Residual
pressure
error
Detail setting mode
No
(1) Deactivate the key lock if necessary (see page 9).
(2) Press S-key for 2 seconds or more.
key
key
key
(3)
key
(4) In state of 3, press S-key for 2seconds or more.
(5) Return to (current) pressure display.
(6) Activate the key lock if necessary (see page 9).
Out of range error of zero clear
Key operation and LED display
(displayed alternately)
Press S-key
key To "GAIN" (refer to P13)
(displayed alternately)
key Press S-key
key To "SENSITIVITY" (refer to P13)
(displayed alternately)
Press S-key
key To "ZERO CLEAR" (refer to P14)
(displayed alternately)
Press S-key
To "INITIALIZE" (refer to P15
- 12 -
Please operate "zero clear"
within the range of 5%F.S..
Please operate "zero clear" after
the secondary pressure of ITV is
became to atmosphere.
