IMPORTANT! KEEP THIS MANUAL FOR REFERENCE
DURING THE WHOLE TIME OF USE!
INSTRUCTION MANUAL
FOR USE OF CAR SEAT "ELITE"
This child restraint
is designed and manufactured in
compliance with the requirements of Regulation 44 of the United Nations
Economic Commission for Europe concerning the safe transportation of
children, the provisions of the product safety directive 2001/95/EU of the
European Parliament and The Council and Directive 91/671/EEC "Compulsory
use of seat belts and child restraints systems for child occupants of power
driven vehicles" of the European Parliament and The Council, as well as the
Consumer Protection law and the national legislation.
Advertisement
Table of Contents
Related Manuals for Chipolino ELITE
Summary of Contents for Chipolino ELITE
- Page 1 IMPORTANT! KEEP THIS MANUAL FOR REFERENCE DURING THE WHOLE TIME OF USE! INSTRUCTION MANUAL FOR USE OF CAR SEAT “ELITE” This child restraint is designed and manufactured in compliance with the requirements of Regulation 44 of the United Nations Economic Commission for Europe concerning the safe transportation of children, the provisions of the product safety directive 2001/95/EU of the European Parliament and The Council and Directive 91/671/EEC “Compulsory...
- Page 2 Б Е Л Е Ж К А ЗА ГРУПА 0+ (0-13kg) 1. Това е „УНИВЕРСАЛНА” ИНТЕГРАЛНА СИСТЕМА ЗА ОБЕЗОПАСЯВАНЕ НА ДЕЦА. Тя е одобрена, съгласно Правило № 44, за обща употреба в превозни средства и е пригодима към повечето, но не всички, седалки за леки автомобили. 2. Може да се очаква, че по отношение на монтирането, системата ще съответства, ако производителят е заявил в инструкцията за експлоатация на превозното средство, че то е пригодено за монтиране на „универсална” система за обезопасяване на деца от тази...
- Page 3 Do not install the child car seat on seat facing aside or backwards. Seat at back Correct Front seat without air bag Correct Middle seat at back equipped with Correct 3-point belt Seat facing Incorrect backwards Seat facing aside Incorrect NEVER LEAVE THE CHILD IN THE CAR SEAT UNATTENDED! DO NOT INSTALL THE CAR SEAT IN A WAY DIFFERENT FROM THE ONE SHOWN IN THE INSTRUCTION. IT IS DANGEROUS TO USE BEARING CONTACT POINTS OTHER THAN THOSE DESCRIBED IN THIS MANUAL AND MARKED ON THE CAR SEAT! IT IS VERY IMPORTANT THAT THE LAP BELT IS LAYING LOW AND THE CHILD’S HIPS ARE...
- Page 4 Do not place additional pads in the car seat than those provided by the manufacturer! Do not use spare parts and other components not supplied by the manufacturer! The manufacturer takes no responsibility for safety in case spare parts are used other than the original. Do not expose this car seat to direct sunlight to avoid injuries of the child, deformation of the car seat and especially of the plastic parts. The car seat does not replace a carrycot or a bed. Should your child need to sleep, then he should be placed in a suitable cot or bed. Strings can cause strangulation! Do not place additional strings to the product to avoid injuries or strangulation! Do not place the car seat on soft surface like beds or sofas! The car seat may tip over and injure or suffocate your child! Do not allow children play with this product! The packaging of the product must be kept out of the reach of children to avoid the risk of strangulation! MAIN FEATURES Suitable for babies aged 0+ months and weighing not more than 13 kg;...
- Page 5 1 – ADJUSTING THE HEIGHT OF THE SHOULDER BELTS The shoulder belts must be at the child’s shoulder level in 2 positions. ATTENTION! Before removing the safety belts from the slots, you have to loosen them (see article 2-2 (5)! IMPORTANT! Shoulder belts must be at the child’s shoulders level (see figure)! Take the shoulder belt out of the slot and thread it through the required slot. If the height is not appro- priate, adjust again. Note: Make sure that shoulder belts are threaded through the same height slots! 2 – SECURING THE CHILD IN THE CAR SEAT 2-1 – Unfastening of safety belt. Press the central buckle button and split the shoulder belts. 2-2 – Lock the safety belt. 2-2 (3) - Make sure the safety belt is fastened by pulling the shoulder straps up. ATTENTION! Shoulder belts must snug well the child and lab belt must lay low so the child’s hips are snug! 2-2 (4) - Tightening the safety belt. ATTENTION! Maximum distance between shoulder belts and child’s body must be around 1.5-2 cm. 2-2 (5) Loosing the safety belt. 3 – INSTALLATION OF THE CAR SEAT INTO THE VEHICLE 3-1 – Place the child car seat on vehicle seat.
- Page 6 press press click 2 - pull 1 - press pull Lap belt Diagonal belt click Tighten Diagonal Lap belt belt WARNING! MAKE SURE THAT BELTS AND BUCKLE OF VEHICLE ARE NOT TWISTED AND ARE IN CORRECT POSITION!
- Page 7 “click” “click” “click” Adjustment button unfolding Canopy bar folding Canopy attachment CARE AND MAINTENANCE Clean the fabrics, plastic parts and metal parts with damp cotton cloth or sponge and mild soap. Fabric seat cover may be hand washed at 300С! Do not bleach! Do not dry clean! Do not tumble dry! Do not iron! Do not use abrasive, bleach or other aggressive detergents. Always after cleaning leave the car seat fully dry and after that use it or store it. If you keep it moist, mold may appear to your car seat. Harnesses must be cleaned with damp cloth and mild soap! Do not wet or remove the stickers. They contain important information! Always store your car seat indoors – on dry and clean place. Do not expose to direct environment influence - sun, rain, moisture and high temperature intervals. Please, contact your authorized dealer for problems connected with the use or repair of this car seat. Fabric content: Shell: 100% polyester Filling: 100% polyester Materials used: plastic, textle, metal STKET021xxxx...
- Page 8 Bulgaria, Plovdiv, str. Golyamokonarskoshosse 1 www.chipolino.com...
