- Page 1 INSTALLATION MANUAL Purita™ Single Handle Water Filtration Faucet FF-100 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing L LC I Rev. March 20, 2023...
- Page 2 Congratulations on the purchase of your new Kraus plumbing fixture! Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance or have any problems with your product: DO NOT RETURN TO STORE...
-
Page 3: Prior To Installation
Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·... - Page 4 Diagram and Parts List A. Faucet Assembly B. Flange C. Rubber Washer D. Metal Washer E. Mounting Nut F. Connector G. Hex Wrench...
-
Page 5: Faucet Dimensions
Faucet Dimensions 7 1/8” 2 3/4“ [181.5mm] [69.5mm] 6” [153.0mm] Ø1 3/4" [Ø45.0mm] 7/16-24UNS-2A Installer Tip: Shut off main water supply before installing new faucet. -
Page 6: Step 1: Preparing For Installation
Step 1: Preparing for installation Remove the rubber washer (C), metal washer (D), and mounting nut (E) from the end of the stud. Step 2: Installing the faucet assembly Place the faucet assembly (A) through the selected hole in the sink or countertop. On the underside of the sink or countertop, slide the rubber washer (C) and metal washer (D) onto the stud. - Page 7 Step 3: Connecting the quick connect adaptor and water line Thread the quick connect adaptor (F) onto the end of the faucet assembly (A) stud, and tighten securely using a wrench. Connect the 3/8 in. water line from the filtration system by pushing the line into the connector (F).
-
Page 8: Replacement Parts
Replacement Parts Replacement Parts List Finish / Color Part # 1. O-ring KP27168 CH, SFS, MB, BG, 2. Spout Nut KP27169 BB, SFACB, SFSB* 3. Locking Ring KP27170 4. O-ring KP27171 5. Cartridge KP27172 CH, SFS, MB, BG, 6. Handle KP27173 BB, SFACB, SFSB* 7. -
Page 9: Troubleshooting
Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: PROBLEM CAUSE ACTION Leakage under the handle Cartridge (5) has come Remove index (7) and loosen set screw with loose hex wrench (13). - Page 10 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
- Page 11 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at: Kraus USA Plumbing, LLC 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 12 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
