6. Identify the Left Handrail (86).
Attach the Left Handrail (86) to the Left Upright
(89) with two 5/16" x 2 1/2" Screws (28) and
two 5/16" Star Washers (11); firmly tighten the
Screws.
Insert the Upright Wire (81) through the hole in
the bottom of the Right Handrail (87) as shown.
Next, attach the Right Handrail (87) to the Right
Upright (90) with two 5/16" x 2 1/2" Screws (28)
and two 5/16" Star Washers (11); firmly tighten
the Screws.
Then, remove the wire tie (A) from the Upright
Wire (81).
7. If there are four screws (E) in the locations
shown, remove and discard them.
6
28
11
86
7
E
10
28
89
11
87
A
E
81
90
