Page 1 *SHOWN WITH OPTIONAL 3 BALE KIT BALE KING 5300 Bale Processor Operator's & Parts Manual Last Updated: August 2021 Bridgeview Manufacturing Inc. P.O. Box 4 Gerald, Saskatchewan, Canada S0A 1B0 Phone: 1-306-745-2711 Fax: 1-306-745-3364 Email: bmi@sasktel.net www.bridgeviewmanufacturing.com...
Page 2 Your Authorized Dealer Your Serial Number The Serial Number is located the front tub panel, next to the operator manual box. Page ii...
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................1 Safety Precautions ......................1 Safety Decals ........................2 Transportation ........................5 FEATURES & OPERATION .....................8 Power Take-off ........................ 8 Hydraulics ........................12 Implement Tongue ......................15 Rear Forks ........................15 Loading Bales ........................ 17 Hoop Grate Adjustment ....................18 Deflector ........................
Page 4 Slow Moving Vehicle (SMV) Sign Kit ................61 Decals ..........................62 Three Bale Kit Option ....................64 Three Bale Kit Left Arm (Series 1) ..............65 Three Bale Kit Lockout Mechanism (Series 1) ............ 67 Three Bale Kit Center (Series 1) ................69 Three Bale Kit Right Arm (Series 1) ..............
Page 5: Introduction
Bale King will provide you with years of trouble-free operation. This is a complete safety, operation and parts manual for the Bale King 5300. The manual covers in detail how to safely and effectively use your new processor. The procedures outlined in this manual should be followed to ensure safe operation and longevity of your machine.
Page 6: Safety Decals
Safety Decals Power Take-off The operator must obey all safety labels and must maintain the proper shielding. A high percentage of drive-line injuries occur when safety shielding is missing or not functioning properly. DANGER: Contact with a rotating drive-line can cause serious injury or death. Page 2...
Page 7 Discharge DANGER: Do not stand on the discharge side of the machine while it is in operation. Page 3...
Page 8 Rear Fork Lift Area DANGER: Stand clear of lift area. Do not stand under the forks unless safety locks are installed. Deflector Safety Lock: Unlock for Operation, Lock for Transport and Storage. Page 4...
Page 9: Transportation
Transportation The Bale King 5300 can be safely towed on public roads, provided the following precautions are met: Weights and Dimensions • The towing vehicle must be suitable for the weight being towed. • Check with local authorities regarding transport on public roads. Follow all applicable laws and regulations.
Page 10 Safety Chain, Jack, PTO, and Hydraulics • ALWAYS ensure that the safety chain is properly installed. There should be enough slack to allow for turning, but not so much that the chain drags on the ground. • Ensure that the jack is installed in its storage position on the front tub wall. •...
Page 11 Safety Locks • Lift the forks all the way up. If carrying a bale, only lift enough for appropriate ground clearance. If empty, install both fork cylinder locks as shown. • If applicable, the 3-bale clamp should be closed. • If possible, the deflector should be in the folded position. •...
Page 12: Features & Operation
Bridgeview Manufacturing Inc. FEATURES & OPERATION Power Take-off The Bale King bale processor has a PTO shaft which is splined on both ends. The implement end uses a 1-3/4"-20 spline with wedge lock bolts. Install onto the gearbox and tighten the wedge bolts.
Page 13 Bridgeview Manufacturing Inc. Shear Bolt All new Bale King processors are equipped with a shear bolt clutch located at the implement end of the PTO shaft. The correct size shear bolt is 3/8 x 2” Fine Thread Grade 5 with Stover Lock Nut.
Page 14 Bridgeview Manufacturing Inc. PTO Use and Maintenance Shut OFF the tractor engine and remove the key before doing any maintenance on the machine. Use ONLY genuine Weasler parts when replacing any worn or damaged PTO components. Length: Confirm the minimum and maximum working lengths of the drive-line.
Page 15 Bridgeview Manufacturing Inc. BEFORE ATTEMPTING ANY REPAIR PROCEDURES, ALWAYS USE APPROPRIATE EQUIPMENT SUCH AS SAFETY GLASSES, SAFETY SHOES, AND GLOVES Shield Removal: • To remove the shield, pop out the red snap, then rotate the guard on the bearing to line up the three tabs with the openings and pull it off away from the knuckle joint.
