  • Page 1 REGO Inverter Charger 3000W VERSION A0 USER MANUAL...
  • Page 2 REGO 12V 3000W Inverter Charger (RIV1230RCL-1SS-G1) Disclaimer z Renogy makes no warranty as to the accuracy, sufficiency, or suitability of information in the user manual because continuous product improvements are going to be made. z Renogy assumes no responsibility or liability for losses or damages, whether direct, indirect, consequential, or incidental, which might arise out of the use of information in the user manual.

  • Page 3: Table Of Contents

    Table of Contents Important Safety Information .......................06 Symbols Used .........................06 General Safety Information .....................06 Introduction ..........................08 General Information ........................08 Key Features ...........................08 Package Contents ........................10 Optional Accessories ........................11 Product Overview ........................12 External View ..........................12 Internal View ..........................13 Wiring Diagram ..........................14 Recommended Cable Sizing .......................15 Components &...
  • Page 4 Temperature Sensor Wiring ......................28 Battery Wiring ..........................30 Device-side Wiring ........................30 Battery-side Wiring ........................32 AC Output Wiring.........................38 Device-side Wiring ........................38 Load Wiring ..........................39 AC Input Wiring ...........................41 Automatic Generator Start ......................43 Communication..........................47 Inter-Device Communication ....................47 Monitoring Device Communication ..................52 Putting Plates Back ........................57 Power on .............................58 Main Switch ..........................58 Wired Remote Control ......................59...
  • Page 5 Wired Remote Control ......................78 Overcurrent Protection ........................80 LED Indicators ..........................81 Indicator of the Inverter Charger ....................81 Indicator of the Wired Remote Control ..................81 Program Codes ...........................82 Warning/Fault Codes ........................91 Technical Specifications ......................93 Dimensions ..........................95 Maintenance ..........................96 Inspection ..........................96 Cleaning ..........................96 Storage ............................96 Emergency Responses .......................97 Fire ............................97...

  • Page 6: Important Safety Information

    Important Safety Information The user manual provides important installation, operation, and maintenance instructions for REGO 12V 3000W Inverter Charger (hereinafter referred to as inverter charger). Read the user manual carefully before installation and operation and save it for future reference. Failure to observe the instructions or precautions in the user manual can result in electrical shock, serious injury, or death, or can damage the inverter charger, potentially rendering it inoperable.
  • Page 7 Important Safety Information Symbols Used General Safety Information z Disconnect all connectors from the inverter charger before maintenance or cleaning. z Risk of electric shock! Be careful when touching bare terminals of the inverter charger as they may retain high lethal voltages even after power is removed. z Do not dispose of the inverter charger as household waste.

  • Page 8: Introduction

    Introduction General Information REGO 12V 3000W Inverter Charger is your off-grid smart living center that revolutionizes comfort when you live in your off-grid home or RV. The inverter charger can invert DC to AC and directly supply power to the load, and charge the battery when it is connected to the utility power.
  • Page 9 Introduction General Information Key Features z Peak conversion efficiency >90% The peak conversion efficiency is more than 90% during operation, which reduces the energy loss. z Multiple electronic protections The inverter charger is equiped with undervoltage protection, overvoltage protection, overload protection, overtemperature protection, and short circuit protection.

  • Page 10: Package Contents

    Package Contents Package Contents REGO 12V 3000W Inverter Charger × 1 Quick Guide × 1 REGO Inverter Charger 3000W VERSION A0 QUICK GUIDE Battery Temperature Sensor x 1 Wired Remote Control x 1 RMS-P2 RJ11 Network Cable (5 m) x 1...

  • Page 11: Optional Accessories

    Optional Accessories Optional Accessories NOTE z You can buy optional accessories from renogy.com. DC Fuse (400A) The DC fuse protects the inverter charger, wires and batteries from overcurrent. Fuse Cable 4/0 AWG The cable is integrated with copper rings at both ends, enabling...

