Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E Page 1...
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E INDEX 1 – INTRODUCTION..........................6 2 – TECHNICAL CHARACTERISTICS...................... 8 3 – GENERAL DESCRIPTION ........................9 4 – INSTALLATION ..........................10 5 – DESCRIPTION OF THE CONTROLS ....................13 6 – USE OF THE APPLIANCE .........................18 7 –...
Page 4
DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011 Codice di identificazione unico del prodotto-tipo: POP6E Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: POP6E Unique identification code of the product type: Model, batch or serial number required under Article 11 (4):...
Page 5
Name and address of the agent as required pursuant to Article 12 (2): THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza) Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3 e 4...
Page 6
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E IT – SCHEDA PRODOTTO (UE 2015/1186) IT – MARCHIO EN – PRODUCT FICHE (EU 2015/1186) EN – BRAND FR – FICHE PRODUIT (UE 2015/1186) FR – MARQUE THERMOROSSI S.P.A.
Furthermore, Thermorossi reserves the right to apply changes to the content of this manual anytime and without notice. Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or used in any other way without the necessary authorisation.
Page 8
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 1.4 GENERAL GUIDELINES Attention: the appliance must be connected to a system provided with a PE conductor (in compliance with the specifications concerning low voltage equipment). Before installing the appliance check the efficiency of the earth circuit of the power supply system.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 3 – GENERAL DESCRIPTION 3.1 OPERATING TECHNOLOGY Your appliance has been built to fully satisfy all your heating and practical requirements. Top-grade components and functions managed with microprocessor technology guarantee high reliability and optimal performance.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 4 – INSTALLATION 4.1 APPLIANCE LOCATION Follow the general guidelines set out in paragraph 1.1 to the letter. Keep in mind that the flooring of the room in which the appliance is to be installed must withstand the combined weight of the appliance and the pellets contained in the tank.
Page 12
3) Attach the hose cover to the Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Page 13
PRE-TAGLIATA Figura 1 Il presente disegno è di proprietà esclusiva di THERMOROSSI S. p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore. Prodotto Descrizione...
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 5 – DESCRIPTION OF THE CONTROLS The appliance, when operating, could be hot to the touch, particularly the external door: take care when handling the appliance components. Your appliance has obtained the CE marking and has been made to run for at least one hour to check that it functions correctly.
Page 15
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E Display The following information can appear on the display: Displays the preset combustion power, and consequently the pellet consumption, by the number of bars that are lit up around the flame symbol, using this logic:...
Page 16
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E To set the current time and date proceed as follows: 1) Press the Menu Button once to view the following screen: 2) After a few seconds the following screen will appear on the display: 3) Now press the Scroll Buttons to change the day of the week;...
Page 17
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 5-B) Press the Scroll Buttons to select the hour at which you wish the appliance to start up automatically for the second time (ON2). The start up time will be that set before OFF1; this is to avoid setting a second start up time that is earlier than the preceding shut off time.
Page 18
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E When the programmed cycles are enabled (a clock symbol appears on the display) it will not be possible to use an additional chronothermostat. Disabling the programmed cycles: To disable the appliance from carrying out the programmed ON/OFF cycles press the Clock Button once again.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 6 – USE OF THE APPLIANCE 6.1 DESCRIPTION OF THE OPERATING STAGES START: has a duration of approx. 20 minutes, during this phase the appliance is programmed to light the flame. The appliance will not accept power variations in the firebox.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 7 – ROOM TEMPERATURE THERMOSTAT / CHRONOTHERMOSTAT (optional) The appliance can be connected to an additional room temperature thermostat or to an additional chronothermostat. This operation must be exclusively performed by qualified professional staff, as set forth by Decree no. 37 of 22nd January 2008 and applicable laws on the subject.
Page 21
ATTENTION: Use N.O. (normally open) contacts for the connection to the chronothermostat. ATTENTION: In the event of connections to the chronothermostat Thermorossi S.p.a. shall not be held responsible for the appliance not starting up, smoke leaks or breakage of the lighting component. In the event of a programmed cycle on always ensure that the brazier is clean and seated correctly in its lodging.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 8 – CLEANING AND MAINTENANCE 8.1 FOREWORD Before beginning any maintenance operation ensure that the appliance is switched OFF and disconnected from the electric power socket. Your appliance, being a pellet-fuelled appliance, requires regular general controls and cleaning.
Page 23
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E ATTENTION: if the appliance remains inactive (and/or not used for over a month) the generator, the smoke discharge tube and the flue outlet must be thoroughly cleaned and checked for any possible obstructions (e.g., birds nests in the chimney cap) before restarting.
Page 24
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E FIGURE - 7 FIGURE - 8 FIGURE - 9 FIGURE - 10 8.3 REPLACING THE BUFFER BATTERY OF THE CONTROL PANEL Inside the control panel there is a buffer battery type CR 1632. When the time and programming are not being memorised, then the battery needs replacing.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 9 – SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS 9.1 FOREWORD Due to the frequent accidents caused by poor functioning of flue outlets installed in private dwellings, we have prepared the following paragraph to assist the installer in his inspection of the parts concerned with eliminating the gases produced by combustion.
Page 26
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 9.3.2 FLUE OUTLET / FLUE SYSTEM COMPONENTS 1 Chimney 2 Flow path Every chimney must have minimum number of components as laid down by 3 Smoke discharge tube standard UNI EN 1443 which are also indicated in the figure on the left.
ATTENTION: The appearance of one of the alarms described below, does not necessarily imply a defect in the product, but simply Thermorossi S.p.A.’s intention to inform the user of the need for corrective actions in order to guarantee maximum safety, greater reliability and high performance of the appliance.
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 12 – INFORMATION FOR THE SKILLED TECHNICIAN 12.1 MAIN COMPONENTS AND THEIR OPERATION SMOKE PRESSURE SWITCH This is a safety switch that stops the screw feeder motor whenever necessary. The main cause for the pressure switch tripping is a blocked flue outlet or smoke exhaust pipe.
Page 30
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E 12.3 TROUBLESHOOTING CAUSE-SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION CLEAN THE BRAZIER AS INDICATED IN THIS USE AND PELLET TANK IS EMPTY MAINTENANCE GUIDE, THEN FILL UP THE TANK WITH THE FOLLOWING ALARM IS SHOWN ON THE DISPLAY “NO PELLET”...
Page 31
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E PROBLEM POSSIBLE CAUSE SOLUTION ROOM TEMPERATURE THERMOSTAT SET TOO LOW; APPLIANCE OPERATES THE APPLIANCE NEEDS TO RUN FOR MORE HOURS AT A INTERMITTENTLY HIGHER POWER; SET A HIGHER ROOM TEMPERATURE...
Page 32
Installation, use and maintenance guide POP6 – POP6E – POP8 – POP8E F ire L o v e rs Via Grumolo, 4 (Z.I.) 36011 Arsiero (VI) - ITALY Fax 0445.741657 - www.thermorossi.com - info@thermorossi.it Page 31...