Page 16: Hydraulics
Long Yellow Lift deflector An optional diverter kit (BMI # 25091) is available to allow the Bale King 5300 to run using only two sets of hoses. The function is then determined by a control box, mounted in the cab of the tractor.
Page 17 Clamp bale An optional grain tank kit is available to allow the Bale King 5300 to carry 40 bushels of grain on the side of the machine (see page 24). If this kit is installed, additional motors are added to the hydraulic functions.
Page 18 Bridgeview Manufacturing Inc. If both kits are installed on the machine, the hydraulic setup is as shown below: 5300XTR – 2 Remote “GRAIN TANK” “AUXILIARY” “FORK” “DEFLECTOR” Control Box Long Blue Discharge grain Clamp bale Lift rear fork Lift deflector...
Page 19: Implement Tongue
Bridgeview Manufacturing Inc. Implement Tongue The adjustable hitch on the Bale King features a cast single tongue with hammer strap insert. This allows for use with tractors equipped with a hammer strap or with a single drawbar. It also allows the machine to move independently over rough terrain without bending the draw pin.
Page 20 Bridgeview Manufacturing Inc. For transport, and safety when working under the forks, install the red safety locks onto the lift cylinder. The Bale King 5300 is equipped with self-catching safety locks that do not require a pin to lock in place. To install, lift the fork all the way...
Page 21: Loading Bales
Bridgeview Manufacturing Inc. Loading Bales When loading bales into your Bale King bale processor, the following procedure should be followed: • Position the tractor and the Bale King so as to be lined up to back straight into the row of bales.
Page 22: Hoop Grate Adjustment
Bridgeview Manufacturing Inc. Hoop Grate Adjustment There are eight adjustment settings for the hoop grate on the bale processor. These settings determine the rate of feed of the bale you are processing and the how fine the cut will be. Move the handle “UP” for a more aggressive cut.
Page 23: Deflector
The Bale King 5300 deflector will bunk feed to a distance of 35” from the tire when in the lowest position. When the deflector is not folded, the transport width of the machine is 9’-10”.
Page 24 For transport and storage, the deflector lock should be put in place by swinging the lock as shown and fastening with a lynch pin. The Bale King 5300 deflector also has the ability to fold for more compact long term storage or long distance transport.
Page 25: Agitators
Bridgeview Manufacturing Inc. Agitators The Bale King is equipped with a flow divider/combiner and two hydraulic motors for turning the bale. Once the main rotor is turning at full speed the bale can be turned in either direction to begin processing. The faster the bale is turned in either direction, the faster it will be processed.
Page 26: Optional Diverter Kit
Bridgeview Manufacturing Inc. Optional Diverter Kit The Bale King 5300 processor has an optional diverter kit (BMI # 25091) which allows it to operate using only 2 hydraulic remotes. The fork and deflector functions are then controlled by a cab-mounted switch box. This box must be wired up to the tractor's electrical system. You may use the provided plug to plug into the accessory outlet.
Page 27: Optional Fine Chop Kit
Optional Fine Chop Kit The Bale King 5300 processor has an optional fine chop knife kit (BMI # 32117) available to go into the lower tub area. This option is available if you require a finer cut on the material which you are processing such as slough hay and silage bales.
Page 28: Optional Total Ration Grain Tank (5300Tr)
Optional Total Ration Grain Tank (5300TR) The Bale King 5300 has an available 40-bushel grain tank, which allows grain to be discharged on top of a windrow of processed hay, or independently out the right side of the machine. This bolt- on kit changes the processor to a 5300TR (Total Ration).
Page 29: Optional 3 Bale Kit (5300X)
Bridgeview Manufacturing Inc. Optional 3 Bale Kit (5300X) The Bale King 5300 has an available attachment kit which increases the carrying capacity of the processor by 50%, while maintaining the easy maneuverability of the two-bale processor. The attachment kit stores the second loaded bale behind the first and above the third in a set of powerful hydraulic clamps.
