  • Page 1 LMW-420-4K/ LMW-550-4K/ LMW-650-4K/ LMW-840-4K Ultra HD 4K LCD Monitor User Manual...
  • Page 3 Product Information LMW-420-4K/LMW-550-4K/LMW-650-4K/LMW-840-4K/ Model: LMW-840-4K Ultra HD 4K LCD Monitor V010400 Version: September 29th, 2016 Release Date: Company OSEE TECHNOLOGY CO., LTD. Contact Information No.22 Building, No.68 zone, Beiqing Road, Haidian District, Address: Beijing, China 100094 Post Code: (+86) 010-62434168 Tel:...

  • Page 4: Contents

     LMW-550-4K  LMW-650-4K  LMW-840-4K The images and descriptions of LMW-550-4K are adopted as examples in the following document. The basic features and functionalities for LMW-420-4K, LMW-550-4K, LMW-650-4K and LMW-840-4K are almost as the same, any of the different specifications among the device types are elaborated. Before...

  • Page 5: Table Of Contents

    Contents Contents ......................I   Chapter 1 Overview ..................1   Chapter 2 Safety ..................... 3   Chapter 3 Unpack and Installation ............... 7   Chapter 4 Device Features ................9   4.1 Control buttons Features ..............10   4.1.1 Arrangement of Control Buttons ............. 10  ...
  • Page 6 6.2.1 INPUT SETUP Menu ..............49   6.2.2 AUDIO Menu .................. 51   6.2.3 ADJUST Menu ................54   6.2.4 WIN1 UMD Menu ................55   6.2.5 WIN UD UMD Menu ............... 58   6.2.6 ALARM Menu ................61   6.2.7 SYSTEM Menu ................

  • Page 7: Chapter 1 Overview

    Overview Chapter 1 Overview The LMW-420-4K/LMW-550-4K/LMW-650-4K/LMW-840-4K LCD Monitor is a high performance broadcast UHD monitor tailoring most applications from program production, intensive upload/download, playout to studio and intensive monitoring all sorts of business in TV Stations. The front frame of the unit comes in a slim bezel design made from rubber mold.
  • Page 8 Overview Features  Prevailing slim bezel design  1080P individual quad split or use 4 synchronized inputs to produce 4K  Adopting Ultra HD, wide viewing angle IPS glass  Using 10-bit signal processing technology plus advanced conversion technology between the interlacing and the progressive ...

  • Page 9: Chapter 2 Safety

    Safety Chapter 2 Safety FCC Caution Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 10 Safety Warnings: Read, keep and follow all of these instructions for your safety. Heed all warnings. Device  Install in accordance with the manufacturer's instructions.  Do not beat with a hard object or scratch the LCD display. Do not make the freeze picture displaying on the screen time too long, ...
  • Page 11 Safety heat.  A nameplate indicating operating voltage, etc., is located on the rear panel.  The socket-outlet shall be installed near the equipment and shall be easily accessible. Power Supply Cord  Do not defeat the safety purpose of the polarized or grounding-type plug.

  • Page 13: Chapter 3 Unpack And Installation

    Chapter 3 Unpack and Installation Unpack: When unpacking the components of LMW-550-4K monitor, please verify that none of the components listed in Table 3.1 are damaged or lack. If there is any missing, contact your distributors or OSEE for it.
  • Page 14 Unpack and Installation As a final step, turn on each screen of the device by pressing the corresponding power switch located on the front panel.  The pedestal and the monitor are packaged separately.  Connect a standard signal lines to the corresponding input port. All BNC connector impedance must be 75Ω.

  • Page 15: Chapter 4 Device Features

    Device Features Chapter 4 Device Features This chapter describes the features of LMW-550-4K monitor. The features of LMW-550-4K monitor are as shown in Figure 4-1 after installed and powered Figure 4-1 Features of LMW-550-4K Monitor Status Information It is displayed in the top left corner of the screen, and includes the input channel and signal format.

  • Page 16: Control Buttons Features

    There are a series of buttons at the back side of the screen, and these buttons are used to control the screen menu items. Figure 4.1-1 the Buttons at the back side of the Front Panel As shown in Figure 4.1-1, these buttons of LMW-550-4K are as follows: POWER ENTER...

