Service Manual
Series 45 Frame K2 Open Circuit Axial Piston Pumps
Introduction
©
Danfoss | April 2017
Pump and control sectional view
LS control
(attached to endcap)
LS adjustment
PC adjustment
Cylinder block
Valve plate
Piston
Endcap
(axial ported)
Block spring
LS spool
PC spool
Servo piston
Swashplate
Bias spring
Slipper
Slipper retainer
Tapered roller bearing
Input shaft
Shaft seal
P109038
AX00000301en-US0101 | 7