Page 30 Bridgeview Manufacturing Inc. 3 Bale Kit Loading Sequence: 1. Position the tractor and the Bale King so as to be lined up to back straight into the row of bales. 2. Ensure the bale clamp is opened fully. 3. When close to the bale, lower the forks...
Page 31 Bridgeview Manufacturing Inc. 8. Once the bale is in the appropriate location, close the clamp fully and then lower the lifting fork. 9. Back under the third bale and lift the forks until the third bale is lightly supporting the second bale. You will see when to stop lifting as the clamped bale will tilt forward slightly.
Page 32 Bridgeview Manufacturing Inc. Lockout Mechanism Adjustment and Setting The 3 Bale Kit is equipped with a lockout mechanism that prevents damage to the clamps if the fork is lifted before the clamps are released. The lockout mechanism works by allowing the clamps to “break-away”...
Page 33: Optional Back-Up Camera
Bridgeview Manufacturing Inc. Optional Back-up Camera The Bale King 5300 processor has an optional back-up camera to provide increased visibility while loading bales. This is especially helpful when combined with a 3-bale kit. There are two versions of the kit.
Page 34: Service And Maintenance
Bridgeview Manufacturing Inc. SERVICE AND MAINTENANCE Greasing Locations Lubricating the Bale King bale processor should be done on a regular basis. Every 150 bales Bale Fork Pivot 3-5 pumps 3-5 pumps 3-Bale Kit Arm Pivot * 3-5 pumps Rotor Gearbox...
Page 35 Bridgeview Manufacturing Inc. PTO/Driveline After storage for long periods of time, lubricate and check the function of every driveline component before operating. Failure to grease all the joints will VOID warranty. Gearbox There is one grease zerk on the front of the gear box. Apply 3-5 pumps of good quality grease every 150 bales.
Page 36 Bridgeview Manufacturing Inc. Cylinder Maintenance The hydraulic cylinders are easily removed for repair or maintenance simply by: • Lowering the fork (or deflector) to the down position and unhooking the hydraulic lines. Be sure there is no pressure on the lines and mark the line locations so there is no confusion when reinstalling the cylinders.
Page 37: Tires
Bridgeview Manufacturing Inc. Tires Wheel bearings should be inspected annually for adjustment and lubricated annually. Inspect more often for extensive traveling. • To tighten the wheel bearings, lift up each wheel (one at a time) until the wheel spins freely.
Page 38: Twine Removal
• Loose straw and hay remaining in the machine may ignite causing a fire in the processor. • Excessive buildup of melted plastic. • Dry out bushings causing them to wear prematurely. NOTE: Bridgeview Manufacturing Inc. VOIDS warranty for any damage caused by twine burning in the processor. Page 34...
Page 39: Gearbox And Flail Replacement Procedure
Inspect the bolt, bushing, and the flail for wear. If wear is excessive, replace with new parts. Bridgeview Manufacturing Inc. recommends when changing flails to change in PAIRS (opposite each other). Processing bales with broken flails causes the rotor to be out of balance and excessive vibration may cause machine deterioration.
Page 40: Trouble-Shooting Guide
Bridgeview Manufacturing Inc. Trouble-shooting Guide Problem Possible Cause Remedy • Idle tractor to engage PTO then bring up to full Engaging PTO at high engine speed or too quickly operating speed • Feather PTO lever into position • Cut twine off rotor...
Page 41: Features And Specifications
Bridgeview Manufacturing Inc. Features and Specifications Dimensions: 5300 5300TR 5300X 5300XTR Overall Weight 4400 lb 5200 lb 5070 lb 5700 lb Drawbar Weight 1250 lb 1540 lb 1320 lb 1570 lb 8’-7” 8’-7” 8’-7” 8’-7” Overall Height 19’-3” 19’-3” 19’-3”...
Page 42: Parts Manual
Bridgeview Manufacturing Inc. PARTS MANUAL Machine Overview Item # Description Item # Description Jack & Hitch Deflector and Hose Cover Wheels & Hub Hose and Manual Holder Inner Tub Components & Drive Decals Rear Tub Components Options Rear Forks Diverter Control Box...
