INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
1:1 Ratio
Fast-Flo Air Powered Pump
1.2 MPa, 12 bar (180 psi) Maximum Air Working Pressure
1.6 MPa, 16 bar (230 psi) Maximum Material Discharge Pressure
Model 225–957
Includes leather packed, carbon steel pump, and an
extension tube.
Assemble as shown.
Pump instructions in separate instruction manual 307–427.
Ref
No.
Part No.
Description
1
226–940
1:1 FAST-FLO AIR POWERED PUMP
See 307–427 for parts
2
215–965
TUBE, extension
307 numbers in descriptions refer to separate instruction manuals.
Order parts by name and series letter of the assembly for which
you are ordering.
3/8 npt(f)
