1.4 Component Identification

< 18% Alarm Indicator - The <18% alarm indicator is located above the
1
Low Alarm Indicator digits. When the low alarm setting is set below <18%, the
indicator will flash each second to alert the operator of this special condition.
See section 2.3.1 for setting this low alarm condition.
Low Alarm LED - In a low alarm condition, the red "LOW ALARM" LED will
2
flash twice a second, accompanied by the audio buzzer.
High Alarm LED - In a high alarm condition, the red "HIGH ALARM" LED
3
will flash twice a second accompanied by the audio buzzer.
3 1/2-Digit Display - The 3 1/2 digit liquid crystal display (LCD) provides
4
direct readout of oxygen concentrations. The digits also display error codes,
alarm set modes and calibration codes as necessary.
% Symbol - The "%" sign is located to the right of the concentration number
5
and is present during normal operation.
Alarm Silence/Smart Alarm Indicator - When the Silent key is pressed the
6
indicator will display with cross bars
key is pressed the indicator will display with T-bars
AIR/O 2
%O
%O
50
2
2
40
30
21
23
866.4.Maxtec
2
3
70
80
90
100
26
to alert condition. When Smart Alarm
to alert condition.
www.maxtec.com
4
13
5
16
9
8
6
17
11
14
3