Page 43: Jack & Hitch
Bridgeview Manufacturing Inc. Jack & Hitch DESCRIPTION PART # Jack, 5000 lb * Comes with pin * 31637 Nut, 3/4" Stover Lock 11823 Hitch Tongue 29785 Bolt, 3/4" x 5-3/4" 10802 Hitch Clevis Kit 29786 Nut, 1/2" Nylon Lock [S/N 7168 & Down] 10241 Nut, 1”...
Page 44: Wheels & Hub
Bridgeview Manufacturing Inc. Wheels & Hub DESCRIPTION PART # Wheel Stud, 9/16 x 1-3/4" NF 10347 Rim, 16.1x14, 8 on 8" 10354 Tire, 16L-16.1 8 ply * See your local tire dealer * Spindle Assembly *See breakdown* 29679 Stover Lock Nut, 9/16”...
Page 45: Spindle
Bridgeview Manufacturing Inc. Spindle DESCRIPTION PART # Complete Assembly 29679 6500lb Spindle 29730 Seal, 2" ID 10344 Inner Bearing Cone, 1-3/4" ID 10345 Inner Bearing Race 10349 Hub Housing * Includes #4 & #6 * 10343 Outer Bearing Race 10346 Outer Bearing Cone, 1-3/8"...
Page 46: Rotor & Drive Components
Bridgeview Manufacturing Inc. Rotor & Drive Components DESCRIPTION PART # Rotor Shaft Cap 17380 Bolt, 5/8" x 1-3/4" NF Gr. 8 10274 Lock Collar 10268 Rotor Bearing * Includes # 3 & 6 * 10221 Nut, 5/8" NF Serrated Flange Gr. 8 15398 Grease Zerk, 1/8"...
Page 47: Gearbox
Bridgeview Manufacturing Inc. Gearbox Page 43...
Page 48 Bridgeview Manufacturing Inc. Gearbox DESCRIPTION PART # Complete Gearbox Assembly 22158 Housing End Cap Output Gear Input Gear Output Shaft Input Shaft Bearing (32012) 60mm 10496 Bearing (32009) 45mm 10497 Seal, 45 x 60 x 8 24013 Seal, 60 x 100 x 10 10498 Pipe Plug, 3/8"...
Page 49: Pto Shaft
24983 NOTE: Ensure that the PTO shaft on the machine is correct to the drawings below. Equal length CV cross (4.19") with bearing cup diameter 1.38". If the damaged PTO has different dimensions, consult the Bridgeview Manufacturing website. Page 45...
Page 50: Grates
Bridgeview Manufacturing Inc. Grates DESCRIPTION PART # Bolt, 1" x 2-1/2" 21820 Grate Pivot Bushing 22417 Flat Washer, 1" 14472 Nut, 1" Stover Lock 21746 Grate Assembly 29944 Grate Adjustment Cam 31720 Bolt, 1/2” x 2” 10322 Nut, 3/8" Serrated Flange...
Page 51: Agitators
Bridgeview Manufacturing Inc. Agitators DESCRIPTION PART # Agitator Shaft Cap 17381 Bolt, 1/2" x 1-1/2" 10174 Lock Collar 10040 Grease Zerk, 1/8" NPT Straight 10270 Agitator Bearing * Includes # 3 & 4 * 10038 Nut, 1/2" Serrated Flange 10273...
Page 52: Rear Tub Components
Bridgeview Manufacturing Inc. Rear Tub Components Rear Deflector / Lights DESCRIPTION PART # QTY/SIDE Light Assembly, Right Hand 31088 Light Assembly, Left Hand 31087 Bolt, 1/2" x 1 1/4" 10240 Flat Washer, 1/2" 11668 Nut, 1/2" Serrated Flange 10273 Bolt, 1/4” x 3/4”...
Page 53: Wing And Bale Slide
Bridgeview Manufacturing Inc. Wing and Bale Slide DESCRIPTION PART # QTY/SIDE Bolt, 3/8" x 1" 13806 Nut, 3/8" Serrated Flange 10271 Nut, 1/2" Serrated Flange 10273 Wing 31692 Flat Washer, 1/2" 11668 Bolt, 1/2" x 1 1/4" 10240 Bale Slide 31703 Flat Washer, 3/8"...
