Publication No. DI4825-1
08NOV06
Supersedes DI4825-1
10DEC05
DIAGRAMS
for the
Kodak DirectView CR 825/850 SYSTEMS
Service Codes: 5634, 4825
Important
Qualified service personnel must repair this equipment.
H177_0500AC
Confidential
Restricted Information
© EASTMAN KODAK COMPANY, 2006
HEALTH GROUP
Advertisement
Table of Contents
Related Manuals for Kodak DirectView CR 825
Summary of Contents for Kodak DirectView CR 825
- Page 1 {Diagrams}{Production}{Health Group}{ExternalAndInternal} Publication No. DI4825-1 08NOV06 Supersedes DI4825-1 10DEC05 DIAGRAMS for the Kodak DirectView CR 825/850 SYSTEMS Service Codes: 5634, 4825 Important Qualified service personnel must repair this equipment. H177_0500AC Confidential Restricted Information © EASTMAN KODAK COMPANY, 2006 HEALTH GROUP...
-
Page 2: Table Of Contents
Eastman Kodak Company reserves the right to change this information without notice, and makes no warranty, express or implied, with respect to this information. Kodak shall not be liable for any loss or damage, including consequential or special damages, resulting from any use of this information, even if loss or damage is caused by Kodak’s negligence or other fault. -
Page 3: Block
Block Section 1: Block System Connections BLUE CABLE KODAK CR850 BLOCK DIAGRAM LEFT CASSETTE MOTOR DRIVE MOTOR 10-08-02 Preliminary INTERLOCK SWITCH INTERNAL P5 J5 RED CABLE BARCODE RS232 RS232 READER BLUE CABLE RS232 MOTION SYSTEM JTAG PHOTO DETECTOR PROGRAM CONTROL BOARD... -
Page 4: Electrical
DIAGRAMS Section 2: Electrical System Overview 1 of 2 • For CR 850 SYSTEMS with serial number below 12400 • For CR 825 SYSTEMS with serial number below 1725 BLUE CABLE DC HARNESS WIRE COLOR KEY J1 P1 J1 P1 BROWN - LINE A/C LEFT CASSETTE DRIVE MOTOR... -
Page 5: System Overview 2 Of 2
System Overview 2 of 2 • For CR 850 SYSTEMS with serial number 12400 or higher • For CR 825 SYSTEMS with serial number 1725 or higher P1 J1 PHASE B1 KODAK DIRECTVIEW CR850M SYSTEM PHASE B1 SENSOR +5V SLOW HALL-B... -
Page 6: Erase Assembly
DIAGRAMS ERASE ASSEMBLY To P10 MSC Board ERASE-J1 ERASE-P1 ERASE ASSEMBLY CS1-A CS1-B CS2-A CS2-B CS3-A CS3-B CS4-A CS4-B CS5-A CS5-B BALLAST #1 BALLAST #2 BALLAST #3 BALLAST #4 BALLAST #5 SOCKET #1 SOCKET #2 SOCKET #3 SOCKET #4 SOCKET #5 SOCKET #1A SOCKET #2A SOCKET #3A... -
Page 7: Image Scan System
Electrical IMAGE SCAN SYSTEM -24VLSR -24VLSR GALVO -6VLSR BOARD LASER LASER_ACTIVE LASER_ACTIVE JTAG LASER LASER_ACTIVE LASER_POWER PROGRAM LASER_POWER DRIVE HEADER DIODE LASER_POWER BACK_FACET BACK_FACET PRE- +5VDC BACK_FACET DRIVER +5VDC REGULATOR +5VDC GND 10 CR500 CR850/950 +24V BLACK PD_B DRAIN PD_GND -24LSR PURPLE PD_A... -
Page 8: Motion System Control Board A1
DIAGRAMS MOTION SYSTEM CONTROL BOARD A1 INTERNAL J1 P1 BARCODE J1 P1 LEFT CASSETTE READER DRIVE MOTOR RS232 MOTOR To J5 MCPU Bd. To K1-5 SLED Power Supply Assy. HARNESS DISCONNECT To P2 Slow Scan NO CONNECTIONS Controller Bd. 4 3 2 1 12 11 10 9 8 7 6 5 4 3 2 1 6 5 4 3 2 1 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1... -
Page 9: Computer, Display And Bar Code Reader
Electrical COMPUTER, DISPLAY and BAR CODE READER To MCPU J1 P.C. KEYBOARD ORANGE MOUSE MOUSE CROSSOVER HANDHELD NETWORK B BARCODE KEYBOARD ON-BOARD PORT READER SOUND H OSPITAL NETWORK NETWORK A 100 BASE-T NIC CARD MONITOR TOUCH EXTERNAL SCREEN 2.4 GHz PC MODEM DISPLAY COMM 1... -
Page 10: Functional
DIAGRAMS Section 3: Functional Power Distribution To P3 MSC Bd. Erase Assembly To P10 MSC Bd. POWER SUPPLY ASSEMBLY MP4 POWER SUPPLY To PMT / DAS BD. V1 24V @ 8.5A RELAY V2/V3 12V @ 10A / 24V @ 2A To P5 MSC BD. - Page 11 Functional Publication History Publication Publication Changed Date ECO No. Pages File Name Notes 28MAR03 DI4825-1 - - - di4825_1.fm New Publication 09JAN04 DI4825-1 - - - di4825_1.fm Revised 10DEC05 DI4825-1 - - - 1 and 8 di4825_1.fm Revised 08NOV06 DI4825-1 - - - Page 5 di4825_1.fm...