  • Page 17: Operation Of Control Buttons

    LMW-650-4K, LMW-840-4K are not exactly the same: the bar of control buttons for LMW-420-4K and LMW-840-4K is at the left edge of the rear panel, vertically arranged; the bar of control buttons for LMW-550-4K is at the leftmost edge of the rear panel, vertically arranged; the bar of control buttons for LMW-650-4K is at the left bottom edge of the rear panel, horizontally arranged.
  • Page 18 Device Features  Enter into the next level menu: press ENTER button, you will enter into the menu item as this relationship: the Main menu list sub-menu list sub-menu value list, the current editable object is in yellow control icon; ...
  • Page 19 Device Features  The main menu, the adjust menu, the function menu and the input signal selection list of a screen may not be shown all simultaneously. This button can achieve the following two functions:  F2: F2 function button. Press F2 to display the function menu list in the center of the screen, F2 is related to the MOMO function, toggle F2 button to change the value to be ON or OFF.
  • Page 20 Device Features  The current editable function menu is labeled in yellow.  The control button contains only two function buttons: F1 and F2, these two buttons, F1 and F2, are different from the corresponding function buttons (F1 and F2) on the remote control, refer to "4.3 Remote Control Features" for the difference.
  • Page 21 Device Features Figure 4.1-6 Display Modes Comparison  UD: it is the 4K mode, it will display the combined four pictures of (SDI1~SDI4 combined signal source), HDMI(HDMI1~HDMI4 combined signal source).  QUAD: it is the quad split screen, it will display four pictures for four separate signal sources, the source could be SDI1, SDI2, SDI3, SDI4, HDMI1, HDMI2, HDMI3 or HDMI4.
  • Page 22 Device Features list and the interfaces in the back panel are shown in Figure 4.1-8: Figure 4.1-8 Correspondence between Source Menu and Interface  In UD mode, the HDMI signal source means a combined HDMI signal source through the four HDMI inputs(HDMI1~HDMI4 combined signal source).

  • Page 23: Display Mode

    Device Features The one-to-one correspondence between the signals in the source menu list and the interfaces in the back panel are shown in Figure 4.1-10: Figure 4.1-10 Correspondence between Source Menu and Interface  In UD mode, the SDI signal source means a combined SDI signal source through the four SDI inputs(SDI1~ SDI4combined signal source).
  • Page 24 Device Features Figure 4.1-11 UD Mode  Source Selection: Click SDI button to select SDI signal source, click HDMI button to select HDMI signal source, the source menu is displayed at the top left corner of the screen, as shown in Figure 4.1-12: Figure 4.1-12 Source Menu ...
  • Page 25 Device Features  Audio Meter Selection: Click MENU button, and select AUDIO menu in menu list, select the source to be HDMI or EBD to display the audio meter, it will display at the left center part of the display window, as shown in Figure 4.1-14: When the AUDIO SOURCE is set to be EBD, the audio meter source is SDI1;...
  • Page 26 Device Features displayed at both sides of UMD. These are the same as in other display modes, it will be no further description in the following.  Refer to “6.2.5 ” for the details about the UMD WIN UD UMD Menu settings in UD mode.
  • Page 27 Device Features Figure 4.1-17 Source Selection-QUAD Mode  Audio Meter Selection: you can specify the audio source for each window through the AUDIO network control page, as shown in Figure 4.1-18: Figure 4.1-18 Audio Meter-QUAD Mode  UMD Selection: set the UMD settings for each WINDOW* in its corresponding WIN* UMD network control page, the UMD information is as shown in Figure 4.1-19: LEFT UMD...
  • Page 28 Device Features  The UMD information for each window is independent of the other’s. Refer to “6.2.4 ” for the details about the UMD settings in WIN1 UMD Menu QUAD mode. SINGLE: 4K display mode There is only one picture for one signal source on the whole screen in SINGLE mode, as shown in Figure 4.1-20: SINGLE MODE Figure 4.1-20 SINGLE Mode...
  • Page 29 Device Features  Audio Meter Selection: Click MENU button, and select AUDIO menu in menu list, select the source to be HDMI or EBD to display the audio meter, it will display at the left part of the display window, as shown in Figure 4.1-22: When the AUDIO SOURCE is set to be EBD, the audio meter source is from the current signal source;...