Page 54: Front Rack
Bridgeview Manufacturing Inc. Front Rack S/N BK7361 & lower DESCRIPTION PART # Bolt, 1/2" x 1-1/4" 10240 Flat Washer, 1/2" 11668 Front Rack 31730 Nut, 1/2" Serrated Flange 10273 Front Rack Grating 32479 Nut, 5/16” Serrated Flange 11814 Bolt, 5/16” x 3/4” Button Head 32513 Bolt, 5/16”...
Page 55 Bridgeview Manufacturing Inc. S/N BK7362 & above DESCRIPTION PART # Bolt, 1/2" x 1 1/4" 10240 Flat Washer, 1/2" 11668 Front Rack 31730 Nut, 1/2" Serrated Flange 10273 Front Rack Grating 32479 Nut, 5/16” Serrated Flange 11814 Bolt, 5/16” x 3/4” Button Head...
Page 56: Rear Forks
Bridgeview Manufacturing Inc. Rear Forks DESCRIPTION PART # Square Rear Fork Frame [S/N BK7361 & below] 31766 Tapered Rear Fork Frame [S/N BK7362 & above] 33759 Rear Fork Pivot Pin 22006 Bolt, 3/8" x 2-3/4" 20908 Nut, 3/8" Nylon Lock...
Page 57: Deflector & Hose Cover
Bridgeview Manufacturing Inc. Deflector & Hose Cover S/N BK7168 & Down Page 53...
Page 58 Bridgeview Manufacturing Inc. Deflector & Hose Cover - S/N BK7168 & Down DESCRIPTION PART # Bolt, 3/8" x 1" 13806 Deflector Rubber Channel 22423 Deflector Rubber 10477 Nut, 3/8" Nylon Lock 10806 Carriage Bolt, 3/8" x 3/4" 14072 Deflector Flipper Pin 24464 Nut, 3/8"...
Page 59 Bridgeview Manufacturing Inc. Deflector & Hose Cover - S/N BK7169 & up Page 55...
Page 60 Bridgeview Manufacturing Inc. Deflector & Hose Cover - S/N BK7169 & up DESCRIPTION PART # Bolt, 3/8" x 1" 13806 Deflector Rubber Channel 22423 Deflector Rubber 10477 Nut, 3/8" Nylon Lock 10806 Carriage Bolt, 3/8" x 3/4" 14072 Deflector Flipper Pin 24464 Nut, 3/8"...
Page 61: Front Tub Components
Bridgeview Manufacturing Inc. Front Tub Components DESCRIPTION PART # Flow Divider Valve 25778 Bolt, 1/4 x 5” 25951 Nut, 1/4” Serrated Flange 11812 PTO Cradle 31760 Bolt, 3/8 x 4” 14379 Nut, 3/8” Nylon Lock 10806 Threaded Pin 13231 Nut, 1/2” Serrated Flange...
Page 62: Hose Holder And Manual Holder
Bridgeview Manufacturing Inc. Hose Holder and Manual Holder DESCRIPTION PART # Hose Holder 31740 Hose Holder Pin 31745 Hairpin, 3/32 x 5/8” 11786 Bolt, Carriage 3/8" x 1" 15718 Nut, 3/8" Serrated Flange 10271 Nut, 1/4” Nylon Lock 11664 Manual Holder Bracket [ S/N BK7361 &...
Page 63: Hose Clamps
Bridgeview Manufacturing Inc. Hose Clamps Page 59...
Page 64 Bridgeview Manufacturing Inc. Hose Clamps…continued DESCRIPTION PART # Hose Holder 31740 Hydraulic Hose Clamp, 1/2” 21561 Hydraulic Hose Clamp, 3/8” 22180 Hydraulic Hose Clamp, 1/4” 22181 Hydraulic Hose Clamp Cap, Large 21725 Hydraulic Hose Clamp Cap, Small 22182 Bolt, 5/16” x 3-1/2”...
