RGBlink mini-mx Quick Start Manual page 6

❹ Channel Fader
❺ Listen and Mute Buttons
❻ T-Bar
❼ Page Up
❽ Page Down
❾ Button 1~8
5-Direction Joystick
❿
⓫ MENU Button
www.rgblink.com
turns into green, then press the button again to close layer.
● Long press to enter LAYOUT interface.
● Control audio volume level for each channel.
● Indicate MIC1 、 MIC2 、 Line-in 、 Bluetooth 、 PREVIEW 、
PROGRAM from left to right.
● Listen Button: Audio management for monitoring port.
Button in green allows users to monitor the audio from a
channel ; no button light indicates monitoring function is OFF.
● Mute Button: Mute that channel on PGM port. When a
channel is muted, the button will be illuminated red; no button
light indicates the channel is ON at PGM port.
PVW and PGM views can be transitioned by pushing T-bar.
Press to return to the previous page.
Press to enter the next page.
● Button 1~8 indicate 8 selections in Main Menu.
● Button 1~4 can also be used as 1~4 HDMI inputs switch
button. When the signal is in PGM, the button will be
illuminated red; When the signal is being edited, the button
illuminated green.
● Set pan, tilt and zoom for PTZ camera.
● Position adjustment for layer.
● Press to switch interface between Preview Interface 、Main
5
