Titanium Spectral-Colouring Anodizer - Zirkon zahn titanium spectral-colouring anodizer Operator And Maintenance Manual

KAPITEL 2
COMPONENTS

TITANIUM SPECTRAL-COLOURING ANODIZER

01
02
05
07
01. Start button
(Short push - 3 seconds anodising time)
(Long push - 11 seconds anodising time)
02. Display
03. Voltage regulator
04. ON/OFF switch
05. Anode plug
06. Cathode plug
07. Ventilation fan
08. Suspension device
09. Connection cable
13
03
04
14
06
08
09
10
11
12
10. Shelf for accessories
11. Cathode plug connection
12. Anodising tray
13. Front panel lever arm
14. Power plug connection
16 16
