BALE KING VR581
Hay Rake
Operator's & Parts Manual
Last Updated: April 18, 2019
Bridgeview Manufacturing Inc.
P.O. Box 4
Gerald, Saskatchewan, Canada
S0A 1B0
Phone: 1-306-745-2711
Fax: 1-306-745-3364
Email: bmi@sasktel.net
www.bridgeviewmanufacturing.com
Bridgeview Manufacturing Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BALE KING VR581 and is the answer not in the manual?

Questions and answers

Related Manuals for Bridgeview BALE KING VR581

Summary of Contents for Bridgeview BALE KING VR581

  • Page 1 BALE KING VR581 Hay Rake Operator's & Parts Manual Last Updated: April 18, 2019 Bridgeview Manufacturing Inc. P.O. Box 4 Gerald, Saskatchewan, Canada S0A 1B0 Phone: 1-306-745-2711 Fax: 1-306-745-3364 Email: bmi@sasktel.net www.bridgeviewmanufacturing.com Bridgeview Manufacturing Inc.
  • Page 2 Your Authorized Dealer Your Serial Number The Serial Number is located on the front of the hitch beam behind the manual holder. Bridgeview Manufacturing Inc.

  • Page 3: Table Of Contents

    Rake Wheel Assembly (Standard Tine) ............... 31 4.5.2 Rake Wheel Assembly (Rubber Mounted Tine) ............32 4.5.3 Spring Assembly ......................33 Decals ........................... 34 Hydraulic Components ......................35 4.7.1 Diverter Valve Kit ......................37 Electrical Components ......................38 Bridgeview Manufacturing Inc.

  • Page 4: Introduction

    1 INTRODUCTION Thank you for purchasing your new Bale King hay rake from Bridgeview Manufacturing. With the proper operation and service as outlined in this manual, this rake will provide years of trouble-free operation. The VR581 hay rake is a 12-wheel, V-style rake specially suited for windrowed hay.

  • Page 5: Highway Transport

    550 lb Ensure that road restrictions do not prohibit these dimensions, and that the towing vehicle and hitch are properly rated for the weight (both gross and tongue). DO NOT EXCEED 20 mph (32 km/h) DURING TRANSPORT. Bridgeview Manufacturing Inc.

  • Page 6: Safety Chain & Jack

    To insert the safety locks, raise the rake wheels to their highest position, then insert the pin as shown. Make sure that this is done for both lift rods. Store pin in other hole when not required. Bridgeview Manufacturing Inc.

  • Page 7: Transport Safety Locks

    If this does not help, tighten the brakes further until the problem no longer occurs. IMPORTANT: Ensure that the spring is loosened back off before operation or the rake will be very difficult to turn or back up. Bridgeview Manufacturing Inc.

  • Page 8: Features And Operation

    For faster operating conditions, rake wheel spring pressure can be increased to prevent excess bouncing of the tines. Under normal conditions, the rake wheel pressure should be approximately 15 lb. Bridgeview Manufacturing Inc.

  • Page 9: Adjustments

    (see left) that allow the spring to be loosened or tightened. This should be done only in the case that one wheel is significantly different weight than the others. Excess threads beyond the nut MUST be trimmed to avoid bottoming out. Bridgeview Manufacturing Inc.

  • Page 10: Windrow Width Adjustment

    S/N 3297 & up IMPORTANT: For maximum turning radius, ensure that the tractor's drawbar is in its most extended position. If the pin still does not stick out past the tires, a drawbar extension may be required. Bridgeview Manufacturing Inc.

  • Page 11: Optional Rubber Mounted Tine (Rmt) Rake Wheel

    These wheels are a direct replacement to the standard wheels, and can be replaced at any time (in any quantity). Model Kit # VR581 RMT Rake Wheel - Left 31292 VR581 RMT Rake Wheel - Right 31293 Bridgeview Manufacturing Inc.

  • Page 12: Optional 14-Wheel Extension Kit

    The Bale King hay rake can be outfitted with an extension kit to add 1 rake wheel to each side, allowing the rake to cover a wider area. This kit can be purchased from Bridgeview Manufacturing or a registered dealer, and can be installed in a short amount of time.

  • Page 13: Trouble-Shooting Guide

    Rake Wheel 62" Diameter, 48 Tines Transport Width 10'-6" 12'-4" Height 7'-7" Length 32'-8" Weight (Total) 4200 lb 4600 lb Weight (Tongue) 550 lb Tires Size 9.5L-15SL, 8 ply Pressure 35 psi Wheel Nut Torque 90 ft-lb Bridgeview Manufacturing Inc.

