ZIP HydroTap G4 Celsius
User Guide
Tap Operation..................(Pages 3-5)
•
LCD Screen & Menu .......(Pages 6-19)
•
Maintenance.................... (Pages 20-23)
•
Contact & Details............ (Page 24)
•
Date of Installation............./........./.........
ARC
COMMERCIAL MODELS
Affix Model Number Label
802701 - G4 User Guide - 09.2016 - v2.02
®
CUBE
Here
802701
Page 1 of 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HydroTap G4 802701 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zip HydroTap G4 802701

Summary of Contents for Zip HydroTap G4 802701

  • Page 1 ® ZIP HydroTap G4 Celsius User Guide Tap Operation....(Pages 3-5) • LCD Screen & Menu ..(Pages 6-19) • Maintenance....(Pages 20-23) • Contact & Details.... (Page 24) • Date of Installation...../../..CUBE COMMERCIAL MODELS Affix Model Number Label Here 802701 802701 - G4 User Guide - 09.2016 - v2.02...
  • Page 2 NOTES Page 2 of 24 802701 - G4 User Guide - 09.2016 - v2.02...
  • Page 3 Tap operation - Chilled Sparkling Turning the rotary control allows the dispensing of either Chilled Sparkling or Chilled water. For your convenience, the rotary control is spring loaded, so when released, will return automatically to the OFF position To dispense Sparkling water: ( Model CS175 Turn the rotary control forward as shown Rotate for Sparkling water...
  • Page 4 Tap operation - Boiling water with the safety ON. To dispense Boiling water: Tapping the illuminated RED safety Rotate for Boiling water button twice, with one finger, will cause the safety red light to flash for a few seconds. While flashing, turn the rotary control (as shown) to dispense boiling water.
  • Page 5 Filter Warning and Reset Temperature Warning Light: The warning light will flash slowly for 1 sec On and 3 secs OFF whenever the water is not at the temperature set point. The tap may be operated, but the water may not be at the desired temperature . The slow flashing light will turn off once the water reaches the set point.

  • Page 6: Lcd Screen

    LCD Screen The Zip HydroTap G4 Celsius introduces a ‘TOUCH’ screen for easy setup and operation adjustment. Safety lock Icon Sleep Mode Icon Energy Mode Icon B160/240 window Set boiling water temperature Filter usage **Status window C125/175 window Set chilled water temp.

  • Page 7: Lcd Screen Menu

    LCD Screen Menu Main Menu Sub Menu Sub Menu Options Section • English Language • German • Product Info • Product serial no. • System Faults • Lists Information • Event Log • Reset options • Filter Flush Installation • Calibration options •...
  • Page 8 LCD Screen operation - Section A Set Language Press [MENU] for main menu. Press [Language] button. Select the preferred language Press [<=] button for the previous menu LCD Screen operation - Section B System Information In this section, you can find your product serial number , check system fault messages or view the event logs of your product.
  • Page 9 LCD Screen operation - Section C Install Once your Zip HydroTap G4 unit has been installed, Go to Install menu to configure the system settings for your product. B160/240 Screen Sub menu: Filter Flush Filter Reset Boiling Calibration Booster Lux Sensor Calibration C125/175 Screen Follow 1,2 &...
  • Page 10 Position CLOSED Position The Zip HydroTap allows the user to adjust the filter life and to edit the filter usage. (See filter details on Pages 14 -15). Page 10 of 24 802701 - G4 User Guide - 09.2016 - v2.02...
  • Page 11 NOTE: Occasionaly the system will vent steam from the tap. This is normal operation as HydroTaps are programmed to re-calibrate at regular intervals. On start up, the Zip HydroTap starts a self-calibration program. The controls take the system through the calibration process. Once complete, the system reverts back to normal operation.
  • Page 12 1800-638-633, for assistance, service, spare parts, or enquiries. LCD Screen operation - Section E Security The Zip HydroTap G4 allows the appliance coordinator to set up a password to protect against users changing the preferred system settings. To set a password Press the [MENU] button for main menu.
  • Page 13 HydroTap unit. LCD Screen operation - Section F F Communication (when available) The Zip HydroTap G4 allows the user to use wifi to monitor & control the product remotely. Not yet available LCD Screen operation - Section G nstructions...
  • Page 14 Home screen. Set Temperature Zip HydroTaps are designed to operate within 1ºC to 2ºC of set point for boiling water and between 5ºC to 9ºC (3ºC to 5ºC for CS175) for chilled drinking water. All boiling water units are self calibrating to 98ºC, which is the recommended setting.
  • Page 15 LCD Screen operation - Section G Filter Zip HydroTap G4 allows the user to adjust filter life and edit filter usage. Note: The filter life may be set as a function of Litres used, or in months from the filter change. When the first of these functions is reached (i.e.
  • Page 16 LCD Screen operation - Section G Energy Modes (Boiling models) This mode allows the HydroTap to Go into Energy Saving mode. There are two options available: ‘Sleep’ mode and ‘ON/OFF’ mode. In SLEEP MODE the unit will Go to “Sleep” after a 2hr period of inactivity.
  • Page 17 LCD Screen operation - Section G In ON / OFF Mode the user may turn the unit ON or OFF at specific times for individual days or alternatively by weekly and/or weekend settings. To activate ON/OFF mode: Press the [MENU] button for main menu.
  • Page 18 LCD Screen operation - Section G Safety (Boiling models) Boiling Only Models To set the safety using the touch screen: Press the [MENU] button for main menu. Press the [Setting] button. If required, Enter your 4 digit password Press the [Safety] button. 5.
  • Page 19 Dispense some sparkling water from the tap and perform a taste test. Note: Do not discard your empty 2.6kg bottle. The 2.6kg bottles are refillable. Return the empty bottle to your nearest Zip service centre for exchange. 802701 - G4 User Guide - 09.2016 - v2.02...

  • Page 20: Filter Maintenance

    Filter Maintenance The Zip HydroTap notifies when a filter replacement is due. If you notice one of the following, you will need to change the filter: • The change Filter light will flash until reset. (See Section C) • The filter percentage will change to 0% on the screen.
  • Page 21 Filter Maintenance Warning: If the Zip HydroTap is switched off for a long period of time (e.g. More than a weekend), run water through the chilled water outlet for at least 5 minutes before consumption. Air Inlet Filter The Zip HydroTap air filter is conveniently located on the outside of the condenser.

  • Page 22: Home Menu Icons

    Home Menu Icons Safety switch is LOCKED. The HydroTap will not dispense any Boiling water. See page 18 for safety switch operation Safety switch is UNLOCKED. Boiling water may be dispensed. See page 4 for tap operation details Sleep mode is active. There are 7 sleep mode options which display this icon on the home screen.
  • Page 23 NOTES 802701 - G4 User Guide - 09.2016 - v2.02 Page 23 of 24...

  • Page 24: Contact Details

    Customer Care. Free Call: 1 800 42 43 44 As Zip policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
