KAPITEL 9
INSTRUCTIONS

Use of the Anodizer Multi Holder (accessories)

1
2
3
2/2
1/2
0
4
The Anodizer Multi Holder Set consists of:
• 7 x long rods
• 7 x short rods
• 7 x clamps
• 1 x Anodizer Multi Holder
• 1 x anode plug
• 1 x wrench
Fix the mounting rods to the Anodizer Multi
Holder.
Fit at least 3 (max.6) mounting rods to the
outermost threaded holes and tighten slightly with
a wrench.
The internal threaded holes are intended for
anodising screws.
Remove the tray from the
Titanium Spectral-Colouring Anodizer and fill it
with cold water.
2/2
The filling quantity depends on the titanium bases
1/2
or screws to be anodised and the rods used.
0
ATTENTION: The filling level must not be
higher than the length of the rods used.
38 38
M2
M1,8
M1,6
M1,4
