LMW-170 SERIES LCD MONITOR
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LMW-170 SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for OSEE LMW-170 SERIES

Summary of Contents for OSEE LMW-170 SERIES

  • Page 1 LMW-170 SERIES LCD MONITOR USER MANUAL...
  • Page 2 PRODUCT INFORMATION MODEL: LMW-170 SERIES LCD MONITOR Version: V020100 Release Date: 2010-07-30 COMPANY NAME Beijing Osee Digital Technology Ltd. CONTACT INFORMATION Address: Room 702, Tower D, Jinyujiahua Building, No.9, 3rd Shangdi Street, Haidian District, Beijing, China Post code: 100085 Tel: 8610-62968823 Fax: 8610-62977165 Http://www.osee-dig.com...
  • Page 3 About The USER MANUAL The user manual applies to the following device types: LMW-170H LMW-170S LMW-170V The images of LMW-170H are adopted in the following descriptions. Any of the different specifications between the device types are elaborated. Before reading the manual, please confirm the device type.

  • Page 4: Table Of Contents

    Chapter 5 Menu Operation Guide ................... 13 5.1 Selecting the Menu Language ....................13 5.2 Using the Menu..........................14 Chapter 6 LMW-170 Series LCD Monitor Menu Structure ......... 15 6.1 Main Menu..........................15 6.2 Adjusting and Changing the Settings ..................15 Chapter 7 Technical Specifications................... 28 7.1 Product Detailed Information:....................28...

  • Page 5: Chapter 1 Product Overview

    LMW-170 SERIES LCD MONITOR User Manual Chapter 1 Product Overview The LM170 is a cost-effective 17 inch LCD monitor that can be used for post production rooms, broadcasters and mobile units, monitoring multi-format high definition video and audio. The LM170 is equipped with 1920×1200 high resolution panel and capable of displaying 1080 format high definition signal at native resolution.

  • Page 6: Chapter 3 Dimensions

    LMW-170 SERIES LCD MONITOR User Manual Chapter 3 Dimensions Front View （Unit: mm） Rear View （Unit: mm ） —2—...
  • Page 7 LMW-170 SERIES LCD MONITOR User Manual （Unit: mm） Side View Top Side View （Unit: mm） —3—...

  • Page 8: Chapter 4 Operation

    LMW-170 SERIES LCD MONITOR User Manual Chapter 4 Operation Status Display Wave form or vector graph TALLY Indicator Signal format Area & Safety Marker Audio Meter Speakers Time Code Tally Indicator： It is used to check the status of the monitor by the color of the tally lamp.

  • Page 9: Input Signals

    LMW-170 SERIES LCD MONITOR User Manual 4.2 Input Signals The following input signals are supported by the LMW-170 monitor: Format Video YPbPr HDMI Device Type* LMW-170 LMW-170 LMW-170 LMW-170 LMW-170 LMW-170 LMW-170V LMW-170S LMW-170H NTSC SECAM NTCS-4.43 PAL-M 480I60 576I50...
  • Page 10 LMW-170 SERIES LCD MONITOR User Manual The specifications of terminals are as follows ： SDI IN1 : SDI 1 Input Terminal SD-SDI input signal which is in compliance with SMPTE259M and ITU-R BT656 standard. SDI IN2 : SDI 2 Input Terminal SD-SDI input signal which is in compliance with SMPTE259M and ITU-R BT656 standard.
  • Page 11 LMW-170 SERIES LCD MONITOR User Manual B. The right part of rear panel The specifications of terminals are as follows ： GPI ：GPI Terminal Female RJ-45 Receptacle Description PIN 1 GPI1 PIN 2 GPI2 PIN 3 GPI3 PIN 4 GPI4...
  • Page 12 LMW-170 SERIES LCD MONITOR User Manual 2 CONFIG ：Configuration Terminal It is used to update the program only. 3 RS485 IN : RS485 IN Terminal ； 4 RS485 OUT : RS485 OUT Terminal ； Female RJ-45 Receptacles Pin No. RS485 IN Terminal Signal RS485 OUT Terminal Signal /–...

