  • Page 1 Centrifugal Ceiling fan Ceileo Compact 200/250 Ceileo Compact 200/250 t/H/ir Ceileo Compact 200/250 light Ceileo Compact 200/250 light t/H/ir USER’S MANUAL...
  • Page 2: Table Of Contents

    Ceileo Compact www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................6 Mounting and set-up .................................. 7 Connection to power mains ..............................9 Control .........................................
  • Page 3 Do not use the unit in a hazardous or explosive environment containing spirits, gasoline, insecticides, etc. Do not close or block the intake or extract vents in order to ensure the efficient air flow. Do not sit on the unit and do not put objects on it.
  • Page 4: Purpose

    Fastening kit 1 pc. User’s manual 1 pc. Packing box 1 pc. DESIGNATION KEY Ceileo Compact 200 Light IR Additional options T : timer H: humidity sensor and timer IR: motion sensor and timer Basic options _: without built-in light source...
  • Page 5: Technical Data

    The unit design is constantly being improved, so some models may be slightly different from those ones described in this manual OVERALL AND CONNECTION DIMENSIONS OF THE FANS Ceileo Compact 200/250 Ceileo Compact 200/250 Light Ceileo Compact 200/250 T/H/IR Ceileo Compact 200/250 Light T/H/IR Dimensions [mm] Model Ø d Ceileo Compact 200/250 40.5...
  • Page 6: Design And Operating Principle

    CEILEO COMPACT 250 CEILEO COMPACT 200 T/H/IR CEILEO COMPACT 250 T/H/IR Parameter CEILEO COMPACT 200 Light WCEILEO COMPACT 250 Light CEILEO COMPACT 200 Light T/H/IR CEILEO COMPACT 250 Light T/H/IR Frequency [Hz] Speed Voltage [V] 1 ~ 220-240 Fan power [W]...
  • Page 7: Mounting And Set-Up

    Ceileo Compact www.blaubergventilatoren.de The fan casing is made of galvanized steel. The fan casing includes an exhaust spigot with a back draft damper to prevent back air flow. The terminal box comprises the terminals for wiring of the fan and is attached to the fan casing. The decorative grille is fixed to the casing via the springs inserted to the holders.
  • Page 8 Ceileo Compact www.blaubergventilatoren.de MOUNTING STEPS 1. Attach the fan to the interjoist using the screws. Vertical attachment to the beams on the wall is permissible. 2. Connect the air duct of a required diameter. 3. Connect the LED lamps (included in the delivery set) for the Light models. Option: connect the humidity sensor or the motion sensor (specially ordered accessory).
  • Page 9: Connection To Power Mains

    Ceileo Compact www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
  • Page 10: Control

    Ceileo Compact www.blaubergventilatoren.de CONTROL CONTROL UNIT WITH A SPEED SWITCH HIGH Three-position speed switch The fan with AC motor is controlled by a three-position switch. The switch has three positions: OFF — the fan is turned off. LOW — the fan operates at reduced performance (speed 1). HIGH —...
  • Page 11: Technical Maintenance

    Ceileo Compact www.blaubergventilatoren.de INDICATOR SYMBOLS OF THE MICROPROCESSOR CONTROL UNIT — turn-off delay timer adjustable from 1 to 90 minutes (default setting 15 minutes). — turn-on delay timer adjustable from 0 to 180 seconds with the increment of 10 seconds (default setting 0). —...
  • Page 12 Ceileo Compact www.blaubergventilatoren.de LAMP REPLACEMENT DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! MAKE SURE THE UNIT IS DISCONNECTED FROM POWER MAINS BEFORE REMOVING THE PROTECTION 1. Remove the decorative grille: • Pull the grille to release the springs from the holders on the casing. •...
  • Page 13: Storage And Transportation Regulations

    Ceileo Compact www.blaubergventilatoren.de TROUBLES AND TROUBLESHOOTING TROUBLE POSSIBLE REASONS TROUBLESHOOTING Check the electric connections and the operation status of the No power supply. circuit breaker. The fan does not get started. Turn the fan off. Troubleshoot clogging of the impeller. Restart Motor jam.
  • Page 14: Manufacturer's Warranty

    Ceileo Compact www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 15: Certificate Of Acceptance

    Ceileo Compact www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Centrifugal ceiling fan Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
  • Page 16 www.blaubergventilatoren.de B183-1EN-01...
