3.10 Monitor System Setup

3.10.1 Wifi/GPRS/4G/WLAN dongle connection

Users can use WiFi/ WLAN /4G /2G dongle to monitor their inverter, and view the monitoring data on computer or
smart phone remotely.
To view data on smartphone, please download the LuxPowerView APP from Google Play or Apple APP store, then login
with their user account.

3.10.2 Setup the monitor system

1. Sign up an account on the mobile phone APP or Website
The "customer code" is a code we assigned to your distributor
or installer. You can contact your supplier for their code.
* E-mail
* Language English
User name * Tel number
* Station name
Pass word
* Nominal power (W)
Remember username Auto login
* Daylight saving time
LOGIN
* Income formula (kWh) RMB (¥)
* Continent
Asia
or * Region East Asia
* Country China
* Time zone
* Address
REGISTER
* Customer code
WIFI MODULE CONNECT
* Datalog serial number
LOCAL CONNECT
* PIN
Version 1.7.1
REGISTER
21
2. Create station and add dongle for the station
add station, add wifi module

3.10.3 Set homewifi password to dongle

1. Connect your mobile phone to the "BAxxxxxxxx" wireless network where "BAxxxxxxxx" is the serial number of the WiFi dongle.
2. Click the "WiFi MODULE CONNECT" button on the APP
3. Select the home WiFi that the WiFi dongle is to be connected to, enter the WiFi's password. And then click "HomeWifi Connect". The WiFi
dongle will restart and try to connect to our server automatically.
4 . Check the LEDs' status on the WiFi dongle. The middle light should be solid lit when the WiFi dongle connects to our server successfully.
12:20
CMCC
WI-FI
BA 19520257 luxpower
Obtaining address...
Pass word
luxpower
luxpowertek_5g Remember username
luxpowertek
ChinaNet-wG49
CMCC-BAKR
HF-WIFI
ChinaNet-EWP
luxpower_5G
MORE SETTINGS DONE
5. Now you can disconnect your mobile phone from the "BAxxxxxxxx" wireless network. Login on the APP with your account,
you'll find the inverter information already appears. Now you'll be able to monitor and control the inverter remotely on any
smart phone or computer that has Internet connection.
Set WIFI password to Inverter WIFI module
SSID:
unknown ssid
Please input password
Password:
Auto login
Homewifi Connect
LOGIN
or
TCP Set
REGISTER
WIFI MODULE CONNECT
LOCAL CONNECT
Version 1.7.1