  • Page 13: Location And Function Of Control Buttons And Knobs On Front Panel

    LMW-170 SERIES LCD MONITOR User Manual 4.4 Location and Function of Control Buttons And Knobs On Front Panel （1）POWER : Power Standby / ON Switch /– Press this switch to turn on the power of this unit or to set this unit in the standby mode(the power switch on the rear panel is turned on).
  • Page 14 LMW-170 SERIES LCD MONITOR User Manual （8）ASPECT Button/lamp Press to set the aspect ratio of the picture, 4:3 or 16:9. Scaled mode only effects for SD signal. For VGA, DVI and HD input signal, it is not valid and is defaulted to 16:9 mode.
  • Page 15 LMW-170 SERIES LCD MONITOR User Manual （12）MENU, ENTER, UP, DOWN Button Displays or sets the main menu. Menu button: Press to display the main menu, when the on-screen menu is not the main menu. Press again to clear the main menu. (For more information, see the chapter 5) Enter button: Press to confirm a selected item on the menu, when the on-screen menu is the main menu .

  • Page 16: Input Signals And Adjustable/Setting Items

    LMW-170 SERIES LCD MONITOR User Manual (16) CONT Knob Displays and adjusts the picture contrast value: 1. Press this knob to display the picture contrast value. 2. Adjust the knob clockwise, the value increases. Adjust the knob counter-clockwise, the value decreases.

  • Page 17: Chapter 5 Menu Operation Guide

    LMW-170 SERIES LCD MONITOR User Manual Chapter 5 Menu Operation Guide 5.1 Selecting the Menu Language You can select one of two languages (English, Chinese) for displaying the menu and other on-screen displays. ”English” is selected in the default setting.

  • Page 18: Using The Menu

    LMW-170 SERIES LCD MONITOR User Manual 5.2 Using the Menu The unit is equipped with an on-screen menu for making various adjustments and settings such as STATUS, COLOR TEMP, MARKER, etc. The current settings are displayed in place of the marks on the illustrations of the menu screen.

