- Page 1 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Installation, use and maintenance guide Models: - Bosky 30 EVO - Bosky F30 EVO - Bosky Country 30 EVO - Bosky Country F30 EVO Page 0...
- Page 2 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Page 1...
-
Page 3: Table Of Contents
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO NDEX 1 – INTRODUCTION..........................7 1.1 SAFETY GUIDELINES ............................. 7 1.2 SAFETY STANDARDS ............................. 7 1.3 RECOMMENDATIONS ............................. 7 1.4 GENERAL GUIDELINES ..........................7 1.5 TRANSPORTATION AND STORAGE ......................8 1.6 GUIDELINES FOR CORRECT DISPOSAL OF THE PRODUCT .............. - Page 4 9.3.4 CONTROLS PRIOR TO INSTALLING THE APPLIANCE ......................31 10 - PROBLEMS, CAUSES AND SOLUTIONS ..................32 11 - SPARE PARTS ..........................33 11.1 BOSKY 30 EVO ............................33 11.2 BOSKY F30 EVO ............................34 11.3 BOSKY COUNTRY F30 EVO ........................36 11.4 BOSKY COUNTRY 30 EVO .........................
- Page 5 DECLARATION OF PERFORMANCE ACCORDING TO REGULATION (EU) 305/2011 Codice di identificazione unico del prodotto-tipo: BOSKY 30 EVO Modello, lotto, serie ai sensi dell'articolo 11, paragrafo 4: BOSKY 30 EVO Unique identification code of the product type: Model, batch or serial number required under Article 11(4):...
- Page 6 Name and address of the agent as required pursuant to Article 12 (2): THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza) Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3...
- Page 7 Name and address of the agent as required pursuant to Article 12 (2): (5): THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (Vicenza) Sistema di valutazione e verifica della costanza della prestazione del prodotto da costruzione di cui all'allegato V: Sistema 3...
-
Page 8: Introduction
Furthermore, Thermorossi reserves the right to apply changes to the content of this manual anytime and without notice. Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or used in any other way without the necessary authorisation. -
Page 9: Transportation And Storage
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Attention: the cable section must in any case be no less than 1.5 mm². The appliance requires powering with a voltage of 230V and 50 Hz. Position the appliance so that the electric power outlet in the room is easily accessible. Ensure that a suitable differential switch is installed upstream from the equipment. -
Page 10: Technical Characteristics
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 2 – TECHNICAL CHARACTERISTICS BOSKY BOSKY BOSKY 30 EVO BOSKY F30 EVO COUNTRY COUNTRY 30 EVO F30 EVO Height (mm) Depth (mm) Width (mm) 1,084 1,048 Weight (Kg) Ø... -
Page 11: Dimensions
VISTA ISOMETRICA - SCALA 1:10 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 2.1 DIMENSIONS BOSKY 30 EVO VISTA ISOMETRICA - SCALA 1:10 BOSKY F30 EVO VISTA FRONTALE VISTA FIANCO SX VISTA POSTERIORE VISTA SUPERIORE... -
Page 12: General Description
It is strictly prohibited to store combustible or inflammable material in the compartment under the oven. The temperature inside can reach very high levels. 3.2 MAIN COMPONENTS BOSKY 30 EVO and BOSKY F30 EVO Primary air control Oven light switch (only F30 EVO) - Page 13 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO BOSKY COUNTRY 30 and BOSKY COUNTRY F30 EVO Primary air control Safety heat exchanger insertion plate Water thermometer Pump active indicator light Starter Smoke deviator flap (only F30 EVO) Thermostat probe and thermometer pocket Air adjustment lever Ash pan door...
- Page 14 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO LEGENDA STARTER CHIUSO STARTER CLOSED STARTER APERTO STARTER OPEN Page 13...
