BALE KING BRX850
Bale Retriever
Operator's & Parts Manual
Last Updated: July 10, 2023
BRIDGEVIEW MANUFACTURING INC.
P.O BOX 4, HWY 22
GERALD, SASK. S0A 1B0
CANADA
Ph: 306-745-2711
Fax: 306-745-3364
Email: bmi@sasktel.net
www.bridgeviewmanufacturing.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BALE KING BRX850 and is the answer not in the manual?

Questions and answers

Related Manuals for Bridgeview BALE KING BRX850

Summary of Contents for Bridgeview BALE KING BRX850

  • Page 1 BALE KING BRX850 Bale Retriever Operator's & Parts Manual Last Updated: July 10, 2023 BRIDGEVIEW MANUFACTURING INC. P.O BOX 4, HWY 22 GERALD, SASK. S0A 1B0 CANADA Ph: 306-745-2711 Fax: 306-745-3364 Email: bmi@sasktel.net www.bridgeviewmanufacturing.com...
  • Page 2 Your Authorized Dealer Your Serial Number The Serial Number is located on the front of the Left Rail. Bridgeview Manufacturing Inc.

  • Page 3: Table Of Contents

    TROUBLESHOOTING GUIDE ..................13 FEATURES AND SPECIFICATIONS ................14 PARTS MANUAL......................15 Bale King BRX850 ....................... 15 Front and Rear Deck ..................... 16 Rocking Axle Weldment Left (and Right)..............17 NOTE: Quantities are given as per side. For both sides, double the above quantities . 17 Axle Install ........................
  • Page 4 Spindle and Rim Assembly (Oversized Wheels) ............20 6500 Lb Spindle Assembly ................... 21 A Frame ........................21 Hydraulic and wiring diagram ..................42 Conveyor Chain motor ....................42 Tilt Cylinder ........................44 Loading arm ........................44 Light Diagram ....................... 46 NOTES ..........................47 Bridgeview Manufacturing Inc.

  • Page 5: Introduction

    • Warranty does not cover normal wear and tear. • Warranty will be VOID and Bridgeview Manufacturing Inc. is not liable in any way if the Bale King BRX850 is used for any purpose other than its intended use. • Tire warranty is covered by the Tire Manufacturer.

  • Page 6: Safety Precautions

    Warranty will be VOID if any component is altered or modified in any way, unless written permission is given by Bridgeview Manufacturing. Bridgeview Manufacturing Inc. reserves the right to make changes or improvements at any time without notice or obligation.

  • Page 7: Features

    Adjust the hitch height such that the machine sits level when attached to the tractor. Axles The Bale King BRX850 is equipped with two tire rocking tandem axle with 14L-16.1 SL and an option to oversize the tires to 16.5L-16.1 (BMI #34541). Lifting Arm The lifting arm on the BRX850 can handle up to 6.5 ft round bales.

  • Page 8: Bale Deck

    Adjustable Roll Over Stop The Roll Over Stop can be adjusted to stop smaller bales sooner. Remove the top Bent Pull Pins and rotate the Roll Over Stop to the desired position and reinstall the Bent Pull Pins. Bridgeview Manufacturing Inc.

  • Page 9: Operation

    Unloading Bales • Raise deck up. • Using the pusher, unload the bales • Lower deck once all bales are unloaded and return pusher to the front of the machine. Bridgeview Manufacturing Inc.

  • Page 10: Unhooking Machine

    Pusher Medium hose with red marker: Lifting Arm Medium hose with blue marker: Deck Lift Cylinder Note: Always set the tractor's hydraulic flow at a lower rate and adjust it upward until the desired speed is reached. Bridgeview Manufacturing Inc.

  • Page 11: Maintenance

    Lifting Arm Pivot (x 2) 200 Bales (or 10 hours) Lifting Arm Cylinder (x2) Deck Lift Cylinder (x2) A Frame Pivot(x2) 1000 Bales (or 50 hours) Deck Pivot (x4) Deck Chain Wheel Hubs (x 4) Seasonally (or 300 hours) Bridgeview Manufacturing Inc.

