- Page 1 TAE 1044 Build-in Touch Terminal Operating Manual | Date of creation: 03.06.2020 | Version date: 11.11.2020 | Article number: 12-200-1044-E...
- Page 2 (print, photocopy, microfilm or in any other process) without express permission. We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for technical or printing errors in this handbook and assumes no responsibility for damages that occur through its use.
-
Page 3: Tae 1044
Build-in Touch Terminal TAE 1044 The multi-touch operating panel TAE 1044 is used to visualize automated processes. The operation and monitoring of automated procedures are simplified using this display unit. The projective capacitive touch screen is used to enter process data and parameters. The output is shown on a 10.1“... -
Page 4: Table Of Contents
TAE 1044 BUILD-IN TOUCH TERMINAL Table of Contents TAE 1044..............1 Build-in Touch Terminal .........1 Table of Contents ...........2 Introduction .............6 Target Group/Purpose of this Operating Manual ...6 Important Reference Documentation .....6 Contents of Delivery ..........6 Basic Safety Guidelines .........7 Symbols Used ............7 Disclaimer ..............8... - Page 5 BUILD-IN TOUCH TERMINAL TAE 1044 Minimum Distance between Operating Elements for Multi-touch Applications ............15 Environmental Conditions ........16 Miscellaneous ............. 17 Interfaces .............. 18 Front Connectors ..........18 X1: Supply (4-pin Phoenix RM 3.5) ....18 X2: HMI Remote-IN (HMI-Link G2.1, Industrial Mini I/O) 19 X3: Service ............
- Page 6 TAE 1044 BUILD-IN TOUCH TERMINAL Wiring ..............30 Grounding ............30 Shielding .............. 30 ESD Protection ............ 31 USB Interface ............31 Transport/Storage ..........32 Storage ..............33 Maintenance ............34 Cleaning and Disinfecting the Touch Screen ..34 Service ..............35 Calibrating the Touch Screen ......
- Page 7 BUILD-IN TOUCH TERMINAL TAE 1044 11.11.2020 Page 5...
-
Page 8: Introduction
General knowledge of automation technology is required. Further help and training information, as well as the appropriate accessories can be found on our website www.sigmatek-automation.com. Our support team is happily available to answer your questions. Please see our website for our hotline number and business hours. -
Page 9: Basic Safety Guidelines
BUILD-IN TOUCH TERMINAL TAE 1044 Basic Safety Guidelines Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes. DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken. -
Page 10: Disclaimer
Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations. Page 8... -
Page 11: General Safety Guidelines
2006/42/EG guidelines is correct. As long as the machine with which the product should be used does not comply with the guideline, operating this product is prohibited. Operate the unit with devices and accessories approved by SIGMATEK only. CAUTION Handle the device with care and do not drop or let fall. - Page 12 TAE 1044 BUILD-IN TOUCH TERMINAL The control cabinet must be connected to ground correctly. To perform maintenance or repairs, disconnect the system from the power supply. Le module est conforme à la norme EN 61131-2. En combinaison avec une machine, le constructeur de la machine doit respecter la norme EN 60204-1.
-
Page 13: Standards And Guidelines
The product was constructed in compliance with the following European Union guidelines and tested for conformity. EU Conformity Declaration EU Declaration of Conformity The product TAE 1044 conforms to the following European guidelines: • 2014/35/EU Low-voltage Guideline • 2014/30/EU Electromagnetic Compatibility (EMC Guideline) 2011/65/EU “Restricted use of certain hazardous substances in... -
Page 14: Technical Data
Performance Data Interfaces 1x HMI Remote IN (HMI-Link G2.1) 2x USB 2.0 Type A OUT 1x Panel Interface Connector (for connecting a SIGMATEK TP) Internal interfaces USB 2.0 (for touch and front USB, if available on the TP) (via Panel Interface... -