-
Page 15: Installation
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 4 – INSTALLATION 4.1 APPLIANCE LOCATION Follow the general guidelines set out in paragraph 1.1 to the letter. Be aware that the flooring of the installation site must be capable of withstanding the weight of the appliance and the water contained in it. -
Page 16: Plumbing System Connections And Diagrams
BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 5 – PLUMBING SYSTEM CONNECTIONS AND DIAGRAMS 5.1 GENERATOR PLUMBING COMPONENTS BOSKY 30 EVO and BOSKY F30 EVO Delivery tube system 1¼” F Heat exchanger thermal relief ½" F System return fitting 1¼” F Heat exchanger discharge ½"... -
Page 17: Instructions For Executing The Hydraulic System Closed Expansion Tank
The nominal volume of the closed expansion tank must be sized in relation to the total volume of the water contained in the system. Thermorossi prescribes the size of the closed expansion tank as equal to 10% of the volume of water contained in the entire system. -
Page 18: Schematic Diagram Of Typical Closed Expansion Tank Hydraulic System
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 5.5 SCHEMATIC DIAGRAM OF TYPICAL CLOSED EXPANSION TANK HYDRAULIC SYSTEM Gate valve (throttle according to pressure drop in the system) Heating plant delivery Heating plant return Closed expansion tank, sized to at least 10% of the volume of water contained in all the system Boiler discharge... -
Page 19: Schematic Diagram Of Typical Closed Expansion Tank Hydraulic System With Puffer Tank
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 5.6 SCHEMATIC DIAGRAM OF TYPICAL CLOSED EXPANSION TANK HYDRAULIC SYSTEM WITH PUFFER TANK System circulating pump Heating plant delivery On-off valve Heating plant return Closed expansion tank, sized to at least 10% of the Nonreturn valve volume of water contained in all the system Thermal relief valve... -
Page 20: Assembling The Components
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 6 – ASSEMBLING THE COMPONENTS 6.1 ASSEMBLING THE SAFETY HEAT EXCHANGER BOSKY 30/F30 EVO (OPTIONAL) Install the safety heat exchanger in accordance with the following procedure: Remove the external door acting on its hinges. Remove the left side panel, its insulation and the vertical upright by acting on the corresponding screws. -
Page 21: Installation Of The Circulating Pump On Bosky 30/F30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 6.3 INSTALLATION OF THE CIRCULATING PUMP ON BOSKY 30/F30 EVO It is mandatory to connect the circulating pump (not supplied as standard) to the dedicated terminal block. The terminal block is located behind the LH side panel. -
Page 22: Mounting The Casing Only On Bosky Country 30/F30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which is not covered by warranty, will result to the body of the generator. Have an electrician check the earthing. There must be no electric potential (Volt) between the earth of the generator and the actual earth of the system. -
Page 23: Mounting The Front Handrail Only On Bosky Country 30/F30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 6.6 MOUNTING THE FRONT HANDRAIL ONLY ON BOSKY COUNTRY 30/F30 EVO To mount the front handrail proceed as follows: Fix the spacers (2) and the supports (4) with the screws (3). Next fix the resulting unit to the product with the screws (1). -
Page 24: Use Of The Appliance
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 7 – USE OF THE APPLIANCE The appliance, when operating, is hot to the touch, particularly the door of the combustion chamber and the cooktop: consequently, take care not to touch any surface. Your appliance has obtained the CE marking. The product must not be used by children, by persons with physical or mental impairments, by persons who are not familiar with the instructions for use and maintenance of the product (the instructions are found in this installation, use and maintenance manual). -
Page 25: Refuelling
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO ATTENTION: IT IS NORMAL FOR THE COOKTOP, AFTER THE FIRST LIGHTING, TO ACQUIRE AND RETAIN A BLUISH AND/OR YELLOWISH HUE. 7.2 REFUELLING The stove is an intermittent combustion appliance so it requires refuelling. Once combustion is achieved inside the combustion chamber and consequently there are embers present, proceed with the first fuel feed: 1) Raise the starter using the special riddling tool. -
Page 26: How To Use The Oven (Only On F30 Evo/Country F30 Evo)
Heating and cooking 7.5 HOW TO USE THE FOLD-AWAY HANGER (ONLY ON BOSKY 30 and F30 EVO) BOSKY 30 EVO and BOSKY F30 EVO are fitted with 2 practical foldaway racks for hanging your washing on to dry. To extend them simply pull out as indicated in the figure on the side. -
Page 27: Prescriptions For Correct Operation
