature Time (min) Shelf position (°C) Christmas stol- Top / Bottom 50 - 70 160 - 180 Heat Bread (rye Top / Bottom 1. 20 1. 230 bread): Heat 2. 30 - 60 2. 160 - 180 1.
  • Page 16 Biscuits Food Function Temperature Time (min) Shelf position (°C) Short pastry bis- True Fan Cook- 150 - 160 10 - 20 cuits Short bread / True Fan Cook- 20 - 35 Short bread / Pastry stripes Short bread /...
  • Page 17 ENGLISH Food Function Temperature Time (min) Shelf position (°C) Lasagne Top / Bottom 180 - 200 25 - 40 Heat Vegetables au Turbo Grilling 160 - 170 15 - 30 gratin Baguettes top- True Fan Cook- 160 - 170 15 - 30 ped with melted cheese Sweet bakes...
  • Page 18 Food Temperature Time (min) Shelf position (°C) 2 positions 3 positions Biscuits made 80 - 100 130 - 170 1 / 4 with egg white, meringues Macaroons 100 - 120 40 - 80 1 / 4 Biscuits made 160 - 170...
  • Page 19 ENGLISH Food Temperature (°C) Time (min) Shelf position Piroggen (Russian 15 - 25 180 - 200 version of calzone) 1) Preheat the oven. 2) Use a deep pan. 9.9 Roasting • To prevent the meat juices or fat from burning onto the pan, put some liquid •...
  • Page 20 Food Quantity Function Tempera- Time (min) Shelf posi- (kg) ture (°C) tion Chop / Spare 1 - 1.5 Turbo Grill- 170 - 180 60 - 90 Meatloaf 0.75 - 1 Turbo Grill- 160 - 170 50 - 60 Pork knuckle 0.75 - 1...
  • Page 21 ENGLISH Food Quantity Function Temperature Time (min) Shelf posi- (kg) (°C) tion Half chicken 0.4 - 0.5 each Turbo Grill- 190 - 210 35 - 50 Chicken, 1 - 1.5 Turbo Grill- 190 - 210 50 - 70 poulard Duck 1.5 - 2 Turbo Grill- 180 - 200...
  • Page 22 Fast Grilling Food Time (min) Shelf position 1st side 2nd side Burgers / Burgers 8 - 10 6 - 8 Pork fillet 10 - 12 6 - 10 Sausages 10 - 12 6 - 8 Fillet / Veal steaks...
  • Page 23 ENGLISH Frozen ready meals Food Function Temperature Time (min) Shelf position (°C) Frozen pizza Top / Bottom as per manufac- as per manufac- Heat turer’s instruc- turer’s instruc- tions tions Top / Bottom 200 - 220 as per manufac- French fries Heat or Turbo turer’s instruc- (300 - 600 g)
  • Page 24 • Put no more than six one-litre • When the liquid in the jars starts to preserve jars on the baking tray. simmer (after approximately 35 - 60 • Fill the jars equally and close with a minutes with one-litre jars), stop the clamp.
  • Page 25: Care And Cleaning

    ENGLISH Food Temperature Time (h) Shelf position (°C) 1 position 2 positions Vegetables for 60 - 70 5 - 6 1 / 4 sour Mushrooms 50 - 60 6 - 8 1 / 4 Herbs 40 - 50 2 - 3 1 / 4 Fruit Food...
  • Page 26 10.3 Oven ceiling 2. Fully press the clamping levers (A) on the two door hinges. WARNING! Deactivate the appliance before you remove the heating element. Make sure that the appliance is cold. There is a risk of burns. Remove the shelf supports.
  • Page 27: Troubleshooting

    ENGLISH 10.5 Replacing the lamp Put a cloth on the bottom of the interior of the appliance. It prevents damage to the lamp glass cover and the cavity. WARNING! Danger of electrocution! Disconnect the fuse before 2. Clean the glass cover. you replace the lamp.
  • Page 28: Energy Efficiency

    ......... Serial number (S.N.) ......... 12. ENERGY EFFICIENCY 12.1 Product Fiche and information according to EU 65-66/2014 Supplier's name Model identification EE4003011M Energy Efficiency Index 103.5 Energy efficiency class Energy consumption with a standard load, conven- 0.99 kWh/cycle tional mode Energy consumption with a standard load, fan-forced 0.88 kWh/cycle...
  • Page 29 ENGLISH 12.2 Energy saving temperature to minimum 3 - 10 minutes before the end of the cooking time, The appliance contains depending on the duration of the features which help you save cooking. The residual heat inside the energy during everyday oven will continue to cook.
  • Page 30 www.aeg.com...
  • Page 31 ENGLISH...
  • Page 32 www.aeg.com/shop...