  • Page 30: Rear Panel Features

    As shown in Figure 4.2-1, there are various input and output interfaces at the rear panel of LMW-550-4K monitor. Figure 4.2-1 The Rear Panel of LMW-550-4K Monitor The interfaces numbered from 1 to 8 in red dotted rectangle are described...

  • Page 31: Operations Of Rear Panel

    LMW-550-4K, LMW-650-4K are not exactly the same: the Power Switch and Power Input for LMW-420-4K are at the right end of the interfaces bar, but the Power Switch and Power Input for LMW-550-4K and LMW-650-4K are at the left end of the interfaces bar.
  • Page 32 Device Features computer to modify the network settings. Video Input/Output Interface (BNC) It provides a SDI input interfaces and a SDI output interfaces, they are labeled from left to right as SDI IN1, SDI OUT1. Video Input Interface (DVI-D) It provides one DVI-D input interface, it can receive DVI or HDMI signals. It is labeled as DVI-D IN1.
  • Page 33 Pin 7 GPI7 Pin 8 GPI8 Pin 9 The relationship of the pins of GPI interface and tally control for LMW-420-4K, LMW-550-4K, LMW-650-4K, LMW-840-4K are not exactly the same, the difference are as shown in Table 4.2-3 and Table 4.2-4. 27 ...

  • Page 34: Remote Control Features

    Device Features Table 4.2-3 The Relationship of GPI Pins and Tally Light- LMW-550-4K/LMW-650-4K/LMW-840-4K LMW-550-4K/LMW-650-4K/LMW-840-4K GPI TALLY Control GPI Pins QUAD SINGLE1/SINGLE3 SINGLE2/SINGLE4 GPI1 CH1 Red LEFT Red GPI2 CH1 Green LEFT Green GPI3 CH2 Red LEFT Red LEFT Red GPI4...

  • Page 35: Operations Of Remote Control

    Device Features Figure 4.3-1 The Remote Control of LMW-550-4K Monitor POWER INPUT MENU DOWN ENTER F4(Reserved) F5(Reserved) 4.3.2 Operations of Remote Control The functionality and usage of the buttons of the remote control are as follows: 29 ...
  • Page 36 Device Features Power Switch the power on or off. When the monitor is powered on, press this button to power it off, or when it is powered off, press this button to power the monitor on. INPUT (Reserved). Press 0~9 number to select the corresponding number. MENU It is used to activate the Main menu.

  • Page 37: Supported Signal Format

    Device Features This button can achieve the following two situations:  Work with the Main MENU: when working with the Main menu, ENTER button achieve the following functions:  Enter into the next level menu: press ENTER button, you will enter into the menu item as this relationship: the Main menu list...
  • Page 38 Device Features HDMI NTSC   480I60/59.94 576I50   480P60/59.94  576P50  720P24  720P25     720P30/29.97 720P50   720P60/59.94   1080SF24/23.97   1035I60/59.94   1080I50   1080I60/59.94   1080P24/23.97 ...

  • Page 39: Chapter 5 Functionality Of The Main Menu

    Functionality of the Main Menu Chapter 5 Functionality of the Main Menu This chapter describes the structure and functionality of the main menu, and introduces how to modify and customize the menu settings. The main menu includes the following menu items, as shown in Figure5-1. Figure 5-1 Main Menu 5.1 Main Menu Press the MENU button at the bottom of the front panel, the main menu is...
  • Page 40 Functionality of the Main Menu The menu interface is divided into three parts: Main Menu List It contains the title of the Main menu and several sub-menu items. The title of this list is MAIN. Press UP or DOWN to access the corresponding menu item.

  • Page 41: Status Menu

    Functionality of the Main Menu  when in the sub-menu item, it shows that this sub-menu item is selected, and the control icon is displayed as a yellow rectangle in front of it, as shown in Figure 5.1-4: Figure 5.1-4 A Sub-menu Item Is Selected ...