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 7.8 PRESCRIPTIONS FOR CORRECT OPERATION - Respect the maximum declared consumption, do not over- load the stove with excessive quantities of fuel as this could cause damage. LOADING A LARGER QUANTITY OF FUEL OR LOADING SEVERAL TIMES IN AN HOUR EXPOSES THE COMPONENTS OF THE APPLIANCE TO VERY HIGH TEMPERATURES. -
Page 28: Cleaning And Maintenance
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 8 - CLEANING AND MAINTENANCE 8.1 FOREWORD To guarantee correct operation and optimal performance of the appliance at all times carry out the operations described below. Observe the recommended frequency. If the product is unused for a prolonged period of time before starting up it is mandatory to inspect the smoke channel and outlet to ensure that there are no obstructions. -
Page 29: Cleaning The Cooktop And Glass Elements
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO EVERY WEEK: Empty the secondary ash pan. We recommend emptying the ash pan regularly before it fills up completely. EVERY MONTH: Clean under the oven, if present. To clean under the oven, remove the cleaning cover as indicated in the figure below and vacuum out the ash deposits. -
Page 30: Smoke Discharge Tube
9.3.1 CONNECTION TO THE FLUE OUTLET Only for models BOSKY 30 EVO and BOSKY F30 EVO. The smoke outlet can be provided either at the top or at the rear, using the collar and its fixing elements supplied as an optional, as shown in the figure below on the right. -
Page 31: Chimney Types
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 9.3.2 CHIMNEY TYPES The following types of chimneys, constructed as described, are possible: LEGENDA • System: chimney installed using a combination of compatible components (flue liner, VITE TC+ M6 CAP SCREW TC + M6 insulation, outer casing, etc…), manufactured or specified by a single manufacturer RONDELLA D6... -
Page 32: Controls Prior To Installing The Appliance
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 9.3.4 CONTROLS PRIOR TO INSTALLING THE APPLIANCE The user must possess a certificate of conformance for the flue outlet (Ministerial Decree 22 January 2008, no. 37). The flue outlet must be built in compliance with UNI 10683. The smoke exhaust illustrated in the figure on the side is the best solution required to ensure that the flue gases are discharged. -
Page 33: Problems, Causes And Solutions
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 10 - PROBLEMS, CAUSES AND SOLUTIONS PROBLEM CAUSE SOLUTION Blocked grate. Clean the grate. Moist wood or too thick. Use smaller sized and more seasoned wood. Clean the ash pan. Remove the cooktop and thoroughly clean the flue Difficulty in lighting the gas path and the flue outlet... -
Page 34: Spare Parts
BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 11 - SPARE PARTS 11.1 BOSKY 30 EVO 7001 1 81 1 6001 1 571 S C A M B IA T O R E A L E T T A T O... -
Page 35: Bosky F30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 11.2 BOSKY F30 EVO Page 34... - Page 36 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 6001 1 559 6001 1 571 S C A M B IA T O R E A L E T T A T O 6001 1 722 C E R C H I IN G H IS A 7001 1 663 7001 2202 8001 1 626...
-
Page 37: Bosky Country F30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 11.3 BOSKY COUNTRY F30 EVO 20/1 1 /201 8 7001 3545 C om pleto 6001 0831 P om olo 6001 3080 6001 3073 6001 3080 7001 3497 60004320 7001 351 0 7001 3492... - Page 38 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Page 37...
- Page 39 60013056 Vite fermo 60010341 Treccia d.8 per porta COUNTRY F_3.pdf Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà p Prodotto Descrizione Note...
- Page 40 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Page 39...
-
Page 41: Bosky Country 30 Evo
Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO 11.4 BOSKY COUNTRY 30 EVO Page 40... - Page 42 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Page 41...
-
Page 43: Bosky Country 30/F30 Evo
7001 3480 7001 3479 7001 351 7 6001 3079 07/1 2/2020 C O U N T R Y _C O U N T R Y F _1 .D F T LEGENDA BOSKY 30 EVO BOSKY 30 EVO Optional Optional VETRIFICATO VITRIFIED... - Page 44 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO BOSKY F30 EVO BOSKY F30 EVO DAL 18-04-06 SINCE 18-04-06 Optional Optional VETRIFICATO VITRIFIED BIANCO WHITE CANNA FUCILE RIFLE BARREL GREY MARRON FUME’ SMOKY BROWN BEIGE BEIGE ROSSO TELAIO IN GHISA CAST-IRON FRAME...
- Page 45 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO Porta caricamento completa Complete feed door Maniglia Country acciaio Country steel handle (specificare dove usata) (specify where used) Perno fissaggio famiglia Country Country fixing pin Semiguscio anteriore maniglia grigio scuro Front handle cover - dark grey Semiguscio posteriore maniglia grigio scuro Rear handle cover - dark grey...
- Page 46 Installation, use and maintenance guide BOSKY 30/F30 EVO – BOSKY COUNTRY 30/F30 EVO F ire L o v e rs Via Grumolo, 4 (Z.I.) 36011 Arsiero (VI) - ITALY Fax 0445.741657 - www.thermorossi.com - info@thermorossi.it Page 45...