  • Page 12: Wheels And Tires

    If there is excessive wheel end play, restriction to rotation, noise, or "bumpy" rotation, the bearing unit needs to be replaced. Remove the wheel. Remove the dust cap by carefully prying around the flange of the cap. Bridgeview Manufacturing Inc.

  • Page 13: Bearing And Seal Inspection

    Then loosen the spindle nut to remove the torque. Do not rotate the hub. Tighten the spindle nut until it is snug and install cotter pin. Pack hub full of grease and install dust cap. Install the wheels and fasten the bolts. Torque bolts to 125 ft-lbs Bridgeview Manufacturing Inc.

  • Page 14: Sled Chain

    Correct tension is measured as 1 inch deflection between chain and deck. Adjust chain tension using the following steps: Loosen the lock nut Turn tension nut accordingly until correct chain tension is acheived. Tighten Lock nut. Bridgeview Manufacturing Inc.

  • Page 15: Cylinder Maintenance

    Rusted cylinder shafts are NOT covered by warranty NOTE: Check all hoses and fittings periodically for leaks. Tighten or replace any dripping components or any worn out hoses. Bridgeview Manufacturing Inc.

  • Page 16: Transportation

    TRANSPORTATION The Bale King BRX850 can be safely towed on public roads, following these precautions: • Tow vehicle must be rated for at least 6490 lb gross, 1930 lb tongue when machine is empty, and 22500 lb gross, 5887 lb tongue when loaded.

  • Page 17: Troubleshooting Guide

    Scored Cylinder Shaft and replace shaft if necessary damaged Seal • Replace cylinder seal if damaged • Replace missing or broken 3/8” x 1” Bolt Lights not in Broken or Missing Shear Position Bolt and 3/8” Nylon lock Nut Bridgeview Manufacturing Inc.

  • Page 18: Features And Specifications

    Tire Size (Oversized Tire Option) 16.5L-16.1 10 Ply Tire Inflation (Standard Tires) 52 PSI Tire Inflation (Oversized Tire Option) 36 PSI Wheel Nut Torque 125 ft-lbs Drive Chain Type C2080H Horsepower Requirement Required Number of Hydraulic Remotes Bridgeview Manufacturing Inc.

  • Page 19: Parts Manual

    Rear Deck A Frame Pusher Lifting Arm Rocking Tandem Axle Wheel Assembly Rollover Stop **THIS MANUAL IS FOR SERIAL NUMBERS 26227 & UP ONLY. FOR PRIOR SERIAL NUMBERS, CONTACT BRIDGEVIEW DIRECTLY. ** Per ID#: NSS=Not Sold Separately Bridgeview Manufacturing Inc.

  • Page 20: Front And Rear Deck

    Front and Rear Deck Item # Description ID number QTY. ¾” x 2” Bolt 13800 3/4" Stover Lock Nut 11823 Front Deck Rear Deck Bridgeview Manufacturing Inc.

  • Page 21: Rocking Axle Weldment Left (And Right)

    2 ½” x 2” x 1 ¾” HSB 34461 Axle Pivot Spacer 34702 0.25 -28 Self Tap Grease Zerk 16364 Rocking Axle Weldment Left 34782 (Right) (34789) NOTE: Quantities are given as per side. For both sides, double the above quantities Bridgeview Manufacturing Inc.

  • Page 22: Axle Install

    14L-16.1 SL Spindle and Rim See next two Assembly pages NOTE: Quantities are given as per side. For both sides, double the above quantities NOTE: For oversized tires Option Substitute the above spindle assembly for the 16.L-16.1 Spindle and Rim Assembly Bridgeview Manufacturing Inc.

  • Page 23: Spindle And Rim Assembly (Standard Wheels)

    Spindle and Rim Assembly (Standard Wheels) Item # Description ID number QTY. 9/16” x ¾” NF Wheel Stud 10347 Tire 14L-16.1 SL 22851 6500 lb Axle Spindle 29679 Bridgeview Manufacturing Inc.