  • Page 19: Chapter 6 Lmw-170 Series Lcd Monitor Menu Structure

    LMW-170 SERIES LCD MONITOR User Manual Chapter 6 LMW-170 Series LCD Monitor Menu Structure 6.1 Main Menu The screen menu of this monitor consists of the following items. [Label] [Main Menu Item] [Sub Menu] STATUS COLOR TEMP MARKER VIDEO CONFIG...
  • Page 20 LMW-170 SERIES LCD MONITOR User Manual For the DVI/VGA input, the following items are displayed. STATUS FORMAT DVI-I:DVI-D SXGA COLOR TEMP 15.63kHz 60Hz AUTO STANDBY MODEL* LMW170-H * For Model, it will display LMW-170H or LMW-170S or LMW-170V, depending on the unit model.
  • Page 21 LMW-170 SERIES LCD MONITOR User Manual MARKER The MARKER menu is used for setting the marker. Sub Menu Settings Explanation MARKER -MARKER ENABLE ON <ON> marker displayed <OFF> marker not displayed -AREA MARKER 15:9 Selects the area marker aspect ratio according to the...
  • Page 22 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation -MARKER LEVEL <1> Sets the luminance to display safety, center and area marker line. <1>: 50% white level <2>: 75% white level <3>: 100% white level -MARKER MAT <OFF> Sets the area marker mat transparency.
  • Page 23 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation VIDEO CONFIG PICTURE CONTROL -AUTO SETUP Automatic Pixel Adjustment, press to adjust the picture automatically to maximize clarity and correct H/V position for the VGA input signal -SHIFT H 50 Adjusts the horizontal position of the picture <0-100>...
  • Page 24 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation -SPEAKER R AUD 1R The same as above (EBD CH2) -METER POSITION HORIZONTAL <HORIZONTAL> <VERTICAL> -METER DISP OFF <OFF> <ON> -METER 1-4 DISP OFF <OFF> <1-2> <1-4> -METER 5-8 DISP OFF <OFF>...
  • Page 25 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation -METER 6 The same as above (EBD CH6) -METER 7 The same as above (EBD CH7) -METER 8 The same as above (EBD CH8) Press ∧(up)or ∨(down) button to select “NEXT PAGE” item, then press Enter button to display the next page menu as follows.
  • Page 26 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation USER CONFIG 1/5 SYSTEM SETUP -NEXT PAGE -BACKLIGHT 50 Adjusts the backlight <0 ... 100> -LINE 2 INPUT VIDOE Selects the LINE 2 input type <VIDEO> <Y/C> <YPbPr> -DVI-I INPUT VGA Selects the DVI-I input type <VGA>...
  • Page 27 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation USER CONFIG 2/4 -NEXT PAGE OFF <ON> -UMD DISPLAY <OFF> RED <RED> -UMD COLOR <GREEN> <YELLOW> <WHITE> -UMD LMW-170H MONITOR 16 characters CHARACTER OFF <ON> -TC DISPLAY <OFF> Display --:--:--:-- if no TC in ANC OFF <OFF>...
  • Page 28 LMW-170 SERIES LCD MONITOR User Manual Press ∧(up)or ∨(down) button to select “NEXT PAGE” item, then press Enter button to display the next page menu as follows. Sub Menu Settings Explanation USER CONFIG 3/4 FUNCTION BUTTON SETUP -NEXT PAGE -F1 BUTTON...
  • Page 29 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation USER CONFIG 4/4 GPI SETUP -NEXT PAGE -GPI1 TALLY R <NONE> <TALLY R> <TALLY G> <SDI 1> <SDI 2> <LINE 1> <LINE 2> <DVI-I> <H/V DELAY> <MONO> <BLUE ONLY> <NORMAL SCAN>...
  • Page 30 LMW-170 SERIES LCD MONITOR User Manual Sub Menu Settings Explanation USER CONFIG 5/5 -NEXT PAGE -UMD PROTOCAL LOCAL LOCAL/TSL3.1/TSL4.0/IMAGE VIDEO LOCAL: Use UMD setting (USER CONFIG 2/5) to control the UMD. TSL3.1: Use the TSLV3.1 protocol setting to control the UMD from a TSL tally controller.
  • Page 31 LMW-170 SERIES LCD MONITOR User Manual state. This mode requires to the UMD tally mode parameter to be set. IMAGE VIDEO 422: Use the setting to control tally state via 422 port. GPI toggle is no available. STANDARD +IV422: OSD and LED tally setting are the same as STANDARD and IMAGE VIDEO 422.

  • Page 32: Chapter 7 Technical Specifications

    LMW-170 SERIES LCD MONITOR User Manual Chapter 7 Technical Specifications 7.1 Product Detailed Information: Display Area 17” diagonal (14.46 X 9.04”, 367.2 X 229.5mm) Viewing Angles 140 degree (H) X 120 degree (V) Color Depth 16.2M Resolution 1920H X 1200V 0.191 X 0.191mm...

  • Page 33: Standard Definition Video, Frame Refresh Rate And Color Matrix (1920×1200)

    LMW-170 SERIES LCD MONITOR User Manual × 7.4 Standard Definition Video, Frame Refresh Rate and Color Matrix (1920 1200) Tab.1 OVERSCAN NATIVE INPUT OUTPUT INPUT OUTPUT 1920X1080, NTSC 684X462 720X487 720X487 1600X1200 1920X1080, 684X548 720X576 720X576 1600X1200 1920X1080, SECAM 684X548...
  • Page 34 LMW-170 SERIES LCD MONITOR User Manual Tab.2 FULL NORMAL Frame Color Matrix Rate INPUT ALL OUTPUT NORMAL 1920X1200 NTSC NTSC 720X487 1920X1080(16:9), 1600X1200(4:3) 1920X1080, 720X576 1600X1200 1920X1080, SECAM SECAM 720X576 1600X1200 1920X1080, NTCS-4.43 NTCS-4.43 720X487 1600X1200 1920X1080, PAL-M PAL-M 720X487...

  • Page 35: Chapter 8 Supplied Accessories

    LMW-170 SERIES LCD MONITOR User Manual Chapter 8 Supplied Accessories Standard accessories: 1. Display 2. AC Power Cord 3. M3 x 6mm Screws 4. Warranty Card 5. Table Stand 6. User Manual Optional accesories: Rack Mount Ears. Note：Specifications are subject to change without notice.
