Instructions - Parts
Wall Mount
Packages
Package solutions for pumping or circulating finishing materials.
For professional use only.
Important Safety Instructions
Read all warnings and instructions in
this manual. Save these instructions.
See pages 3-5 for model information, including maximum working pressure.
®
Xtreme
Packages
TI10362A
™
Dura-Flo
Packages
TI10398A
312358F
®
High-Flo
Packages
TI10364A
II 2 G Ex h IIB 230°C (T2) Gb
EN
TI28081A
Advertisement
Table of Contents
Related Manuals for Graco Xtreme 116MCN
Summary of Contents for Graco Xtreme 116MCN
- Page 1 Instructions - Parts Wall Mount 312358F Packages Package solutions for pumping or circulating finishing materials. For professional use only. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. See pages 3-5 for model information, including maximum working pressure. ®...
-
Page 2: Table Of Contents
Integrated Air Control Module ....9 Graco Information ......20 Air Line Accessories . -
Page 3: Models
Models Models Part No. Matrix Check your wall mount package’s identification plate (ID) for the 6-digit part number of your package. Use the following matrix to define the construction of your package, based on the six digits. For example, Part No. 1 16 M C N rep- resents a bare Xtreme package (1), pressure ratio (16: 1), low noise motor (M), carbon steel lower (C), and a lower with an enclosed wet cup and npt connec- tions (N). -
Page 4: Wall Mount Packages
Models Wall Mount Packages NOTE: All packages include integrated air controls, a wall mount bracket, attaching hardware, and ground wire. Xtreme Packages Maximum Includes (see page 5): Working Maximum Air Pressure Input Pressure Lower Size (cc 5 Gal. CST 55 Gal. CST CST Fluid Filter Part No. - Page 5 Models High-Flo Packages Maximum Working Maximum Air Pressure Input Pressure Lower Size (cc Part No. psi (MPa, bar) psi (MPa, bar) per cycle) 703MSN 300 (2.1, 21) 100 (0.7, 7.0) 1500 703MST 300 (2.1, 21) 100 (0.7, 7.0) 1500 703SSN 300 (2.1, 21) 100 (0.7, 7.0) 1500...
-
Page 6: Warnings
Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable. - Page 7 Warnings EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system com- ponent.
-
Page 8: Installation
Installation Installation Mount on Wall GS, LW 1. Ensure the wall is strong enough to support the weight of the pump assembly and accessories, fluid, hoses, and stress caused during pump operation. 2. Ensure that the mounting location has sufficient TI8250A clearance for easy operator access. -
Page 9: Package Components
Package Components Package Components Integrated Air Control Module • Air line moisture drain valve (S): install at the bot- tom of each air line drop, to drain moisture. Fluid Line Components Some Xtreme and Dura-Flo packages include fluid suc- Trapped air can cause the pump to cycle unexpect- tion kits and fluid filter kits. - Page 10 Package Components Detail of Integrated Air Control Module (C) TI8322C L and M TI10390A . 2: Typical Installation (Xtreme Package Shown) Key: Pump 55 Gallon (200 Liter) Drum Suction Kit Wall Bracket 5 Gallon (19 Liter) Pail Suction Kit Integrated Air Control Module (includes items D-H) Pump Ground Wire (required) Bleed-type Master Air Valve (required) Main Air Supply Line...
-
Page 11: Pump Operation And Repair
Package Components Pump Operation and Repair This equipment stays pressurized until pressure is manually relieved. To help prevent serious injury from splashing fluid and moving parts, follow the Pressure Relief Procedure when you stop spraying and before cleaning, checking, or servicing the equipment. Follow the Pressure Relief Procedure in your pump manual before cleaning or repairing your equipment. -
Page 12: Parts
Parts Parts Xtreme Packages Common Parts Screws are thread-forming. Start threading by hand before using a tool. Torque to 20 ft-lb (27.1 N•m). The following parts are used on all Xtreme wall mount packages. Not used on all packages. Ref. Part Description Qty. -
Page 13: Suction And Filter Kits For Xtreme Packages
Parts Suction and Filter Kits for Xtreme Packages 247472 1-1/4 in., 5. Gal. (19 Liter) CST 247474 1 in. CST Fluid Filter Kit Suction Kit Ref. Part Description Qty. 100509 PLUG, pipe; 1/4 npt Ref. Part Description Qty. 150286 ADAPTER; 3/8 npt (m x f) 116401 ELBOW;... -
Page 14: Dura-Flo Packages
Parts Dura-Flo Packages Common Parts Screws are thread-forming. Start threading by hand The following parts are used on all Dura-Flo wall mount before using a tool. Torque to 20 ft-lb (27.1 N•m). packages. Not used on all packages. Ref. Part Description Qty. -
Page 15: Suction Kits For Dura-Flo Packages
Parts Suction Kits for Dura-Flo Packages 247475 1-1/2 in., 5. Gal. (19 Liter) SST 247476 1-1/2 in., 55. Gal. (200 Liter) SST Suction Kit Suction Kit Ref. Part Description Ref. Part Description 101 15M667 ADAPTER; 1-1/2 npt(m) x 3/4 npt(f) 15M667 ADAPTER;... -
Page 16: Filter Kits For Dura-Flo Packages
Parts Filter Kits for Dura-Flo Packages 247479 3/4 in. SST Fluid Filter Kit Used on 247480 Kit only. Ref. Part Description Qty. 102281 BUSHING; 3/4 npt(m) x 3/8 npt(f) 15C076 ADAPTER; 3/8 npt (m x f) 235207 UNION, swivel; 3/8 npt(m) x 3/8 npsm(f) 171195 NIPPLE;... -
Page 17: High-Flo Packages
Parts High-Flo Packages Common Parts Screws are thread-forming. Start threading by hand before using a tool. Torque to 20 ft-lb (27.1 N•m). The following parts are used on all High-Flo wall mount packages. Ref. Part Description Qty. NXT011 CONTROL, air, integrated; see 311239 255143 BRACKET, mounting (includes 4 and 5) -
Page 18: Mounting Hole Diagram
Mounting Hole Diagram Mounting Hole Diagram 17.8 in. (451 mm) 14.5 in. (368 mm) 12.4 in. (314 mm) 9.0 in. (229 mm) 5.4 in. (137 mm) 7.4 in. (187 mm) 5.3 in. (133 mm) 2.0 in. (51 mm) 1.0 in. (25 mm) 1.6 in. -
Page 19: Dimensions
Dimensions Dimensions High-Flo Packages Xtreme Packages Dura-Flo Packages TI10425 TI10427 TI28083a TI10426 Air Inlet Fluid Inlet Fluid Outlet Weight Package in. (mm) in. (mm) in. (mm) in. (mm) (in.) (in.) (in.) lb (kg) Xtreme Pumps (bare) 40.7 (1033) 13.8 (350) 3/4 npt(f) 1-1/4 npt(m) 1 npt(f) -
Page 20: Graco Standard Warranty