  • Page 42: Audio Menu

    FAST MODE OFF Show the fast mode. DISPLAY Show display SINGLE MODE mode. Show the production MODEL LMW-550-4K model. SERIAL Show serial LMW5502014090001 -- NUMBER number. IP ADDRESS 192.168.1.86 Show the IP address.  The sub-menu values in STATUS menu can’t be modified, they are displayed the actual status of the monitor.
  • Page 43 Functionality of the Main Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 5.1-2: Table 5.1-2 The Description of AUDIO Menu Items Default Items Domain Range Description Value Select the audio source. ...
  • Page 44 Functionality of the Main Menu The appearance of Meter is as shown in Figure 5.1-8: Figure 5.1-8 Audio Meter  METER SELECT control the operational characteristics of Audio Metering, the former controls the amount of channels displayed in a meter. Each G* contains four channels, and each CH* means a channel with number.

  • Page 45: Display Menu

    Functionality of the Main Menu  The prerequisite for the available settings of the display mode is that the METER SOURCE is not NONE. 5.1.3 DISPLAY Menu The DISPLAY menu items are used to adjust the parameters displayed on the screen, the menu items are as shown in Figure 5.1-10: Figure 5.1-10 DISPLAY SETUP Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 5.1-3:...

  • Page 46: Color Temp Menu

    Functionality of the Main Menu Figure 5.1-11 CONFIG Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 5.1-4: Table 5.1-4 The Description of CONFIG Menu Items Default Items Domain Range Description Value Set whether in fast FAST MODE...
  • Page 47 Functionality of the Main Menu Figure 5.1-12 COLOR TEMP Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 5.1-5: Table 5.1-5 The Description of COLOR TEMP Menu Items Items Default Value Domain Range Description USER1: Customized by user...

  • Page 48: Menu Settings

    Functionality of the Main Menu Items Default Value Domain Range Description D93: 9300K Reset the Gain and RESET Offset values to the product originals COLOR NATIVE/EBU/SMPTE-C/ Select the color matrix SPACE ITU-709/AUTO  The items about RED/GREEN/BLUE GAIN and BIAS are available only in USER1 and USER2 mode.
  • Page 49 Functionality of the Main Menu  Back to the Main menu After entering to a sub-menu item or a sub-menu item value, press MENU button to back to the upper level menu area.  Close the Main menu Press MENU button to close the Main menu when the control icon is in the Main menu item.
  • Page 50 Functionality of the Main Menu  Switch sub-menu item value When the control icon is in sub-menu item value, press UP or DOWN button to switch among its value list.  Confirm the modification to sub-menu item value Press ENTER button to confirm the selection of a value, and the control icon is back to the corresponding sub-menu item.
  • Page 51 Functionality of the Main Menu Step 3 Confirm the modification of the value of sub-item Click DOWN button to select the sub-item LANGUAGE to Chinese, as shown in Figure 5.2-4, press ENTER button to confirm the modification. Figure 5.2-4 Switching the Value of LANGUAGE Step 4 Exit the main menu Click MENU button to exit the main menu.

  • Page 53: Chapter 6 Network Control

    Ethernet interface to achieve the network control to LMW-550-4K.  The network address of the computer which is connected with LMW-550-4K and the network address of LMW-550-4K must be in the same segment. This chapter will introduce how to set and check the parameters of LMW-550-4K in Internet Explorer.

  • Page 54: Menu Control

    Network Control 6.2 Menu Control Open the management interface as shown in Figure 6.2-1, the menu items listed in the left part are almost as the same as the main menu items. Figure 6.2-1 Management Interface As shown in Figure 6.2-1, the management interface is divided into the following parts: Navigation menu list It shows the navigation menus: INPUT SETUP, AUDIO, DISPLAY,...

  • Page 55: Input Setup Menu

    Network Control list will change with the navigation menu when switched. Figure 6.2-2 Parameter List  The SET button is used to confirm the modification of the parameter value. 6.2.1 INPUT SETUP Menu It will introduce INPUT SETUP menu. Click INPUT SETUP button at the left navigation menu list, it is used to select the input signal for each window in different display modes, as shown in Figure 6.2-3: 49 ...
  • Page 56 Network Control Figure 6.2-3 INPUT SETUP Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-1: Table 6.2-1 The Description of INPUT SETUP Menu Items Items Default Value Domain Range Description INPUT Select the input signal in SDI/HDMI...

