The Insight online Help system explains in full the functions and use of Surveyor,
and the process of making selections and entering data in the wizards: click Help,
and then Contents, on Insight's main menu; then, within Help, click on Contents
headings and topics to expand and read them. In particular, see 'Using Surveyor'
and (under 'Data Analysis') 'Statistical Process Control'.
You may also click the Help button in any wizard dialog – or press the F1 key – to
bring up help information relevant to that stage of the wizard.
Surveyor Hardware: Specifications and Use
Additional hardware used with Surveyor comprises:
• Carrier frame, with sensors (thermocouple probes, p. 46) fitted.

Carrier Frame

Chief features of the PA0878 frame:
• Easily adjustable to fit the oven's conveyor: width continuously variable from
100 to 350 mm (3.95–13.7 in.).
• Three fixed temperature sensors.
• Carries a Datapaq DP5 logger inside its thermal barrier.
The frame will carry different models of the DP5 logger: six-channel standard
and narrow case formats (but not super-slim) and 12-channel (only six channels
are used). Thermal barriers currently available for use with these logger models
(p. 11) can be used with Surveyor.
Dimensions Height
28 mm
1.1 in.
1
Height of the frame itself: 20 mm/0.8 in. above pin-chain, 8 mm/0.3 in. below pin-chain. Overall height of
carrier-frame assembly depends on height of thermal barrier used.
2
Remove side-plates for minimum width (see main text).
3
Including sensors. Length is minimum when side-rails are fully extended.
4
With sensors and side-plates attached.
Part numbers:
PA0883 Surveyor frame PA0878 with sensor plugs PA0885 (p. 46) to fit standard
6-channel DP5 logger.
PA0884 Surveyor frame PA0878 with sensor plugs PA0886 (p. 46) to fit narrow
6-channel and standard 12-channel DP5 loggers.
44
Surveyor
1 Width 2 Length
100–350 mm 456–517 mm
3.95–13.7 in. 18.0–20.4 in.
3 Weight 4
0.93 kg
2.0 lb
