Table 35 - Lei Series Scanner Specifications
Item
Scan
17
Speed
Illumination
Resolutions
Paper Path
Scan Width
Minimum Scan Width
Document Width
Maximum Scan Length
Scan Accuracy
Media Thickness
Modes
Operating Environments
Acoustic Noise
Power Supply
Power Consumption
Compliances
17
The scan rate is proportional across the full range of resolutions supported by the scanner. Actual scan times will depend
on the host system performance. Quoted top speeds may be limited by the effective bandwidth of the USB 2 and is not
guaranteed for all media types.
18
The quoted scan accuracy may vary depending on the operating environment and the thickness of the media.
imagePROGRAF TM-Series Service Guide
Revision 4
Colortrac Lei Series Scanner Specifications
L36ei Scanner
300/300dpi Standard:
•
Color: up to 1" per second
•
Monochrome: up to 3" per second
300/600dpi High:
COPY
•
Color up to 1" per second
•
Monochrome up to 3" per second
600/600dpi Best:
•
Color up to 0.5" per second
•
Monochrome up to 1.5" per second
200dpi Standard:
•
Color up to 1" per second
•
Monochrome up to 3" per second
300dpi High:
SCAN
•
Color up to 0.5" per second
•
Monochrome up to 1.5" per second
600dpi Best:
•
Color up to 0.33" per second
•
Monochrome up to 1" per second
96 LEDs
Optical: 600 dpi
Scan Mode: 200/400/600dpi
Face up, rear exit. Forward document transport only.
Document return guide included. (1 for L24ei, 3 for L36ei)
Up to 6" (15 cm)
Up to 38" (965 mm)
18
0.2% ; +/- 1 pixel
Minimum: Approximately 0.003" (0.07 mm)
Maximum: Approximately 0.020" (0.50 mm)
• Scan to USB - RGB/Greyscale/BW, TIFF (No ScanApp Lei)
• Scan to USB - RGB/Greyscale/BW, JPG, PDF, M-PDF (ScanApp
Lei available)
• Scan to PC - RGB/Greyscale/BW, Tiff, JPEG, PDF, TiffG4, M-PDF
• Copy - RGB/Greyscale/BW
• Copy & Archive – (Combination of Copy and Scan to PC above).
• Cloud connectivity is achieved by using Direct Print & Share.
10 – 35°C, 35-90% RH, Non-condensing
50.6 dB gray scan
External PSU: Input: 100-240 V, 50-60 Hz
Output: 3.42 at 19 V
17.5 W (Scanning)
0.6 W (Standby)
11.7 W (Idle)
VCCL, CB, CE, FCC, UL, ENERGY STAR, S mark, NOM-019-SCFI
imagePROGRAF TM-Series Service Guide
Scanner
64 LEDs
Up to 36"
Up to 109" (2,768 mm)
48.4 dB gray scan
L24ei Scanner
Up to 24"
Up to 6.2" (16 cm)
Up to 26" (660 mm)
June 2021
Page 42
