  • Page 1 RMD9024 USER MANUAL...
  • Page 3 Product Information Model: RMD9024 LCD MONITOR Version: V030002 Release Date: March 12th, 2015 Company OSEE TECHNOLOGY CO., LTD. Contact Information No.22 Building, No.68 zone, Beiqing Road, Haidian District, Address: Beijing, China Post Code: 100094 (+86) 010-62434168 Tel: Fax: (+86) 010-62434169 http://www.osee-dig.com/...
  • Page 4 The user manual applies to the following device types:  RMD9024-HSC  RMD9024-SC  RMD9024-V The images of RMD9024-HSC are adopted in the following descriptions. Any of the different specifications between the device types are elaborated. Before reading the manual, please confirm the device type.

  • Page 5: Table Of Contents

    Chapter 1 Product Overview ....................1 Chapter 2 Safety Precaution for Use .................. 2 Chapter 3 Unpacking and Installation ................4 Chapter 4 Using the RMD9024 ................... 5 4.1 Status Display of the Screen ......................5 4.2 Front Panel Controls ........................6 4.3 Quick Button Descriptions ......................

  • Page 6: Chapter 1 Product Overview

    Chapter 1 Product Overview The 4U rack mounted RMD9024 represents new trend in LCD monitor for broadcast and professional video applications. It has 800X480 high resolution, anti-glare TFT screens with full digital signal processing. HD-SDI, SD-SDI and analog composite video standards are accepted of this model. All video formats are scaled to fit on screen in the highest quality using full digital processing, precision scaling and Gamma correction to produce the best images available.

  • Page 7: Chapter 2 Safety Precaution For Use

    RMD9024 LCD MONITOR User Manual Chapter 2 Safety Precaution for Use FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules.
  • Page 8 Warnings: Read and keep these instructions. Heed all warnings. Follow all instructions. About the Position Do not block any ventilation openings. Do not use this unit near water. Do not expose the unit to rain or moisture. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that product heat.

  • Page 9: Chapter 3 Unpacking And Installation

    Connect A.C. Mains power using the included power cord. Please ensure an Earth ground present to ensure proper operation of the unit. Fasten the power protect accessory. As a final step turn on each screen of the RMD9024 by depressing the power switch located on the front of the unit.

  • Page 10: Chapter 4 Using The Rmd9024

    3. Safe Areas: Multiple safe areas are configurable in the MAIN Menu 4. Audio Meters: Levels for the audio. For RMD9024-SC and RMD9024-V, only two meters on the left side. 5. UMD: The MAIN Menu provides settings to customize the (In-Monitor Display) text area to show a line of characters, numbers, and/or some symbols.

  • Page 11: Front Panel Controls

    RMD9024 LCD MONITOR User Manual  Referring to the circumstance of no sync ( power on): Will indicate on the top left hand of screen: IN A: NO SYNC On the bottom of screen will UMD and METER be shown, but the display of UMD and METER is subject to the current main menu setting.
  • Page 12 3: SCAN Press to display the 100% image (UNDER SCAN) and 95% (NORMAL) image. 4/5/6: USER1~ USER3 “USER1~ USER3” serve as the quick-button; its function can be assigned in the main MENU. （For more information, please refer to “Chapter 4.3.2”） 7: MENU Press to display the main menu.

  • Page 13: Quick Button Descriptions

    RMD9024 LCD MONITOR User Manual 4.3 Quick Button Descriptions 4.3.1 ENTER BUTTON When MENU is not used, you can press ENTER to regulate the following parameters: VOLUME, BRIGHTNESS, CONTRAST, SATURATION, SHARPNESS, and HUE. Press ENTER six times, parameters will cycle. You can get the exact value combined with buttons of ∧（up）or ∨(down).
  • Page 14 The different apparatus model includes different user menu items. The options are as follows. (The underlined value means the DEFAULT value.) User Menu Items MODEL RMD9024-V RMD9024-SC RMD9024-HSC BUTTON ITEM    USER 1 SD ASPECT* H/V DELAY H/V DELAY ...

  • Page 15: Menu Button

    RMD9024 LCD MONITOR User Manual 4.3.3 MENU BUTTON When you want to change the value of a parameter, you may use MENU, and you can follow four steps.  Step 1: Press MENU, and you can enter the main MENU.
  • Page 16 Monitor video input Monitor video input TALLY IN channel B (HD-SDI/SDI channel A (HD-SDI /SDI DB-9 Male /Analog Composite) /Analog Composite) Analog audio Analog audio RS485 12VDC from input channel 1 input channel 2 connector Power Supply  Tally IN connector (DB9 male) : Tally IN (DB-9 Male) Pin 1 CH1-R...