  • Page 12: Product Overview

    Product Overview External View Internal View Product Overview External View Part Part Remote & Accessory Cable Entry DC Negative Battery Cable Entry AC Output Cable Grommet DC Cable Plate AC Input Cable Grommet DC Positive Battery Cable Entry Main Power Switch Chassis Ground Lug LCD &...

  • Page 13: Internal View

    Product Overview External View Internal View Internal View Part Part Wired Remote Port (REMOTE) Battery Temperature Sensor (BTS) Port Dry Contact Relay Terminal Block DC Negative Battery Terminal AC Output Lever Terminal Block AC Input Lever Terminal Block DC Positive Battery Terminal Input Circuit Breaker Output Circuit Breaker Communication Port (CAN Bus)

  • Page 14: Wiring Diagram

    Wiring Diagram Wiring Diagram AC Loads Shore Power or Generator Live wire (AC) AC Load Center (120V Single Phase, 30A Max.) (120V Single Phase, 40A Max.) Neutral wire (AC) Positive (DC) Negative (DC) Ground Temperature sensor Remote control DC Fuse (400A) RMS-P2 Wired Remote Control...

  • Page 15: Recommended Cable Sizing

    Recommended Cable Sizing Recommended Cable Sizing Cable Cable Length (ft) / (m) Recommended Cable Size 0 ft to 10 ft (0 m to 3 m) 8 AWG AC Output 11 ft to 20 ft (3 m to 6 m) 6 AWG 21 ft to 30 ft (6 m to 9 m) 6 AWG 0 ft to 10 ft (0 m to 3 m)

  • Page 16: Components & Tools

    Recommended Components. Recommended Components Battery Scenario A: REGO Battery Kit REGO 12V 400Ah Lithium Iron Phosphate Battery System Combiner Box Accessory Set Positive / Negative Busbars Accessory Set REGO 4 Ports 400A System Combiner Box...
  • Page 17 Components & Tools Battery Scenario B: Normal Battery Kit Battery Inverter Cable 4/0 AWG Normal Battery with +/- Bolts (Ring Terminal Adapter Cable) Required Tools Wrench (10 mm) Wrench (14 mm) Measuring Tape Insulation Tape Phillips Screwdriver Slotted Screwdriver Socket Wrench Wire stripper (6 mm) (6 mm)
  • Page 18 Components & Tools NOTE z The AC Output Cable Grommet has an inner diameter of 13 mm. Properly select the AC cable size and ensure it can run through the grommet. z The DC Positibe/Negative Terminals use M8 Studs. Select the appropriate ring terminal. z Read Recommended Cable Sizing in this manual, and select the appropriate cables...

  • Page 19: Inspection

    Inspection Inspecting Inverter Charger Environment Placement Checking Battery Inspection Inspecting Inverter Charger 1. Inspect the inverter charger for any visible damage including cracks, dents, deformation, and other visible abnormalities. All connector contacts shall be clean, dry, and free of dirt and corrosion.

  • Page 20: Placement

    Inspection Inspecting Inverter Charger Environment Placement Checking Battery Placement The inverter charger can be fixed vertically (terminals facing down) to a wall or horizontally to the floor. 1. Ensure enough space to avoid tangles and kinks of cables. Allow at least 10 inches of clearance at the fan and at least ≥254mm 7 inches around each side.

  • Page 21: Checking Battery

    Inspection Placement Checking Battery Inspecting Inverter Charger Environment 2. Measure the length of the adapter cable to make sure it can be connected to the inverter charger. NOTE z If the adapter cable is not long enough, reselect the installation site. 3.
  • Page 22 Inspection Inspecting Inverter Charger Environment Placement Checking Battery NOTE z Make sure the battery is working normally. z Battery types supported by the inverter charger: AGM/Gel/SLA/Open Lead Acid Fooded/ Calcium/De-sulphation/Li. z Take care to use a high-capacity lead-acid battery. Be sure to wear protective goggles. If carelessly getting electrolyte in your eyes, flush your eyes with clean water immediately.

