Set the SENSITIVITY by using the
(5)
and keys.
(6) Press S-key.
Press S-key for 2 seconds or more, then go out from detail setting mode.
(7)
(Select the menu with
(8) Activate the key lock if necessary (see page 9).
Relation between setting and sensitivity
Sensitivity Sharp
Setting of
sensitivity
*Default:
Zero clear
This function is the same as the function via IO-Link.
The display can be set to zero again by executing "zero clear".
When "zero clear" is executed with residual pressure in the secondary piping, the pressure is
assumed to be zero. Please execute the operation of "zero clear" with the supply pressure is
intercepted, and the piping of the second side removed.
No
(1) Deactivate the key lock if necessary (see page 9).
(2) Press S-key for 2 seconds or more, then go to detail setting mode.
(3) To "F03" by using the
(4) Press S-key.
Press and
(5)
(press S-key to (3))
"Zero clear" is executed, after 3 seconds.
(6)
(Release keys till less than 3 seconds to (4))
Returns to the state immediately after turning on of the power supply.
(7)
Activate the key lock if necessary (see page 9).
(note) The adjustable range is within ±5%F.S from the state of the factory shipment. When more
than this range,
or keys, then jump to another item.)
Key operation
and keys.
keys for 3 seconds or more.
is displayed and zero-clear is not executed.
(blink and change the rightest digit)
(displayed alternately)
second.