  • Page 17: Chapter 5 Main Menu Structure

    RMD9024 LCD MONITOR User Manual ( Female RJ-45 Receptacles ) Pin No. RS485 IN Terminal Signal RS485 OUT Terminal Signal Chapter 5 Main Menu Structure The descriptions of main menu structure are as follows: (The operation of main menu refers to Chapter 4.3.3) The main menu includes seven sub-menu icons.

  • Page 18: Video Sub-Menu

    MON SOURCE MET 1…MET 4 Used to set the monitoring audio source from among audio meters. Note: For RMD9024-HSC, there are four audio meters (MET1~MET4). For RMD9024-SC/ RMD9024-V, there are only two audio meters (MET1~MET2). User Manual for RM7023...
  • Page 19 Used to set the horizontal position of left audio meter. METER H POS R 000…255 Used to set the horizontal position of right audio meter. Only used for RMD9024-HSC. TEST LEV -18dB…-20dB Used to set the test level of audio meter. AUDIO (2/5) IN A: MET 1 NONE…VU...

  • Page 20: Marker Sub-Menu

    INB connector. IN B: MET 2 NONE…VU Note: …PK…VU+PK For RMD9024-HSC, there are four audio AUDIO (4/5) meters (MET1~MET4). IN B: MET 3 NONE…VU For RMD9024-SC/ RMD9024-V, there are …PK…VU+PK...

  • Page 21: Osd Sub-Menu

    RMD9024 LCD MONITOR User Manual ON…OFF Select ON to enable the 90% safe area size of the image display and OFF not to display. No function in h/v delay mode ON…OFF Select ON to enable the 80% safe area size of the image display and OFF not to display.
  • Page 22 UMD PROTOCOL LOCAL…TSL V3.1 …TSL V4.0…IMAGE VIDEO UMD ID 0…255 device independently through downloading software and with the set value, convenient for remote control OSD (3/3) UMD NAME(S/N) S00000 16 Characters totally. UMD NAME is in compliance with IMAGE VIDEO Protocol UMD TLY MODE T1…T2…T1T2…T2T1 UMD TLY MODE is in...
  • Page 23 RMD9024 LCD MONITOR User Manual *3. UMD FIXED SETUP Use this setting to display static UMD text on the screen. This setting is used to enter UMD text locally, when a serial protocol is not used for remote control. The UMD will be overridden by serial protocol commands.
  • Page 24 *8. UMD Name (S/N) Use this setting to assign a name to each screen when using the Image Video protocol. The UMD name is equivalent to the Image Video serial number and is used by the Image Video controlling device to identify each screen. The default UMD Name(S/N) is “S00000.” It is recommended to maintain this naming scheme in order to avoid serial number conflicts with other Image Video devices on the same serial bus.

  • Page 25: User Control Sub-Menu

    RMD9024 LCD MONITOR User Manual 5.6 USER CONTROL Sub-menu Input Signal PARAMETERS Domain Range NOTE CVBS SD-SDI HD-SDI SCAN NORMAL…UNDER SCAN Used to adjust the image display scale.  NORMAL: 95%  UNDER SCAN:100% SD ASPECT 4:3…16:9 Used to adjust the screen Aspect Ratio.

  • Page 26: Chapter 6 Technical Specifications

    WFM/ VT MODE SOLID…75% Used to set the transparence of the …50%…25% waveform and vectorscope.  SOLID:100%over cover background  75%:75%over cover the background  50%:50%over cover the background  25%:25%over cover the background Chapter 4.3.2 USER 1 H/V DELAY USER2 SD ASPECT Chapter 4.3.2...
  • Page 27 RMD9024 LCD MONITOR User Manual Signal Format RMD9024 are compatible with the following Signal Formats: Product Number Signal Formats NTSC、PAL 480i-59.94、576i-50 1035i-59.94、1035i-60、1080i-50、1080i-59.94、1080i-60、1080p-23.97、 RMD9024-HSC 1080p-24、 1080p-25、 1080p-29.97、 1080p-30、 1080PsF-23.97、 1080PsF-24、 720p-50、 720p-59.94、 720p-60、 720p-23.97、 720p-24、 720p-25、 720p-29.97、 720p-30 NTSC、 PAL RMD9024-SC 480i-59.94、576i-50...
  • Page 28 Dimensions: Front View Unit: mm Rear View and Side View Unit: mm Top Side View Unit: mm User Manual for RM7023 - 23 -...

  • Page 29: Chapter 7 Warranty For Lcd Monitor

    This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty. If there is no proof of purchase provided with a warranty claim, osee reserves the right not to honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer.
