1.6 What You Will Need to Operate the Blender

All operator-detachable inlet pressure hoses supplied with the gas mixer comply
with ASTM/ISO 5359.
Pressurized Oxygen: The compressed oxygen source must provide clean, dry,
medical grade oxygen at the pressure specified in Section 8.0.
Pressurized Air: The compressed air source must provide clean, dry, medical
grade air at the pressure specified in Section 8.0.

2.0 OPERATING PROCEDURES

2.1 Setup and Installation

2.1.1 Battery Installation

All MAXBlend2 units are powered by four, AA, alkaline batteries (4 x 1.5 Volts)
and are shipped without the batteries installed. The battery compartment
is accessible from the back side of the unit. Batteries should be changed
by service personnel. Use only brand name batteries. Replace with four AA
batteries and insert per orientation marked inside the battery box.
To install the batteries:
Open the battery drawer by squeezing inward on both tabs as shown in figure
below. If you have difficulty squeezing the tabs in with your fingers, use two
flat screwdrivers or two coins. Remove the battery drawer completely from the
MaxBlend2. Install four new, AA, alkaline batteries in the unit, observing the
orientation shown on the plastic inside the drawer. Slide the drawer back in
with the batteries facing upward. Press in on the drawer until both tabs latch
into place.
! WARNING: Battery replacement by inadequately trained personnel could result in a
safety hazard.
WARNING: Electrical shock or damage to the equipment may occur if an
!
inappropriate external power supply is used. Maxtec recommends using only the
Maxtec MAXBlend2
6
External Power Supply - R230P10.