Page 15: Display
BUILD-IN TOUCH TERMINAL TAE 1044 Display Type 10.1” IPS color display Resolution WXGA 1280 x 800 pixels Color depth 18-bit RGB LCD mode normally black LCD Polarizer transmissive Pixel size 0.1695 x 0.1695 mm Active range 216.96 x 135.60 mm... -
Page 16: Control Unit
TAE 1044 BUILD-IN TOUCH TERMINAL Control Unit Touch panel projective capacitive touch panel Cleaning see chapter: FEHLERHAFTER QUERVERWEIS Cleaning and Disinfecting the Touch Screen INFORMATION A projective capacitive touch screen is built into the panel, with which 10- finger input, zoom and gesture functions can be implemented. Data can be input using fingers, a project capacitive touch pen as well as with thin gloves. -
Page 17: Minimum Distance Between Operating Elements For Multi-Touch Applications
BUILD-IN TOUCH TERMINAL TAE 1044 Minimum Distance between Operating Elements for Multi-touch Applications To guarantee smooth operation with multi-touch applications, buttons and control elements that should be operated at the same time must have the minimum clearance shown below (depending on the estimated touch point). -
Page 18: Environmental Conditions
TAE 1044 BUILD-IN TOUCH TERMINAL Environmental Conditions Storage temperature -25 ... +85 °C Environmental temperature 0 ... +50 °C Humidity 10-95 %, non-condensing Installation altitude above 0-2000 m without derating sea level > 2000 m up to a maximum of 5000 m with derating of the maximum environmental temperature by 0.5 °C per 100 m... -
Page 19: Miscellaneous
BUILD-IN TOUCH TERMINAL TAE 1044 Miscellaneous Article number 12-200-1044 Hardware version Operating system Standard designed according to UL Approvals CAUTION If the modular components (e.g. TP and PIM) are not bolted together,they are NOT ESD-protected and can only be unpacked and handled in an ESD-safe environment by trained personnel. -
Page 20: Interfaces
TAE 1044 BUILD-IN TOUCH TERMINAL Interfaces Front Connectors X1: Supply (4-pin Phoenix RM 3.5) Function +24 V DC +24 V DC Page 18 11.11.2020... -
Page 21: X2: Hmi Remote-In (Hmi-Link G2.1, Industrial Mini I/O)
= do not use INFORMATION For service purposed only! • For the service interface, only a separate cable that can be ordered from SIGMATEK may be used. Using a different cable can lead to malfunction and damage. 11.11.2020 Page 19... -
Page 22: X4, X5: Usb 2.0 (Type A)
TAE 1044 BUILD-IN TOUCH TERMINAL X4, X5: USB 2.0 (Type A) Function +5 V, I = 500 mA out,max INFORMATION It should be noted that many of the USB devices on the market do not comply with USB specifications; this can lead to device malfunctions. This may cause the device to malfunction. -
Page 23: Applicable Connectors
8-pin Industrial Tyco Mini I/O (not included in delivery) For the service interface, only a separate cable that can be ordered from SIGMATEK may be used. Using a different cable can lead to malfunction and damage. USB 4-pin, Type A (downstream connector) (not included with delivery) -
Page 24: Status Display Leds
TAE 1044 BUILD-IN TOUCH TERMINAL Status Display LEDs LED Color Definition green DC OK 2 (OS Error dependent) The status LEDs of a PIM with EDGE2, for example, can be controlled via the application. With standard settings within an application or after starting the PIM’s operating system, the... -
Page 25: Mechanical Dimensions
BUILD-IN TOUCH TERMINAL TAE 1044 Mechanical Dimensions 11.11.2020 Page 23... - Page 26 TAE 1044 BUILD-IN TOUCH TERMINAL Dimensions 264 x 183 x 48 mm (W x H x D) Material front plate: 1.1 mm glass (touch screen) in black anodized aluminum frame Weight 1.5 kg Page 24 11.11.2020...
- Page 27 BUILD-IN TOUCH TERMINAL TAE 1044 INFORMATION Due to the aluminum front, caution must be taken to ensure that it is not damaged during mounting via strong impacts on the edges or corners! 11.11.2020 Page 25...