  • Page 24: Spindle And Rim Assembly (Oversized Wheels)

    Spindle and Rim Assembly (Oversized Wheels) Item # Description ID number QTY. 9/16” x ¾” NF Wheel Stud 10347 Tire 16.5L-16.1 12850 6500 Lb Axle Spindle 29679 Bridgeview Manufacturing Inc.

  • Page 25: 6500 Lb Spindle Assembly

    10343 #6 * Outer Bearing Race 10346 25821 Outer Bearing Cone, 1-3/8" ID 10348 25877 Cotter Pin, 3/16" x 1-1/2" 10072 Flat Washer, 1-1/6" ID x 2" OD 10071 Castle Nut, 1" NF 10153 Dust Cap 10350 Bridgeview Manufacturing Inc.

  • Page 26: A Frame

    ¼” -28 Self Tapping Grease Zerk 45 20888 7/16” Nylon Lock Nut 10799 Side Arm Pin 8.875” 27347 7/16” x 3” Bolt 21784 Side Arm Cylinder Pin 6.75 24131 Pilot Operated Check Valve 19114 5/16” Nylon Lock Nut 11815 Bridgeview Manufacturing Inc.
  • Page 27 ½” x 3” Allen Head Bolt 25952 ½” Nylon Lock Nut 10241 Sprocket Spacer 34759 Motor Chain Sprocket Weldment 34776 Hydraulic Motor LH 28702 Hydraulic Motor RH 28703 1/2" Stover Lock Nut 14393 1/2" x 2 1/2" Allen Head Bolt 16863 Bridgeview Manufacturing Inc.
  • Page 28 Item # Description ID number QTY. Elevator Bolts 17970 ¼” Nylon Lock Nut 111664 Sled Stop Striker Pin 35056 5/8” Nylon Lock Nut 10364 Caster Lock Spring 28842 Sled Weldment 34777 Sled Slider Top 34583 Step Washer 34790 Bridgeview Manufacturing Inc.
  • Page 29 Sled Attachment Item # Description ID number QTY. ½” x 2 ¼” Carriage Bolt 34761 Sled Chain Attachment 34801 ½” Nylon Lock Nut 10241 ½” Flat Washer 11668 Bridgeview Manufacturing Inc.
  • Page 30 3/8” x 1” Bolt 13806 3/8” x 2 ½” Bolt 26307 3/8” Nylon Lock Nut 10806 5/16” x 2 ½” Bolt 19115 5/16” Nylon Lock Nut 11815 3/8” Washer Fender 13773 Front Sled Barrier 34744 5/16” Flat Washer 12496 Bridgeview Manufacturing Inc.
  • Page 31 13795 ¾” x 5” Bolt 17826 ¾” Nylon Lock Nut 10007 Idler Wheel Assembly 34460 Chain Tensioner Pin (6.5”) 34594 ¼” x 2” Bolt 11663 ¼” Nylon Lock Nut 11664 Tensioner Roller 34746 Chain Tensioner Carriage 34871 Bridgeview Manufacturing Inc.
  • Page 32 ID number QTY. ½” Nylon Lock Nut 10241 ½” x 1 ½” Bolt 10174 3/8” Nylon Lock Nut 10806 3/8” x 3” Bolt 13770 Arm Float 34930 Arm Float Rear Arm 34779 Arm Float Front Arm 34778 Bridgeview Manufacturing Inc.
  • Page 33 Lifting Arm Bridgeview Manufacturing Inc.
  • Page 34 Side Arm Cylinder Pin 6.75 24131 5/8” x 2” Bolt Carriage 16361 5/8” Flat Washer 13975 5/8” Nylon Lock Nut 10364 5/8”x 6” UNC Bolt 34762 5/8” Hex Nut 10176 5/8” x 2 ½” Bolt Full Thread 10008 Bridgeview Manufacturing Inc.
  • Page 35 Roll Over Stop Item # Description ID number QTY. ¾” x 3 ½” Bent Pull Pins 34457 Roll Over Stop 34775 Bridgeview Manufacturing Inc.