Page 65: Slow Moving Vehicle (Smv) Sign Kit
Slow Moving Vehicle (SMV) Sign Kit S/N BK7361 & below S/N BK7362 & above NOTE: Only the parts shown above are used on the Bale King 5300. Additional parts are included in the SMV sign kit which are not required. DESCRIPTION...
Page 66: Decals
Bridgeview Manufacturing Inc. Decals Page 62...
Page 67 Bridgeview Manufacturing Inc. DECALS DESCRIPTION PART # “BALE KING” 32804 “5300” 31657 “DANGER”, PTO 12219 “DANGER”, Discharge 12230 “DANGER”, Stand Clear of Lift 12229 AMC Member 12239 FEMA Member 25347 Wheel Torque Reminder 28385 Deflector Safety Lock 22292 Red Reflector...
Page 68: Three Bale Kit Option
Bridgeview Manufacturing Inc. Three Bale Kit Option Two different versions of the three bale kit have been produced. Check the serial number of your machine to determine which version to order. The primary difference is the lockout mechanism, though most other parts different.
Page 69: Three Bale Kit Left Arm (Series 1)
Bridgeview Manufacturing Inc. Three Bale Kit Left Arm (Series 1) Page 65...
Page 70 Bridgeview Manufacturing Inc. Three Bale Kit Left Arm (Series 1) DESCRIPTION PART # Nut, 5/16” Serrated Flange 11814 SMV Adapter 31896 Bolt, 5/16” x 3/4” Carriage 11662 Grease Zerk 16364 3 Bale Kit Left Arm 31852 Arm Pin 31660 Nut, 1/2” Nylock 16741 Nut, 1/2”...
Page 71: Three Bale Kit Lockout Mechanism (Series 1)
Bridgeview Manufacturing Inc. Three Bale Kit Lockout Mechanism (Series 1) Page 67...
Page 72 Bridgeview Manufacturing Inc. Three Bale Kit Lockout Mechanism (Series 1) DESCRIPTION PART # 3 Bale Kit Rocker 31934 Bolt, Shoulder 1/2” x 2-1/4” x 3/8” 31358 3 Bale Kit Spring Guide Rotator 31920 3 Bale Kit Upper Spring Guide 31915...
Page 73: Three Bale Kit Center (Series 1)
Bridgeview Manufacturing Inc. Three Bale Kit Center (Series 1) DESCRIPTION PART # 3 Bale Kit Timing Bar [S/N 7168 & Down] 32202 3 Bale Kit Timing Bar [S/N 7169 - 7361] 32236 Bolt, 3/4 x 3” 27451 Nut, 1/2” Stover Lock Fine Thread...
Page 74: Three Bale Kit Right Arm (Series 1)
Bridgeview Manufacturing Inc. Three Bale Kit Right Arm (Series 1) DESCRIPTION PART # Nut, 1/2” Stover Lock Fine Thread 32153 Tub Mount 31873 Bolt, 1/2” x 1-1/4” Fine Thread 32152 3 Bale Kit Right Arm 31854 Grease Zerk 16364 Arm Pin 31660 Nut, 1/2”...
Page 75: Three Bale Kit Left Arm (Series 2)
Bridgeview Manufacturing Inc. Three Bale Kit Left Arm (Series 2) Page 71...
Page 76: Three Bale Kit Center (Series 2)
Bridgeview Manufacturing Inc. Three Bale Kit Center (Series 2) Page 72...
Page 77: Three Bale Kit Right Arm (Series 2)
Bridgeview Manufacturing Inc. Three Bale Kit Right Arm (Series 2) Page 73...
Page 78 Bridgeview Manufacturing Inc. Three Bale Kit (Series 2) DESCRIPTION PART # Left Arm 33328 Right Arm 33329 Torsion Bar 33330 Torsion Bar Mount 33331 Rear Support Left 33332 Rear Support Right 33333 Cylinder Base Mount 33334 Cylinder Mount Tub Adaptor...
Page 79: Total Ration Grain Tank Option
Bridgeview Manufacturing Inc. Total Ration Grain Tank Option Item # Description Tank Front Page 76 Tank Rear Page 78 Cross Auger Page 80 Page 82 Page 75...