-
Page 28: Assembly/Installation
TAE 1044 BUILD-IN TOUCH TERMINAL Assembly/Installation Check Contents of Delivery Ensure that the contents of the delivery are complete and intact. See chapter FEHLERHAFTER QUERVERWEIS Contents of Delivery. INFORM ATION On receipt and before initial use, check the device for damage. If the device is damaged, contact our customer service and do not install the device in your system. -
Page 29: Restricted Space Around Rear Trimming
BUILD-IN TOUCH TERMINAL TAE 1044 Restricted Space Around Rear Trimming Symbol Image 15“ A restricted area of 15 mm around the terminal must be ensured. This is required to exchange the module without removing the TP, tightening the screw terminals and ensuring cooling of the TP. -
Page 30: Required Cutout For Mounting The Terminal
TAE 1044 BUILD-IN TOUCH TERMINAL Required Cutout for Mounting the Terminal Control cabinet cutout width X 255 mm Control cabinet cutout height Y 174 mm Maximum thickness of control cabinet 2 mm wall Z Page 28 11.11.2020... -
Page 31: Mounting Position
BUILD-IN TOUCH TERMINAL TAE 1044 Mounting Position Observe the mounting position of 60-120°. INFORMATION The specified installation distances may be reduced if appropriate measures and technical precautions are taken to dissipate the corresponding waste heat. 11.11.2020 Page 29... -
Page 32: Wiring
Wiring Grounding The TAE 1044 is grounded via the TP. The device must be grounded to protective earth (PE) via the blade terminal provided. In addition, ensure that when installing into the control cabinet, a large grounding surface is provided. It is important to establish a low-Ohm connection to ground to ensure error-free function. -
Page 33: Esd Protection
BUILD-IN TOUCH TERMINAL TAE 1044 ESD Protection CAUTION Typically, USB devices (keyboard, mouse, etc.) are equipped with non- shielded cables. These devices are disrupted by ESD and in some instances, no longer function. Before any device is connected or disconnected, the potential should be equalized (by touching the control cabinet or ground terminal). -
Page 34: Transport/Storage
TAE 1044 BUILD-IN TOUCH TERMINAL Transport/Storage INFORMATION This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport. -
Page 35: Storage
BUILD-IN TOUCH TERMINAL TAE 1044 Storage INFORM ATION When not in use, store the device according to the storage conditions. See chapter FEHLERHAFTER QUERVERWEIS Transport/Storage. During storage, ensure that all protective covers are placed correctly, so that no contamination, foreign bodies or fluids enter the device. -
Page 36: Maintenance
TAE 1044 BUILD-IN TOUCH TERMINAL Maintenance INFORM ATION During maintenance as well as servicing, observe the safety instructions from chapter FEHLERHAFTER QUERVERWEIS Basic Safety Guidelines. Lors de l'entretien et de la maintenance, respectez les consignes de sécurité du chapitre FEHLERHAFTER QUERVERWEIS Basic Safety Guidelines. -
Page 37: Service
BUILD-IN TOUCH TERMINAL TAE 1044 INFORMATION To ensure the optimal function of the device, the touch screen should be cleaned at regular intervals! Service This product was constructed for low-maintenance operation. Calibrating the Touch Screen The touch screen is calibrated at the factory. You should therefore only recalibrate the touch screen when press-point changes are noticed. -
Page 38: Repair
TAE 1044 BUILD-IN TOUCH TERMINAL Repair INFORMATION When sent for repair, the device should be transported in the original packaging if possible. Otherwise, packaging should be selected that sufficiently protects the product from external mechanical influences. Such as cardboard filled with air cushioning. -
Page 39: Modularity
BUILD-IN TOUCH TERMINAL TAE 1044 Modularity INFORMATION The device is not Hot-Plug capable and can be damaged when the supply is not disconnected before inserting or removing the PIM. Always disconnect the supply before inserting or removing. • Removing the PIM from the Touch Panel CAUTION This product is a sensitive electronic device. -
Page 40: Mounting The Pim Onto The Touch Panel
TAE 1044 BUILD-IN TOUCH TERMINAL Mounting the PIM onto the Touch Panel To mount the PIM on a TP, follow the steps below: Ensure that an ESD-compliant working method is followed (ESD armband, ESD clothing). Disconnect the device from the supply. -
Page 41: Display „Burn-In" Effect
BUILD-IN TOUCH TERMINAL TAE 1044 Display „Burn-In“ Effect The “Burn-In” effect describes a pattern burned into the display after displaying the same contents over a longer period of time (e.g. a single screen). This effect is also described mostly as “image sticking”, “memory effect/sticking” or “ghost image”. -
Page 42: Disposal
TAE 1044 BUILD-IN TOUCH TERMINAL Disposal INFORMATION Should you need to dispose of the device, the national electronic scrap regulation must be observed. The device appliance must not be disposed of as household waste. Page 40 11.11.2020... -
Page 43: Accessories
BUILD-IN TOUCH TERMINAL TAE 1044 Accessories Touch Pen Description Order number Touch pen with holder V3 01-690-059-3 11.11.2020 Page 41... -
Page 44: Changes Chart
TAE 1044 BUILD-IN TOUCH TERMINAL Changes Chart Change Affected Chapter Note date page(s) 30.07.2020 FEHLERHAFTER QUERVERWEIS Notes on disinfection added Cleaning and Disinfecting the Touch Screen 20.08.2020 FEHLERHAFTER QUERVERWEIS Chapter added Position Series Label Sub Device 31.08.2020 Introduction Text corrected FEHLERHAFTER QUERVERWEIS X9 =>...
