Summary of Contents for HOMCOM A90-282V70
- Page 1 INan014_UK A90-282V70 TREADMILL USER’S MANUAL * Maximum user weight is 100 kg. CAUTION Read all precautions and instructions in this manual before using this equipment. ASSEMBLY & INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
CONTENTS I. IMPORTANT PRECAUTIONS II. MAIN TECHNICAL FEATURES III. ASSEMBLY IV. WORKOUT GUIDELINES V. TREADMILL OPERATION VI. MAINTENANCE VII. RECYCLING INFORM VIIl. COMMON ERRORS... -
Page 3: Important Precautions
I.IMPORTANT PRECAUTIONS MINIMUN 140 cm 100 kg. USER USER WEIGHT HEIGHT The security key has a magnet which must be put in the display. At the end of the lace there is a clamp which should be attached to the clothes.The treadmill will start working only if the key is placed in the display.THIS IS ESSENTIAL. - Page 4 5-Place the unit on a flat surface. If the surface is uneven, the proper functioning could be affected. Some models include levellers or levelling threads behind the legs, helping the levelling. Please read the manual to verify if your unit is provided with one of them.. 6-The unit must be placed in a ventilated area.
- Page 5 19-A correct lubrication of the treadmill with silicon oil or Teflon is REALLY IMPORT- ANT. This lubrication must be performed regularly depending on each person, even before its first use. The lubrication must be carried out this way: disconnect the equipment of the electricity supply (in case you have one), pull up the tapestry from the side with one hand and spread the oil on the board.
-
Page 6: Main Technical Features
II.MAIN TECHNICAL FEATURES Pad holder LED screen Cup Holder Motor cover Running belt End cap Side Rail Input Voltage 220V±10% Frequency 50/60 Hz Running area 1220X460mm Time, Speed, distance, Calorie, heart rate, Function USB input(charging only) Speed Range 1.0-15km/h Incline No incline Max user weight 100kgs... -
Page 7: Assembly
III.ASSEMBLY NOTICE: ASSEMBLY REQUIRES TWO PERSONS Name Q'ty Main part 1.Main frame 1set Fittings Qnty Fittings Qnty M8 Knob Multi ⑦ Wrench 6mm Wrench ⑧ Knob M6*15 Silicone oil ⑨ ST4.2*16 Safety Key ④ ⑩ Cup Holder User’s ○... - Page 8 STEP 2 1.Put the console at right place as below picture shows, and lock it with 2pcs M8 knob screws at two sides. STEP 3 1.use 6mm wrench to fix the Ipad holder with the 2pcs M6x15 in the position shown in the figure.
- Page 9 STEP 4 When you not use treadmill, just unlock the 4pcs knob screws, fall down upright tube,lay flat as below picture shows, and lock again 2pcs M10 knob screws at two sides. STEP 5 1.Fold up the treadmill, turn around the supporting frame locker to horizontal place, the supporting frame will extend automatically.
-
Page 10: Workout Guidelines
IV.WORKOUT GUIDELINES BEWARE: Before starting to use this or any exercise programs, consult your doctor. This is especially important for people older than 35 years old, or for people with health prob- lems. If your equipment is provided with a pulse sensor, you must keep in mind this isn’t a medi- cal instrument. -
Page 11: Treadmill Operation
V.TREADMILL OPERATION COMPUTER MANUAL... -
Page 12: Vi. Maintenance
VI. MAINTENANCE This product must be earthed. If the power cord is damaged, it must be replaced with a manu- facturer recommended power cord. DO NOT TANGLE THE POWER CORD REGULAR MAINTENANCE OF THE TREADMILL • STORAGE: Keep your equipment in a enclosed place, away from dust or humidity. Don’t store it neither in a garage or in a indoor backyard, or near the water. - Page 13 After the lubrication is completed, start the machine at 1km/h to let the running belt bring silicon all over the board. After running for a period of time, the treadmill must be configured with special cymene silicone oil for lubrication. Suggestion: <...
- Page 14 • TIGHTEN THE BELT: (if the belt slips on the treadmill when walk- ing). Start treadmill and increase the speed to 3MPH.Using the 6 mm Wrench, turn both bolts 1/4 clockwise. If the belt is properly tight to walk, you must be able to pull up each side of the belt 5 or 7 cm off the platform.
-
Page 15: Recycling Inform
VII.RECYCLING INFORMATION This electronic product must not be disposed of in municipal waste. To preserve the envi- ronment, this product must be recycled after its useful life as required by law. VIII. COMMON ERRORS: ERRO CODE REASON HOW TO SOLVE A) signal wire not well connected Re-connect signal wire B) signal wire broken...