  • Page 14: Maintenance & Lubrication

    Warranty does not cover damaged rims and hubs due to loose wheel bolts. Ensure that the wheel bolt torque is checked after the first hour of use. Tire warranty is covered by the tire manufacturer. See your local tire dealer for service and replacement. Bridgeview Manufacturing Inc.

  • Page 15: Greasing

    NOTE: For ease of greasing, all zerks are accessed from the outside of the rake. The rake should be either fully closed or fully open (including rear width) for best access to fittings (C) and (D). Bridgeview Manufacturing Inc.

  • Page 16: Tine Replacement

    • Insert the replacement tine in the opposite way from removal. • Reinsert bolt and tighten. • PART #16092 RMT Wheels Rubber mounted tines are replaced in pairs without any further disassembly required. Bridgeview Manufacturing Inc.

  • Page 17: Parts Book

    Left and right as used in the parts book is as viewed from the rear of the rake looking in the direction of travel. Parts Book Sections Section Description Gooseneck Hitch Beams and Scissor Rear Frame Boom Arms Rake Wheel Assembly Decals Hydraulics Electrical Bridgeview Manufacturing Inc.

  • Page 18: Gooseneck Assembly

    4.1 Gooseneck Assembly Bridgeview Manufacturing Inc.
  • Page 19 Select the correct version before ordering parts. * NOTE: Includes (10)(11)(12) NSS = Not Sold Separately Description Hitch Tongue 22440 29785 Hitch Clevis Option * 25540 29786 Hitch Clevis 22441 Hitch Clevis Bolt 26406 Hitch Clevis Nut 11823 Bridgeview Manufacturing Inc.

  • Page 20: Transport Lock

    Flat Washer, 3/8" 11667 Tee-Handle Pin 21246 Nut, 3/8" Nylon Lock 10806 Bolt, 1 x 3-1/2" 25663 Clevis Pin, 5/8 x 2-3/4" 21829 Nut, 1" Stover Lock 21746 Lynch Pin, 3/16 x 1-1/4" 13233 Bolt, 5/8 x 3" 20907 Bridgeview Manufacturing Inc.

  • Page 21: Hitch Beam & Scissor Assembly

    4.2 Hitch Beam & Scissor Assembly 4.2.1 Scissor Components Front Bridgeview Manufacturing Inc.
  • Page 22 Pin, 1-1/8 x 8-1/2" 26449 Nut, 1/4" Nylon Lock 11664 Flat Washer, 1-1/8" 26450 Pin, 1 x 3-3/4" Usable 20788 Roll Pin, 1/4 x 2" 15872 Flat Washer, 1" 14472 Slider Plate Front 22242 Cotter Pin, 3/16 x 1-1/2" 10072 Bridgeview Manufacturing Inc.

  • Page 23: Scissor Components Rear Vr581

    4.2.2 Scissor Components Rear VR581 Bridgeview Manufacturing Inc.
  • Page 24 Hyd. Cylinder, 2.5 x 20" 17328 Slider Side Plate 22246 Seal Kit 16396 Plastic Slider 18011 Bulkhead Cover Plate 22234 Elevator Bolt, 1/4 x 1" 17970 Grommet 21428 Nut, 1/4" Nylon Lock 11664 Lock Washer, 9/16" 23369 Bridgeview Manufacturing Inc.

  • Page 25: Width Indicator

    Nut, 3/8" Nylon Lock 10806 Bolt, 1/2 x 2-1/4" 11820 Width Indicator Decal 23011 Nut, 1/2" Nylon Lock 10241 # S/N VR3373 & below. If a longer needle is desired, both parts 3 & 4 must be replaced. Bridgeview Manufacturing Inc.

  • Page 26: Rear Frame Assembly

    U-bolt, 3/4 x 5 x 6" 16091 Left Light 22968 Nut, 3/4" Serrated Flange 16076 Right Light 22969 Bolt, 5/8 x 1-3/4" 12379 Bolt, 1/4 x 1" 11810 Nut, 5/8" Serrated Flange 11614 Nut, 1/4" Nylon Lock 11664 SMV Sign Rear Axle Bridgeview Manufacturing Inc.

  • Page 27: Rear Axle

    Dust Cap 16308 * NOTE: Hub (14) comes with grease zerk (16) and bearing cups (13,15) installed # NOTE: See your local tire dealership for replacement or repairs Quantities are per assembly as shown. Left side shown. Bridgeview Manufacturing Inc.