  • Page 36 Manual Holder Item # Description ID number QTY. ¼” x ¾” Bolt 11809 ¼” SF Nut 11812 Operators manual box 22409 Bridgeview Manufacturing Inc.
  • Page 37 SMV Sign and Lights Right Hand Side Left Hand Side Bridgeview Manufacturing Inc.
  • Page 38 3/8” x 1” Bolt 13806 3/8” Nylon Lock Nut 10806 ¼” x 1 ¼” Bolt 12375 ¼” Nylon Lock Nut 11664 Left Light 31087 SMV Sign 22411 Break Away Light 34791 SMV Sign Bracket 34792 Right Light 31088 Bridgeview Manufacturing Inc.
  • Page 39 1” x 6 1/2” Bolt 28426 1” Stover Lock Nut 21746 Spring Hose Holder 17967 Hitch (Vertical 7500 lbs) 23404 Safety Chain 3/8” W/D Ring & Latch 23559 21000LB 52” 5000 lb Sidewind Jack Square Mount 31637 Bridgeview Manufacturing Inc.
  • Page 40 Front Full Load Indicator Item # Description ID number QTY. Front Full Load Indicator Flag Horizontal 34739 Bass Bushing (0.75 OD x 0.5" ID x 0.625 L) 33002 Bridgeview Manufacturing Inc.
  • Page 41 3/8" Washer Fender 13773 Full Load Indicator Wire Assembly 34763 ½” x 2 ¾” Bolt 12378 Spring 1” x 0.12” x 8 ½” 11787 ½” Nylon Lock Nut 10241 Cotter Pin (.125 x 1) 21169 Closed Body Turnbuckle 34769 Bridgeview Manufacturing Inc.
  • Page 42 Rear Full load Indicator Item # Description ID number QTY. Flail Bushing 10005 Bridgeview Manufacturing Inc.
  • Page 43 3/8” x 2” Bolt 10279 3/8” Nylon Lock Nut 10806 Cotter Pin (.156 x 1 1/2") 30658 Item # Description ID number QTY. Rear Full Load Indicator Access Panel 34799 ¼” x ¾” Bolt 11809 ¼” Lock Washer 14448 Bridgeview Manufacturing Inc.
  • Page 44 Motor Covers Item # Description ID number QTY. Motor Cover Left 34784 Motor Cover Right 34783 ½” x 1 ¼” Bolt 10240 ½” Nylon Lock Nut 10241 ½” x 1 ¼” Carriage Bolt 11819 Bridgeview Manufacturing Inc.
  • Page 45 34427 DECAL - SPEED LIMIT 2.75" X 4.5" 20MPH 33159 DECAL FEMA 25347 DECAL, HYDRAULIC HOSE GUIDE - 34428 BRX850 - 3 REMOTE Red Reflective Marker, 2 x 9" 28383 Yellow Reflective Marker, 2 x 9" 28384 Bridgeview Manufacturing Inc.

  • Page 46: Hydraulic And Wiring Diagram

    Hydraulic and wiring diagram Pusher Chain Motor Bridgeview Manufacturing Inc.
  • Page 47 Bridgeview Manufacturing Inc.

  • Page 48: Tilt Cylinder

    Tilt Cylinder Bridgeview Manufacturing Inc.

  • Page 49: Loading Arm

    Loading arm Bridgeview Manufacturing Inc.

  • Page 50: Light Diagram

    Light Diagram Bridgeview Manufacturing Inc.

  • Page 51: Notes

    NOTES ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ Bridgeview Manufacturing Inc.
  • Page 52 BRIDGEVIEW MANUFACTURING INC. P.O. BOX 4, HWY 22 GERALD, SASK. S0A 1B0 CANADA Ph: 306-745-2711 Fax: 306-745-3364 Email: bmi@sasktel.net www.bridgeviewmanufacturing.com...
