IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE!
INSTRUCTION MANUAL FOR
USE OF CHILD RESTRAINT SYSTEM
„NEXT GEN"
This child restraint system
is manufactured in compliance
with the requirements of Regulation No 129 of the Economic Commission
for Europe of the United Nations (UN/ECE) — Uniform provisions concerning
the approval of enhanced Child Restraint Systems used on board of motor
vehicles (ECRS), the provisions of the Product safety Directive 2001/95/
EU of the European Parliament and The Council as well as the Consumer
Protection Law of Bulgarian Legislation.
Advertisement
Related Manuals for Chipolino NEXT GEN
Summary of Contents for Chipolino NEXT GEN
- Page 1 IMPORTANT! KEEP THIS MANUAL FOR FUTURE REFERENCE! INSTRUCTION MANUAL FOR USE OF CHILD RESTRAINT SYSTEM „NEXT GEN” This child restraint system is manufactured in compliance with the requirements of Regulation No 129 of the Economic Commission for Europe of the United Nations (UN/ECE) — Uniform provisions concerning...
- Page 2 Car seat “NEXT GEN” is suitable for children with height 40-150 cm, age 0-12 years. Height of Position of Approximate Installation method Category the child the car seat age of the child of the car seat REARWARD 40-105 cm 0-15 months...
- Page 3 NEVER INSTALL THE CAR SEAT IN VEHICLE WITH 2-POINT BELT! INSTALL IT ONLY IN VEHICLE WITH 3-POINT SAFETY BELT! CAUTION! This car seat is only suitable for installation in vehicles fitted with APPROVED 3-POINT SAFETY BELTS WITH RETRACTOR, meeting the requirements of Regulation no. 16 of EC of UN! PLACES FOR INSTALATTION OF THE CAR SEAT IN THE VEHICLE The rear seats are the most safety places in the vehicle for children under 12 years old.
- Page 4 CHOOSING OF APPROPRIATE WAY FOR INSTALLATION OF THE CAR SEAT (ACCORDING TO THE HEIGHT OF THE CHILD) Size approx from birth to 15 months rearward Size approx from 15 months to 4 years forward Size booster seat approx from 3 to 12 years old forward Size booster seat...
- Page 5 CAUTION! WARNINGS! CAUTION! NEVER LEAVE YOUR CHILD UNATTENDED! CAUTION! DO NOT USE ANCHOR POINTS OTHER THAN THE ONES DESCRIBED IN THIS MANUAL AND MARKED ON THE RESTRAINT SYSTEM! CAUTION! WHEN YOU INSTALL THE CAR SEAT IN POSITION „REARWARD FACING“, NEVER PLACE IT ON PASSENGER SEAT, EQUIPPED WITH ACTIVE AIRBAG! THIS MAY LEAD TO SE RIOUS INJURY OR DEATH! ...
-
Page 6: Product Features
Do not attach objects with long cords or strings on the car seat in order to avoid danger of suffocation! Never place the car seat on beds, couches or similar soft surfaces! Do not allow children to play with the product! ... - Page 7 INSTALLATION OF THE CAR SEAT WITH ISOFIX AND TOP TETHER click press shake 1. Press the ISOFIX connectors release button and set them maximum out. 2. Insert ISOFIX attachment of car seat to ISOFIX anchor point of the vehicle and push the seat until you hear click sound and it get fixed.
- Page 8 DIRECTION OF THE TOP TETHER SHORTENING THE LENTGH IN “REAR FACING” CAR SEAT OF THE TOP TETHER STRAP Some top tether anchor points are very close to the child seat (place A), you have to shorten the top belt strap,on which the hook is mounted. ATTENTION! Please use the longer upper fixing belt...
- Page 9 INSTALLATION FOR CATEGORY i-Size Universal ISOFIX 40-105 cm, “REARWARD” facing car seat For children from birth to about 4 years ISOFIX + Top Tether + 5-point harness of the car seat 1. Place the car seat in position “REARWARD” facing and adjust it to „R“ reclining position. 2.
- Page 10 5-POINT HARNESS OF THE CAR SEAT CATEGORY i-SIZE Universal ISOFIX Button for adjusting the shoulder belts click 1. Press the release button on the shoulder belts with one hand and pull them out with the other. 2. Unfasten the belt from the buckle and place the child in the seat. 3.
- Page 11 INSTALLATION FOR CATEGORY i-SIZE BOOSTER SEAT 100-150 cm, “FORWARD” facing car seat For children from 3 to about 12 years ISOFIX + 3-point safety belt of the vehicle Only with 3-point safety belt of the vehicle click Loose safety belt can not guarantee the protection function of the car seat. CAUTION! Make sure the belt is not twisted and the child pelvis is firmly engaged without pressing! 1.
- Page 12 RELEASE OF ISOFIX AND TOP TETHER ISOFIX button adjusting hook mechanism press place for attachment 1. Push the seat back with your hand or leg. 2. Press the ISOFIX release button, pull it back and release ISOFIX connectors. 3. Loosen the top tether belt from the adjusting mechanism. 4.
- Page 13 TIGHTENING /LOOSENING OF 5-POINT HARNESS OF THE CAR SEAT button for adjusting the belts 1. Press the button for adjusting the belts. 2. Loosening: Press the button for adjustment with one hand and with the other pull the shoulder belts. Loosening Tightening 3.
- Page 14 REMOVAL OF 5-POINT HARNESS OF THE CAR SEAT 1. Press the belt adjustment button and at the same time pull the shoulder belts out. 2. Remove the seat belts from the connector on the back of the seat. 3. Pull the shoulder belts out of the soft pads (the pads are sewn to the belts). 4.
- Page 15 ROTATION /CHANGE OF THE CAR SEAT DIRECTION This seat can rotate 360°. It can be fixed in two positions – in direction FORWARD facing and in direction REARWARD facing . CAUTION! ALWAYS CHECK THAT THE SEAT IS FIXED IN THE SELECTED POSITION BEFORE DRIVING! DO NOT USE THE SEAT IF IT IS NOT FIXED! ‘’REARWARD“...
- Page 16 REMOVAL AND PLACING THE SEAT COVER 1. Unfasten the buckle. 2.Remove the 5-point harness from the seat (See section “REMOVING THE 5-POINT HARNESS”). 3. Remove the headrest cover. 4. Unbutton the seat cover on both sides of the seat and remove it. To put the seat cover on the seat, perform the steps described in reverse order .
-
Page 17: Care And Maintenance
CARE AND MAINTENANCE Clean the plastic or metal parts with damp cotton cloth or sponge and mild soap. Upholstery and soft pads may be hand washed at 30 С using mild detergent! Do not bleach! Do not tumble dry! Do not machine wash! Do not iron! ... - Page 18 Bulgaria, Plovdiv, Golyamokonarsko shosse Str. № 1 www.chipolino.com...