  • Page 57: Audio Menu

    Network Control  In QUAD mode, you can only select the signal source through network control page, but not by the remote control or the control buttons on the monitor. And, the signal source for the designated window must be from the corresponding interface.
  • Page 58 Network Control Figure 6.2-4 AUDIO Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-2: Table 6.2-2 The Description of AUDIO Menu Items Items Default Value Domain Range Description Select which SPEAKER_ WINDOW1/WINDOW2/W WINDOW1...
  • Page 59 Network Control Items Default Value Domain Range Description speaker When the audio source is Left speaker, select a SPEAK OUT EBD, the range of this channel according to EBD CH1 LEFT item is EBD CH1~ EBD the type of audio CH16.

  • Page 60: Adjust Menu

    Network Control Items Default Value Domain Range Description SOURCE WINDOW4 Select the reference REF LEVEL -20dB -20dB/-18dB level  -10dB  -8dB OVER Select the overload -8dB  -6dB LEVEL level  -4dB  -2dB Select meter METER CH1-2 The same as WIN1’s display mode in UD SELECT mode...

  • Page 61: Win1 Umd Menu

    Network Control Figure 6.2-6 ADJUST Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-3: Table 6.2-3 The Description of ADJUST Menu Items Items Default Value Domain Range Description CONTRAST 0~100 Adjust the picture contrast BRIGHTNESS 50 0~100...
  • Page 62 Network Control Figure 6.2-7 WIN1 UMD Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-4: Table 6.2-4 The Description of WIN1 UMD Menu Items Items Default Value Domain Range Description WIN1 Set whether to display the OFF/ON...
  • Page 63 Network Control Items Default Value Domain Range Description BACK COLOR R the background color for the left UMD Set the green component WIN1 LEFT UMD 0~256 of the background color BACK COLOR G for the left UMD Set the blue component WIN1 LEFT UMD 0~256 of the background color...

  • Page 64: Win Ud Umd Menu

    Network Control Items Default Value Domain Range Description UMD COLOR B of the characters color for the right UMD WIN1 OSD TALLY TALLY OFF/GPI/TSL SOURCE source for window1 WIN1 OSD TALLY RG/GR/RGY/O TALLY MODE display mode for window1 TSL3.1  WIN1 TSL4.0 ...
  • Page 65 Network Control Figure 6.2-8 WIN UD UMD Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-5: Table 6.2-5 The Description of WIN UD UMD Menu Items Items Default Value Domain Range Description Set whether to display the OFF/ON DISPLAY...
  • Page 66 Network Control Items Default Value Domain Range Description LEFT LEFT/CENTER/ Set the alignment for the LEFT UMD ALIGN RIGHT left UMD LEFT Set the red component of BACK 0~256 the background color for COLOR R the left UMD Set the green component LEFT BACK 0~256...

  • Page 67: Alarm Menu

    Network Control Items Default Value Domain Range Description of the characters color for the right UMD Set the blue component WIN UD RIGHT 0~256 of the characters color for UMD COLOR B the right UMD TALLY OFF/GPI/TSL TALLY SOURCE source for window1 RG/GR/RGY/O TALLY TALLY MODE...
  • Page 68 Network Control Figure 6.2-9 ALARM Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-6: Table 6.2-6 The Description of ALARM Menu Items Default Domain Items Description Value Range WIN1 VIDEO LOST OFF OFF/ON Enable/Disable WIN1 video lost alarm WIN1 AUDIO LOST OFF OFF/ON Enable/Disable WIN1 audio lost alarm...

  • Page 69: System Menu

    Network Control  ALARM Icons Only in QUAD mode, there will be the corresponding alarm icon at the center of the window when alarm happens. The video loss alarm displays VIDEO LOSS characters, and the audio loss alarm displays VIDEO LOSS characters, as shown in Figure 6.2-10: Figure 6.2-10 ALARM Icons ...
  • Page 70 Network Control system parameters, as shown in Figure 6.2-11: Figure 6.2-11 System Menu The relationship of Items, Default Value, Domain Range and Description of the sub-item is shown in Table 6.2-7: Table 6.2-7 The Description of System Menu Items Domain Items Default Value Description...