  • Page 23: Preparation

    Preparation Mounting Removing the Plate Cautions Preparation Mounting Recommended Accessories Self-tapping Screws (M8 or M6) NOTE z Choose proper self-tapping screws to adapt to the installation site. z Make sure the inverter charger is firmly mounted on the installation site to prevent it from sliding or falling off.

  • Page 24: Cautions

    Preparation Mounting Removing the Plate Cautions 2. Turn the two screws on the lower panel counterclockwise by hand or a Phillips screwdriver, and remove the DC Cable Plate. Cautions NOTE z All wiring should be done by qualified personnel to ensure compliance with all applicable installation code and regulations.

  • Page 25: Ground Cable Wiring

    Ground Cable Wiring Ground Cable Wiring 1. Turn the cable retainer screws for the Chassis Ground Lug counterclockwise with a slotted screwdriver to ensure that the cable retainer is open. Close Open 2. Insert one end of the bare wire into the wiring hole of the Chassis Ground Lug.
  • Page 26 Ground Cable Wiring 4. Connect the other end of the bare cable to the Chassis Ground Lug of the INFO z When connecting the inverter charger to the chassis ground lug of your RV, consult the RV supplier to confirm the location of the chassis ground lug. A connection terminal can be installed if needed.

  • Page 27: Remote Control Wiring

    Remote Control Wiring Remote Control Wiring You may choose to use the wired remote control of the inverter charger. 1. Run one end of the included RJ11 cable through the Remote & Accessory Cable Entry. 2. Connect the connector to the Wired Remote Port (REMOTE). 3.

  • Page 28: Temperature Sensor Wiring

    Temperature Sensor Wiring Temperature Sensor Wiring The temperature sensor measures the temperature of the battery and provides the inverter charger with a charge voltage calibration mechanism to ensure that the inverter charger can properly charge the battery within the operating temperature from -4°F to 140°F or -20°C to 60°C.
  • Page 29 Temperature Sensor Wiring z Do not overtighten the cable retainer screws. Otherwise it will lead to stripped screws or screw bending. 4. Plug the harness connector into the BTS Port of the inverter charger. 5. Place the temperature sensor near the battery and fix it with a cable tie or insulation tape if necessary.

  • Page 30: Battery Wiring

    Terminal by turning it counterclockwise with a socket wrench and then remove the gasket. 3. Insert the positive ring REGO Battery Kit terminal of the battery adapter cable through the DC Positive Battery Cable Entry, and the negative ring terminal through...
  • Page 31 Battery Wiring Device-side Wiring Battery-side Wiring 4. Connect the negative ring terminal to the DC Negative Battery Terminal. 5. Install the gasket and the retaining nut, and tighten the nut clockwise with a socket wrench. NOTE z The retaining nut torque of the DC Negative Battery Terminal is 26 N·m. Do not overtighten it to prevent damage.

  • Page 32: Battery-Side Wiring

    Battery Wiring Device-side Wiring Battery-side Wiring 7. Install the gasket and retaining nut, and tighten the nut clockwise with a socket wrench. NOTE z The retaining nut torque of the DC Positive Battery Terminal is 26 N·m. Do not overtighten it to prevent damage.
  • Page 33 Battery Wiring Device-side Wiring Battery-side Wiring Battery Scenario A: REGO Battery Kit INFO z Read the REGO 4 Ports 400A System Combiner Box User Manual carefully before connection. █ Using Battery Adapter Cable (Anderson 350 Connector to Ring Terminal Adapter Cable) 1.
  • Page 34 Battery Wiring Device-side Wiring Battery-side Wiring 2. For your safety, it is recommended to use a DC fuse (400A). Connect AC/INV FAULT the positive ring terminal to the DC fuse. Install the DC Positive Battery Terminal fuse cable on the other end of the fuse.
  • Page 35 Battery Wiring Device-side Wiring Battery-side Wiring 1. Connect the Anderson Connectors of the batteries to the Adapter Cables (sold separately). 2. Connect the positive and negative ring terminals of the Adapter Cables to the Positive and Negative Busbars (not included) respectively.
  • Page 36 Battery Wiring Device-side Wiring Battery-side Wiring 5. Attach the ring terminal of the other end of fuse cable to the Positive Busbar and tighten the wire retaining bolt with a wrench. AC/INV FAULT DC Positive Battery Terminal Battery Scenario B: Normal Battery Kit NOTE z Select the appropriate wrench according to the specification of the positive/negative wire retaining bolt of the system hub.
  • Page 37 Battery Wiring Device-side Wiring Battery-side Wiring 2. For your safety, it is recommended to use a DC fuse (400A). Connect AC/INV FAULT the positive ring terminal of the inverter charger DC Positive Battery Terminal adapter cable to the DC fuse. Install the fuse wire on the other end of the fuse.