Page 80: Total Ration Tank Front
Bridgeview Manufacturing Inc. Total Ration Tank Front Page 76...
Page 81 Bridgeview Manufacturing Inc. Total Ration Tank Front DESCRIPTION PART # Total Ration Grain Tank 30199 Bolt, 5/16” x 3/4” 20903 Tank Cleanout Cover 30237 Nut, 5/16” Serrated Flange 11814 Nut, 5/16” Nylock 11815 Bolt, 5/16” x 1” Carriage 17884 Bearing, 3-Bolt Pressed Flange Housing 10368 Bearing, 3/4”...
Page 82: Total Ration Tank Rear
Bridgeview Manufacturing Inc. Total Ration Tank Rear Page 78...
Page 83 Bridgeview Manufacturing Inc. Total Ration Tank Rear DESCRIPTION PART # Total Ration Grain Tank 30199 5300 SMV Sign Mount *5300 only S/N BK7253 & below 30389 Flow Control Valve 10455 Bolt, 1/4 x 2-3/4” *S/N BK7253 & below 11811 Bolt, 1/4 x 2-1/2”...
Page 84: Total Ration Cross Auger
Bridgeview Manufacturing Inc. Total Ration Cross Auger Page 80...
Page 85 Bridgeview Manufacturing Inc. Total Ration Cross Auger DESCRIPTION PART # Cross Auger Pipe 30179 Cross Auger Half Clamp 30401 Bolt, 3/8” x 1” 13806 Nut, 3/8” Stover Lock 17586 Bolt, 5/16” x 1.75” 21726 Hydraulic Hose Clamp Cap, Large 21715 Hydraulic Hose Clamp, 1/2”...
Page 86: Total Ration Tank Lid
Bridgeview Manufacturing Inc. Total Ration Tank Lid DESCRIPTION PART # Grain Tank Lid 30165 Bolt, 1/2” x 1-1/4” 10240 Washer, 1/2” Fender 10238 Bushing, 1/2” ID x 1.250” OD 10239 Nut, 1/2” Stover Lock 14393 Nut, 5/16” Nylon Lock 11815 Bolt, 3/8”...
Page 87: Fine Chop Option
Bridgeview Manufacturing Inc. Fine Chop Option Page 83...
Page 88 Bridgeview Manufacturing Inc. Fine Chop Option DESCRIPTION PART # Fine Chop Cover * IF NO FINE CHOP INSTALLED * Fin Bolt, 3/8" x 3/4" 10807 Fine Chop Cover Plate 22438 Nut, 3/8" Serrated Flange 10271 Fine Chop Kit * Optional * 32117 Bolt, 3/8"...
Page 89: Twine Cutter Option
Bridgeview Manufacturing Inc. Twine Cutter Option DESCRIPTION PART # Twine Cutter Kit 17686 Twine Cutter Handle Kit Twine Cutter Holder Kit 21549 Rubber Handle Cap 17587 Twine Cutter Handle 20862 Bolt, 1/4" x 3/4" Truss Head 17638 Nut, 1/4" Serrated Flange...
Page 90: Back-Up Camera Option
Bridgeview Manufacturing Inc. Back-up Camera Option DESCRIPTION PART # Back-up Camera Kit - Standard Back-up Camera Kit - Pro Camera Mounting Bracket 32618 Camera Mounting Strap 32617 * Back-up Camera – Standard 32640 * Back-up Camera – Pro 32639 Bolt, #10 x 1/2”...
Page 91: Hydraulic And Electrical Schematics
Bridgeview Manufacturing Inc. HYDRAULIC AND ELECTRICAL SCHEMATICS Machine Marker Function Page # Hydraulic Components Hydraulic Fittings Hydraulic Hoses Long Red Turn Agitators Clockwise 5300 Long Blue Lift Rear Fork 3 Remote Long Yellow Lift Discharge Deflector Long Red Turn Agitators Clockwise...
Page 92: Hydraulic Schematics
Bridgeview Manufacturing Inc. Hydraulic Schematics FRONT PANEL – AGITATORS Page 88...
