Toto EGO TX607KE Quick Start Manual

SPECIFICATIONS
150±10
G½
185
TX 607 KEBR
"Ego" Combination Kitchen Faucet
150±10
G½
TX 607 KESBR
"Ego II" Combination Kitchen Faucet
S06194BS
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners
may contain chemicals, such as ammonia, chlorine, toilet cleaner
etc. which could adversely affect the finish and are not
recommended for cleaning
INSTALLATION
1
MOUNT CONNECTORS PARALLEL WITH THE
Hot
Water
Supply
0
67
-7
Leg
2
*Tigthen the nut by wrench.
Body
0
67
185
-7
"EGO" COMBINATION KITCHEN FAUCET TX607KE
WALL
Cold
Water
150±10
Supply
Use Seal tape
150
(Not Include)
O-Ring
Packing
Nut *
TROUBLESHOOTING
PROBLEM
Flow rate unsatisfactory
Water leaks around the handle
Handle is loose
1. AERATOR
3. BOLT
ATTENTION
Don t use abrasive cleaners or solvents on faucets and fittings.
1.
2. Flow Regulator should not be remove because it could damage
the system
3. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
installation principles are the same.
Cover 4. The hot water supply side of the faucets is in a condition of high
temperature. Do not allow skin to contact with the hardware
surface directly. Otherwise,
scalding may occur.
CHECK
SOLUTION
POINT
1 Remove & Clean
2 Tighten
3
Tighten
2. CERAMIC HEAD WORK
R5