  • Page 38: Ac Output Wiring

    AC Output Wiring Device-side Wiring Load Wiring AC Output Wiring Device-side Wiring 1. Run three bare wires through the AC Output Lever Terminal Block. 2. Push up the switches of the wire harness retainer of the AC Output Lever Terminal Block. 3.

  • Page 39: Load Wiring

    AC Output Wiring Device-side Wiring Load Wiring 4. Press down the wire harness retainer of the AC Output Lever Terminal Block. NOTE z Tug at the wire to ensure a firm connection. Load Wiring Recommended Accessories AC Load Center NOTE z For your safety, it is recommended that qualified electricians familiar with safety codes of electrical systems perform the installation.
  • Page 40 AC Output Wiring Device-side Wiring Load Wiring 2. Connect the AC Output cable of the inverter charger to the AC load center. Connect the live wire to the (L) terminal, the neutral wire to the (N) terminal, and the ground wire to the (PE) busbar.

  • Page 41: Ac Input Wiring

    AC Input Wiring Device-side Wiring Load Wiring AC Input Wiring The AC input is optionally installed on demand. 1. Run the AC power cable Shore Power or Generator (120V Single Phase, 40A Max.) through the AC Input Cable Grommet. AC/INV FAULT AC Input Lever Terminal Block NOTE...
  • Page 42 AC Input Wiring Device-side Wiring Load Wiring 3. Connect the live wire to the (L) terminal, the neutral wire to the (N) terminal, and the ground wire to the ) terminal. NOTE z Strip 10 mm of the insulation off the AC input cable with a wire stripper. z You can only connect the AC input to the AC Input Lever Terminal Block.

  • Page 43: Automatic Generator Start

    Automatic Generator Start Automatic Generator Start If the inverter charger is connected to an AC Power Supply (AC Input) and the generator can automatically start or stop. It is recommended to connect the generator to the Dry Contact Relay Terminal Block with a signal cable. When the voltage of the inverter charger is lower than the set voltage in Program 96, the inverter charger will automatically start the generator and charge the battery while the load is supplied by the generator.
  • Page 44 Automatic Generator Start Wiring Diagram AC Generator AC Input Positive (DC) Negative (DC) Signal Line AC/INV FAULT Dry Contact Relay Battery System (12V) Terminal Block INFO z Connect three signal lines to NC (normally closed contact), NO (normally open contact), and C (common static contact) of the AC Input.
  • Page 45 Automatic Generator Start 3. Run three signal lines through the Remote & Accessory Cable Entry. 4. Turn the cable retainer screws of NC, C and NO of Dry Contact Relay Terminal BLock Close counterclockwise with a slotted screwdriver to ensure that the cable retainers are open.
  • Page 46 Automatic Generator Start 6. Turn the cable retainer screws of NC, C and NO clockwise with a slotted screwdriver to fasten the cable. NOTE z Do not overtighten the cable retainer screws. Otherwise it will lead to stripped screws or screw bending.

