Toto MONO TX605KMBR Quick Start Manual

SPECIFICATIONS

178
Ø42
G½

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).

MAINTENANCE

Always wipe chrome plated area with dry soft cloth,
and sometimes wipe it with cloth soaked in mild soap.
ATTENTION
1. Don t use abrasive cleaning material such as; detergents
containing hydrochloric acids, thinner, polishing powder,
and nylon brush.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
S060005BR
"MONO" SINGLE LEVER KITCHEN FAUCET TX605KMBR

INSTALLATION

1.
Ø35 Hole
2.
Faucet
Packing
Ø35 Hole
Washer
Lock Nut
To Hot
To Cold
Water S upply
Water S upply

TROUBLESHOOTING

PROBLEM
Water leaks around the handle
Handle is loose
Body swinging
Setting
Bolt
3. LOCK NUT
CHECK
SOLUTION
POINT
1 Tighten
2
Tighten
3 Tighten
1. CONNECTING
NUT
2. BOLT
R5