  • Page 28: Slow Moving Vehicle (Smv) Sign Kit

    Nut, 1/4" Serrated Flange Lock Washer, 5/16" Sign Mounting Bracket Tapered Mounting Bracket Plastic Sign Carriage Bolt, 5/16 x 5/8" Screw, 1/4 x 5/8" * NOTE: Individual parts not sold separately. Not all parts in kit are used. Bridgeview Manufacturing Inc.

  • Page 29: Boom Arm Assembly

    4.4 Boom Arm Assembly 4.4.1 Boom Arm Assembly Bridgeview Manufacturing Inc.
  • Page 30 20888 Roll Pin, 1/4 x 2" 15872 Grease Zerk 16364 Side Caster Support 581 24502 Hose Clamp 28585 Riser Arm 581 Left 22237 Hose Clamp Top 22182 Riser Arm 581 Right 22238 Bolt, 5/16 x 1-3/8" 22183 Bridgeview Manufacturing Inc.

  • Page 31: Lift Rod Details

    28843 Hairpin 16363 Flat Washer, 1" 14472 Lift Rod Bushing 16099 Cotter Pin, 3/16 x 1-1/2" 10072 * NOTE: Comes with clevis (3) and nut (4) @ NOTE: Comes with jam nuts # NOTE: Comes with hairpin Bridgeview Manufacturing Inc.

  • Page 32: Caster Wheel And Hub

    # NOTE: See local tire dealership for replacement or repairs Quantities are per assembly as shown. Left side shown. For right side, install fork opposite direction. Wheel nuts installed with cone IN, air valve same side as wheel nuts. Bridgeview Manufacturing Inc.

  • Page 33: Rake Wheel And Arm

    Nut, 1/2" Stover Lock 14393 * NOTE: Hub (11) comes with wheel studs (20), grease zerk (13), and bearing cups (12) installed. Quantities are per assembly as shown. Left side shown. Torque wheel nuts to 90 ft-lb Bridgeview Manufacturing Inc.

  • Page 34: Rake Wheel Assembly (Standard Tine)

    Complete Right Wheel Outer Ring 22055 Center Disk Left 22053 Nut, 3/8" Stover Flange 17844 Center Disk Right 22731 Carriage Bolt, 3/8 x 1" 15718 Wind Guard 22054 NOTE: Left hand shown. Quantities are for each wheel. Bridgeview Manufacturing Inc.

  • Page 35: Rake Wheel Assembly (Rubber Mounted Tine)

    RMT Wheel Frame 31291 Bolt, 1/4 x 1” Truss-Head 32106 Wind Guard 32106 Washer, 5/16” Fender 32148 RMT Tine 31234 Nut, 1/4” 12904 Bolt, 3/8 x 1” 13806 NOTE: Left hand shown. Quantities are for each wheel. Bridgeview Manufacturing Inc.

  • Page 36: Spring Assembly

    10240 Spring Slide Rod 16493 Roll Pin, 3/16 x 1-1/4" 10302 Flat Washer, 5/8" 16652 Lock Washer, 5/8” 10276 Nut, 5/8” Nylon Lock Rake Wheel Spring 16095 10364 Spring Retainer Block 16100 NOTE: Quantities are per assembly. Bridgeview Manufacturing Inc.

  • Page 37: Decals

    Orange Reflector 28386 FEMA 25347 "BALE KING" 22162 Speed / Transport Lock 31304 "VR581" 26353 Wheel Torque Reminder 28385 "Bridgeview" Left 24554 Width Indicator 23011 "Bridgeview" Right 24552 Red Reflector 28383 Hydraulic Functions 31307 Amber Reflector 28384 Bridgeview Manufacturing Inc.

  • Page 38: Hydraulic Components

    4.7 Hydraulic Components Bridgeview Manufacturing Inc.
  • Page 39 1/4 x 54” OAL, 6FJX-6FJX Extension Kit * 14 wheel Only * 3/8 x 40” OAL, 6FJX-6MJ 26457 1/4 x 40” OAL, 6FJX-6MJ 21374 Diverter Kit (26357) 1/4” x 26” OAL, 6FJX-6FJX90 26460 10MB-6MJ 11739 10MB-6MJ45 22722 Bridgeview Manufacturing Inc.

  • Page 40: Diverter Valve Kit

    13561 Rake Control Box Decal 23296 4-pin Trailer Plug 24691 5/16 x 3" Socket Head 11783 4-pin Tractor Plug 24690 5/16" Serrated Flange Nut 11814 Bolt *NOTE: Control box (4) comes with switch (11), and plugs (12),(13). Bridgeview Manufacturing Inc.

  • Page 41: Electrical Components

    4.8 Electrical Components Bridgeview Manufacturing Inc.
  • Page 42 Bridgeview Manufacturing Inc.