  • Page 47: Communication

    Inter-Device Communication Depending on the installation condition, the RV-C communication connections between the inverter charger and other REGO devices can be established with backbone or daisy chain topology. The inter-device communication allows the inverter charger to dynamically adjust the charging profile for an optimal and safe charge.
  • Page 48 Communication Inter-Device Communication Monitoring Device Communication NOTE z The drop cable shall not exceed 19.6 feet (6 m), and the RV-C bus shall not exceed 98.4 feet (30 m). z Different drop sockets are used on the RV-C bus by different RV manufacturers. Select the Drop Plugs that match the drop sockets for the inter-device communication connections.
  • Page 49 NOTE z If you fail to locate the drop taps, please contact the RV manufacturer for help. 6. Connect the Drop Plugs on the drop cables and other REGO devices to the drop sockets on the drop tap. NOTE z Different drop taps are used on the RV-C bus by different RV manufacturers. This user...
  • Page 50 Communication Inter-Device Communication Monitoring Device Communication Daisy Chain Topology The daisy chain topology applies to RVs that are not integrated with RV-C buses. NOTE z Do not place the inverter charger at the first or last of the daisy chain network. Recommended Accessories LP16 Plug (7-Pin) to RJ45 RJ45 Network 1 to 2 Port...
  • Page 51 LP16 Plug (7-Pin) to RJ45 Communication Adapter Cables to the vacant CAN communication ports of other REGO devices. Insert the terminal plugs (sold separately) into the vacant CAN communication port of the first and last REGO devices.

  • Page 52: Monitoring Device Communication

    Communication Inter-Device Communication Monitoring Device Communication Monitoring Device Communication Depending on the application, the short-range or long-range communication connections can be established between the inverter charger and monitoring devices. The monitoring device allows for the monitoring and programming of the inverter charger or even the complete system. NOTE z Make sure the Bluetooth of your phone is turned on.
  • Page 53 Battery Charging Watts Battery Vots Long-Range Monitoring If long-range communication and programming are required, connect the inverter charger to Renogy ONE through Bluetooth or wires, and the Renogy ONE to the DC Home app through Wi-Fi. Recommended Accessories Renogy ONE NOTE z Make sure that the Renogy ONE is powered on before the connection.
  • Page 54 Renogy ONE with the DC Home app through Wi-Fi. Commonly Monitor the inverter charger Security Night Devices Battery Controller on the Renogy ONE or the DC RBT12400LFPL-... RCC60RVRU Home app. Device Scene Community Personal 12V Power Supply NOTE z Make sure the inverter charger does not communicate with any other device.
  • Page 55 If you are unsure about the pinout of the terminal block plug, contact the RV manufacturer. z Refer to Backbone Topology for more instructions. 2. Monitor and program the complete system on Renogy ONE or the DC My Renogy Home app. h left Commonly Security Night...
  • Page 56 2. Connect the Renogy ONE to the free CAN Communication Port on the REGO device with the Communication Adapter Cable (sold separately). 12V Power Supply 3. Pair Renogy ONE with the DC Home app. Monitor...

  • Page 57: Putting Plates Back

    Putting Plates Back Inter-Device Communication Monitoring Device Communication Putting Plates Back Reinstall the plates into the inverter charger after wiring. 1. Check and make sure all cable connections are tight and secure. 2. Install the DC Cable Plate and drive the two panel screws clockwise to fix the plate.

  • Page 58: Power On

    Power on After installation, power on the battery and the AC input connected to the inverter charger, then turn on the inverter charger. REGO 12V 3000W Inverter Charger can be powered on via the main switch or wired remote control.

  • Page 59: Wired Remote Control

    The buzzer rings for 7 seconds z The fan operates with the sound z The screen lights up z The indicator lights up z The ON indicator of the wired remote control lights up Please contact us through renogy.com/contact-us/.

  • Page 60: Operation

    Operation Button Setting Battery Type User Mode Operation You can view the current operation status and warning messages of the inverter charger on the LCD. Icon Function Description Input Source Information Indicates the AC input. INPUTBATT Indicates input voltage, input frequency, battery voltage, and charger current.
  • Page 61 Operation Button Setting Battery Type User Mode Icon Function Description Battery Information Indicates battery level by 0-24%, 25-49%, 50-74%, and 75-100% in battery mode and charging status in line mode. CHARGING In AC mode, the LCD displays the battery charging status. Status Battery voltage LCD Display...
  • Page 62 Operation Button Setting Battery Type User Mode Icon Function Description Load Percentage Battery Voltage LCD Display < 11.2V 11.2V - 11.7V Load < 20% 11.7V - 12.2V > 12.2V Load Information OVER LOAD Indicates overload. Indicates the load level by 0-24%, 25-49%, 50-74%, and 75-100%. 0-24% 25-49% 50-74%...

