Danfoss iC7 Installation Manual page 11

iC7-Automation Frequency Converters
Installation Guide
FA06–FA08
4.1
T25
See Tech. Doc
for Info
11 24V 45 24V ST X1 X2
12 24V 46 S.INA+
MS NS
13 DI1 47 S.INB+
14 DI2 48 S.FB+
15 DI/DO1 X8
16 DI/DO2
17 DI3 45 GND
46 S.INA-
18 DI4
47 S.INB-
19 GND
20 GND 48 S.FB-
31 A01 61 24V ext
32 +10V 62 GND
33 AI1
34 AI2
35 GND
WARN
1 COM
READY
2 NO
FAUL
3 NC
PUSH
4 COM
5 NO
6 NC
– [3.5 Nm (31 in-lb)]
T1
– [2 Nm (18 in-lb)]
T2
Illustration 7:
Danfoss A/S © 2022.05
4.2
X11
X12
T1
T2
4.3
X1 X2
See Tech. Doc
for Info
ST X1 X2
11 24V 45 24V
12 24V 46 S.INA+
MS NS
13 DI1 47 S.INB+
14 DI2 48 S.FB+
15 DI/DO1
X8
16 DI/DO2
17 DI3
45 GND
18 DI4 46 S.INA-
19 GND 47 S.INB-
20 GND 48 S.FB-
61 24V ext
31 A01
32 +10V 62 GND
33 AI1
34 AI2
35 GND
WARN
1 COM
READY
2 NO
FAUL
3 NC
PUSH
4 COM
5 NO
6 NC
X102
X101
T1
4.4
( ! )
AN319740057641en-000301 / 136R0242 | 11
Instructions
STO
STO
X31
X32
X61
4.6
T1
T2
4.5
