What's in the box?
EV Wall mounting plate
EV Wall Business
×3
×3
Screw & plug
Small screw
QR code
Smart Charge
sticker
Card
EV
Smappee
owner
EV Charging station
Quick Starter Guide
Quick Install
Quick Starter
Guide
Guide
Optional: 8 m cable with cable holder
EV Wall
BUSINESS
Connection diagram
Fixed cable version
LED Board
Front panel
Socket version
LED Board
Front panel
In case of 3-phase delta (3*230 V) or
shutter version, consult the full manual
at smappee.com/downloads
or via the QR code:
Manual
Power supply
Connect
L1
L2
L3
N
PE
L1
MID
RCD
L2
meter
L3
L3
L2
L1
N
N
PE
CP
PP
A
B B
A+B
Charging
Power
Ethernet
cable
supply
cable
cable
Power supply
Connect
L1
L2
L3
N
PE
L1
MID
RCD
Lock
L2
meter
L3
L3
L2
L1
N
N
PE
CP
PP
A
B B
A+B
Power
Ethernet
supply
cable
cable
EN
Safety warning
Carrying out electrical work within the home or workplace
can be dangerous and must be conducted according to the
appropriate national safety standards and executed by a
certified electrician.
For safety purposes, it is also necessary to power off
the installation before proceeding with the physical
installation.
For further safety instructions
and more detailed information,
please consult the full manual at
smappee.com/downloads
or via the QR code:
How to install EV Wall
BUSINESS
1
Prepare the installation. Foresee an ethernet cable
with stable internet connectivity, and a power supply
cable between the distribution panel and the EV Wall.
Note: the power supply cable must be protected by the
appropriate circuit breaker and RCD where required.
2
Optional: install Smappee Infinity in the distribution
panel. Consult the Infinity installation manual
at smappee.com/downloads.
Smart Charging functionality requires the installation of Smappee
Infinity to measure the grid and solar production.
3
Fix the mounting plate to the wall with the provided
plugs and screws.
4
Attach the EV Wall housing to the EV Wall mounting
plate with the provided small screws.
Connect the power supply cable, ethernet cable and
5
charging cable (if applicable) to the EV Wall. Connect
the cable to the LED board on the front panel, but do not
close it yet.
See diagrams overleaf. In case of 3-phase delta (3*230 V) or shutter
version, please consult the full manual online.
Switch on the power using the circuit breaker.
6
7
Download the Smappee App and follow the instructions
to configure your Smappee charging station. If an
Infinity installation is already present, make sure to add
the charging station to the existing Smappee location.
8
Close the EV Wall by attaching the front panel and
tightening the M4 nuts.
9
Use the Smappee app to send an invite to your
customer's email address to share the newly created
location with them. This user account will be used for
the Smappee App and Dashboard and to set smart
charging preferences. Lastly, hand over the Quick
Starter Guide.