  • Page 63: Button

    Operation Button Setting Battery Type User Mode Button You can turn to the display pages or set parameters of the inverter charger with the four buttons. AC/INV FAULT Exit the settings and go back to the menu. Menu key. Menu key. 1.

  • Page 64: Setting Battery Type

    Operation Button Setting Battery Type User Mode Setting Battery Type Set the battery type immediately after the inverter charger is powered on. Refer to the specifications provided by the battery manufacturer when choosing a preset battery. Damage caused by incorrect battery type voids warranty. 1.
  • Page 65 Operation Button Setting Battery Type User Mode 4. Press and select a battery type on demand in accordance to the following table. AC/INV FAULT 5. After selection, press to save settings. AC/INV FAULT Program Description Parameter Setting Boost Voltage Float Voltage Code Type of battery User Mode...
  • Page 66 Operation Button Setting Battery Type User Mode Program Description Parameter Setting Boost Voltage Float Voltage Code Sealed Lead Acid 14.4V 13.6V Gel 2 14.4V 13.8V Open Lead Acid / Flooded 14.8V 13.8V For accurate charging, connection to Calcium a temperature 15.1V 13.6V sensor is required.

  • Page 67: User Mode

    Operation Button Setting Battery Type User Mode User Mode WARNING z Read the user manual of the battery when customizing a preset battery. Incorrect battery type selection damages the inverter charger and voids the warranty. 1. Long press until the LCD enters the setting mode.
  • Page 68 Operation Button Setting Battery Type User Mode 。 4. Press to select AC/INV FAULT 5. After selection, press to save settings. By default, this inverter charger is preset to Boost at 14.3V and Float at 13.7V. AC/INV FAULT 6. Long press until the LCD enters the setting mode.
  • Page 69 Operation Button Setting Battery Type User Mode 8. Press to enter 94 settings. AC/INV FAULT 9. Press to select Lithium Battery Non-lithium Battery according to the battery type. AC/INV FAULT AC/INV FAULT 10. After selection, Press to save settings. AC/INV FAULT 11.
  • Page 70 Operation Button Setting Battery Type User Mode 12. Press to enter Program 26. BATT AC/INV FAULT 13. Press to enter 26 settings. BATT AC/INV FAULT 14. For lithium battery, set the Maximum Charging Voltage Bulk Charging Voltage maximum charging voltage in Program 26.
  • Page 71 Operation Button Setting Battery Type User Mode 16. After selection, press to save settings. BATT AC/INV FAULT 17. Long press until the LCD enters the setting mode. AC/INV FAULT AC/INV FAULT 18. Press to enter Program 27. BATT AC/INV FAULT 19.
  • Page 72 Operation Button Setting Battery Type User Mode 20. For lithium battery, set the Battery Low Voltage Open Floating Charging Voltage battery low voltage open Charging charging in Program 27. For non-lithium battery, BATT BATT set the floating charging voltage in Program 27. AC/INV FAULT AC/INV...

  • Page 73: Working

    Working Working REGO 12V 3000W Inverter Charger combines an inverter charger with an automatic transfer switch into one complete system. Featuring a three-stage battery charging mode when connected to the utility AC input, the inverter charger can meet powerful needs as well as charge your battery bank.
  • Page 74 If the AC/INV indicator and CHG indicator do not light up as described in this user manual, but the power supply equipment (batteries and AC input source) is operating normally, the inverter charger needs troubleshooting. Please contact our customer service through renogy. com/contact-us/. 4. Under normal conditions,...