  • Page 71: Other Menus

    Network Control Domain Items Default Value Description Range NCU Version 6130 Display the product information 6.2.8 Other Menus The menu items in main menu on screen display are mostly as the same as the menu items listed in navigation menus: DISPLAY, CONFIG and COLOR TEMPERATURE, please refer to the corresponding sections in “Chapter 5 Functionality of the Main Menu”, there will be no further description about their meanings and value range in this chapter.
  • Page 72 Network Control Figure 6.2-13 Screen Main Menu for AUDIO Click button to display the drop-down value list for the parameter, as shown in Figure 6.2-14, for example, modify “CH1-2” to “G1”. Figure 6.2-14 Display the Drop Down Value List of Meter Select(S) Click button to confirm the selection and the page is refreshed.
  • Page 73 Network Control Figure 6.2-15 Modify the Value of a Parameter  The volume can be checked and modified in adjust menu on screen adjustment, or in Volume item of ADJUST menu in management interface. Figure 6.2-16 The Value is Modified Simultaneously on Screen Menu Likewise, if you modify the value of a parameter on screen menu first, you may check the same changing result in management interface through network connection.

  • Page 75: Chapter 7 Specifications

    Specifications Chapter 7 Specifications Product detailed information Specification Values Model LMW-420-4K LMW-550-4K LMW-650-4K LMW-840-4K LCD Dimension 42”, 954 x 552.75 x 81 55”, 1245 x 715.5 x 81 65”, 1461.4 x 836.5 x 81 84”, 1917.7 x 1103.5 x 95.7...
  • Page 76 Specifications Specification Values Operating Temperature 0°C~35°C Operating Humidity 20%~80% (no condensation) 2. Input/Output Resolution, Frame Refresh Rate and Color Matrix OVERSCAN NATIVE FULL/NORMAL Refresh Color OUTPUT Rate Matrix Input Output Input Output INPUT ALL NORMAL 1366X768 1366X768 NTSC 684X462 720X487 720X487 720X487 1024X768...
  • Page 77 Specifications OVERSCAN NATIVE FULL/NORMAL Refresh Color OUTPUT Rate Matrix Input Output Input Output INPUT ALL NORMAL SVGA 800X600 1366X768 60-75 1024x768 1366X768 60-75 SXGA 1280x1024 1366X768 60-75 UXGA 1600x1200 1366X768 WXGA 1360X768 1360X768 WUXGA 1920x1200 1366X768 *Don’t display all OSD when SCAN is NATIVE. Dimensions ...
  • Page 78 Specifications Figure 7-2 Rear Panel(Unit: mm) Figure 7-3 Side View(Unit: mm) 72 ...
  • Page 79 Specifications Figure 7-4 Top View(Unit: mm)  The description of LMW-550-4K dimensions is shown as in the following figures: Figure 7-5 Front Panel(Unit: mm) Figure 7-6 Rear Panel(Unit: mm) 73 ...
  • Page 80 Specifications Figure 7-7 Side View(Unit: mm) Figure 7-8 Top View(Unit: mm) The description of LMW-650-4K dimensions is shown as in the following figures: 74 ...
  • Page 81 Specifications Figure 7-9 Front Panel(Unit: mm) Figure 7-10 Rear Panel(Unit: mm) 75 ...
  • Page 82 Specifications Figure 7-11 Side View(Unit: mm) Figure 7-12 Top View(Unit: mm)  The description of LMW-840-4K dimensions is shown as in the following figures: 76 ...
  • Page 83 Specifications Figure 7-13 Front Panel(Unit: mm) Figure 7-14 Rear Panel(Unit: mm) 77 ...
  • Page 84 Specifications Figure 7-15 Side View(Unit: mm) Figure 7-16 Top View(Unit: mm)  Specifications are subject to change without notice. ------------------No Text Below------------------ 78 ...
  • Page 85 FOR MORE INFORMATION PLEASE VISIT: http://www.osee-dig.com/ OSEE TECHNOLOGY CO., LTD. No.22 Building, No.68 zone, Beiqing Road, Haidian District, Beijing, China Tel: (+86) 010-62434168, Fax: (+86) 010-62434169 E-mail: sales@osee-dig.com...