Page 93 Bridgeview Manufacturing Inc. FRONT PANEL – 3 REMOTE Page 89...
Page 94 Bridgeview Manufacturing Inc. FRONT PANEL – 2 REMOTE Page 90...
Page 95 Bridgeview Manufacturing Inc. FRONT PANEL – 1 OPTION, 4 REMOTE Page 91...
Page 96 Bridgeview Manufacturing Inc. FRONT PANEL – 1 OPTION 3 REMOTE Page 92...
Page 97 Bridgeview Manufacturing Inc. FRONT PANEL – 1 OPTION 2 REMOTE Page 93...
Page 98 Bridgeview Manufacturing Inc. FRONT PANEL – 2 OPTION, 4 REMOTE Page 94...
Page 99 Bridgeview Manufacturing Inc. FRONT PANEL – 2 OPTION 3 REMOTE Page 95...
Page 100 Bridgeview Manufacturing Inc. FRONT PANEL – 2 OPTION 2 REMOTE Page 96...
Page 101 Bridgeview Manufacturing Inc. REAR FORK – S/N 7362 & UP Page 97...
Page 102 Bridgeview Manufacturing Inc. REAR FORK AND THREE BALE KIT – S/N 7362 & UP Page 98...
Page 103 Bridgeview Manufacturing Inc. REAR FORK – S/N 7361 & BELOW Page 99...
Page 104 Bridgeview Manufacturing Inc. REAR FORK AND THREE BALE KIT – S/N 7361 & BELOW Page 100...
Page 105 Bridgeview Manufacturing Inc. TR GRAIN TANK KIT Page 101...
Page 106 Bridgeview Manufacturing Inc. HYDRAULIC COMPONENTS DESCRIPTION PART # Hydraulic Cylinder – 3 Bale Kit Arms 30126 *Seal Kit 17609 WS230 Hydraulic Motor – Tank Auger 31172 Hydraulic Cylinder - Rear Forks 21717 * Seal Kit 20807 * Stopper Kit 21860...
Page 107 Bridgeview Manufacturing Inc. HYDRAULIC FITTINGS DESCRIPTION PART # Adaptor, 10MB-8MJ 10161 Adaptor, 10MB-8MJ90 12169 Adaptor, 10MB-8MJ45 23844 Adaptor, 10MB-6MJ 11739 Adaptor, 10MB-6MJ45 22722 Adaptor, 8MBR-8MJT 22159 Adaptor, 8MB-6MJ 11740 Adaptor, 8MB-6MJ90 10200 Adaptor, 8MB-4MJ *not required if hose has 8MB end*...
Page 108 Bridgeview Manufacturing Inc. HYDRAULIC HOSES DIAM. LENGTH ENDS 1/2" 170" OAL 8FJX-8MB 1/2” 33” OAL 8FJX-8MB 1/2" 125" OAL 8FJX90-8MB 1/2” 48” OAL 8FJX-8FJX 1/2" 92" OAL 8FJX-8MB 1/2” 24” OAL 8FJX-8FJX90 1/2" 44.5" OAL 8FJX-8FJX90 1/2” 102” OAL 8FJX90-8FJX 1/2”...
Page 109: Diverter Control Box
Bridgeview Manufacturing Inc. Diverter Control Box DESCRIPTION PART # Complete Control Box with Harness (Standard) 24466 Complete Control Box with Harness (4 Function) # 33134 Complete Control Box with Cab to Hitch Harness (5300 Series) Square Plug for Diverter Valve...
Page 110 Bridgeview Manufacturing Inc. Diverter Machine Side Harness Page 106...
Page 111 Bridgeview Manufacturing Inc. Diverter Control Box #24466 Page 107...
Page 112 Bridgeview Manufacturing Inc. Diverter Control Box #33134 (4 Function with Additional Push Button Switch) Page 108...
Page 113: Lights & Harness
Bridgeview Manufacturing Inc. Lights & Harness Page 109...
Page 114: Notes
Bridgeview Manufacturing Inc. NOTES --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- --------------------------------------------------------------------------------------------------------------------- ---------------------------------------------------------------------------------------------------------------------...