  • Page 75: Working Logic

    Working Logic Power Supply Logic Charging Logic Heat Dissipation Logic Working Logic Power Supply Logic Battery Voltage AC Input Power Supply Equipment 10.5V to 16V (±0.3V) Battery ＜ 10.5V (±0.3V) — — AC Input If the inverter charger is connected to the battery or the AC input is powered off, the battery starts to supply power to the load when the battery voltage ranges from 10.5V to 16V (±0.3V).
  • Page 76 Working Logic Power Supply Logic Charging Logic Heat Dissipation Logic █ Battery Charging Stages Adjustable Time Depending on Battery Bank Size Volts Charging Current % 14.5 Float 13.5v 13.5 12.5 11.5 10.5 Time Full Current Available on Float for on Board Supply in Power Pack Mode The New Battery Chargers And Boosters Offer The Fastest Charge Rate Currently Available Step 1 = Constant Current Charge Step 2 = Absorption Charge at 14.4V/14.8V...

  • Page 77: Heat Dissipation Logic

    Working Logic Power Supply Logic Charging Logic Heat Dissipation Logic Heat Dissipation Logic The inverter charger uses the fan for heat dissipation. The working logic of the fan is as follows: Inverter Charger Working properly The fan works for 1 minute every 30 minutes. When AC output current ≥...

  • Page 78: Power Off

    Power off Main Switch Wired Remote Control Power off Main Switch 1. Press the main switch of the inverter charger to "OFF" to turn it off. 2. The LCD and the LED indicators go out when the inverter charger is powered off. Wired Remote Control 1.
  • Page 79 Power off Main Switch Wired Remote Control 2. The LCD and LED indicators of the inverter charger as well as the ON indicator of the wired remote control go off when the inverter charger is powered off. RMS-P2...

  • Page 80: Overcurrent Protection

    Overcurrent Protection Overcurrent Protection The inverter charger is integrated with two circuit breakers which ensure that the inverter charger keeps operating even when the input/output stops working. When the input/output circuit breaker is activated, a manual reset is required to resume operation. WARNING z Risk of electric shock! Turn off...

  • Page 81: Led Indicators

    LED Indicators Indicator of the Inverter Charger Indicator of the Wired Remote Control LED Indicators Indicator of the Inverter Charger LED Indicator Parameter Solid Output is powered by an AC source in line mode. AC/INV Green Flashing Output is powered by battery or in invert mode. Solid Battery is fully charged.

  • Page 82: Program Codes

    Program Codes Program Codes The inverter charger is fully programmable. You may change the respective parameter by going to the Program Code listed below. █ Operation Methods (1). Long press until the LCD enters the setting mode. (2). Press to select programs. (3).
  • Page 83 Program Codes NOTE z After settings, disconnect the inverter charger from the AC source/shore power. Turn off the inverter charger and wait for 10 seconds. Turn it on and settings will take effect. █ 03 AC Input Voltage Range By default, the inverter charger is set to a narrow input voltage range for which the inverter charger will work in Utility mode.
  • Page 84 Program Codes █ 07 Auto Restart Temperature Fault The operating temperature range for the inverter charger is 32°F to 104°F or 0°C to 40°C. If the temperatures of internal power components begin to exceed their safe operating temperature, the inverter charger shuts down to protect itself from damage. This setting controls whether the inverter charger automatically restarts after the inverter charger cools down or whether you have to manually restart the inverter charger.
  • Page 85 Program Codes Icon Description Details The range is from 10.5V to 12.5V. If the Low battery voltage battery voltage is below this setpoint, no point when the BATT power is given to loads from the battery. By power source default this is the low battery voltage in the switches from charging table for all batteries.
  • Page 86 Program Codes █ 19 Screen Mode By default, after 1 minute of inactivity, the inverter charger will return to the screen displayed at startup. You can change this mode to continue viewing the last screen before inactivity. Icon Description Details Return to default display screen Auto return to...
  • Page 87 Program Codes Icon Description Details Record enabled Record Fault code Record disabled (default) █ 26 Boost Charging For more instructions, read Setting Battery Type in the user manual. NOTE This setting will not be modifiable if you choose a preset battery voltage. When the voltage reaches the preset voltage, the charging will stop.
  • Page 88 Program Codes Icon Description Details Setting Battery Set the floating charging voltage after selecting the user mode Type in Program 94. For non-lithium battery, set the voltage from 13.0V to 15.0V. BATT BATT Battery low voltage Set battery low voltage open charging after selecting the user open charging (for mode in Program 94.
  • Page 89 Program Codes █ 94 Selection of Battery Type Custom For more instructions, read Setting Battery Type in the user manual. NOTE z This setting will not be modifiable if you choose a preset battery voltage. Icon Description Details Lithium battery The battery charge voltage and battery low open charging can be set up in Program 26, 27...
  • Page 90 Program Codes Icon Description Details When battery voltage reaches the setpoint, the dry contact switches from NC to NO. This value cannot be lower than the cut-off point of the low battery. The setting range is from 10.5V Battery low voltage to 12.5V for 12V.

  • Page 91: Warning/Fault Codes

    ERR indicator of the wired remote control are flashing red, while the buzzer beeps long and the LCD displays the FAULT code. Troubleshoot typo according to the following table. For more technical support, contact our custom service through renogy.com/contact-us. Icon...
  • Page 92 06: The output voltage of inverter charger is too high or too low Shut down the inverter charger and restart it. If the fault still persists, ERROR contact our custom service through renogy.com/contact-us/. 07: Inverter charger overloaded Reduce the quantity and power of the load.

  • Page 93: Technical Specifications

    Technical Specifications Technical Specifications Inverter Specifications Rated Output Power 3000W Surge Power (1 second) 9000W Surge Power (3 seconds) 4500W Surge Power (10 seconds) 3600W Nominal Output Voltage RMS 120V AC (100V to 120V AC, 5V intervals) Outuput Frequency 50 Hz (±0.3 Hz) or 60 Hz (±0.3 Hz) Output Wave Form Pure Sine Wave 105% <...
  • Page 94 Technical Specifications Charger Specifications Short Circuit Protection Circuit Breaker 120% < Load < 150% (±10%) Fault (Turn off output after 60 seconds) Output Overload 150% < Load (±10%) Fault (Turn off output after 1 second) Overcharge Protection 16V for 12V DC Shutdown Transfer Switch Specifications Transfer Time...

  • Page 95: Dimensions

    Dimensions Dimensions 12.99 in [330 mm] 0.35 in [9 mm] 8.89 in [266 mm] 12.99 in [330 mm] 0.28 in [7 mm] 14.99 in [380.8 mm] 9.76 in [248 mm] 0.51 in [13 mm] 7.58 in [192.7 mm] 11.22 in [285 mm] 20.07 in [510 mm] NOTE z Dimension tolerance: ±0.2 in (0.5 mm)

  • Page 96: Maintenance

    Maintenance Inspection Cleaning Storage Maintenance Inspection For optimum performance, it is recommended to perform these tasks regularly. z Ensure the inverter charger is installed in a clean, dry and ventilated area. z Ensure there is no damage or wear on the cables. z Ensure the firmness of the connectors and check if there are any loose, damaged or burnt connections.

  • Page 97: Emergency Responses

    Emergency Responses Fire Flooding Smell Noise Emergency Responses In the event of any threat to health or safety, always begin with the steps below before addressing other suggestions. z Immediately contact the fire department or other relevant emergency response team. z Notify all people who might be affected and ensure that they can evacuate the area.

  • Page 98: Technical Support

    Technical Support Technical Support For additional support, contact the Renogy technical support team through renogy.com/contact- us. Have the following information available when contacting Renogy. z Owner name z Contact information z Order number z Purchase channel z Serial number z Brief description of the issue Renogy offers premium services worldwide:...
  • Page 99 FCC Statement This device complies with Part 15 of the FCC Rules. FCC ID: 2ANPBRSMLP4-G2. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 100 "Contact Us". Renogy reserves the right to change the contents of this manual without notice. Join the Renogy Power Plus Community by downloading the DC Home App. Find your e-warranty here, and more.
