VnM®8 Print and Font Settings
To change print settings for certain VnM inks and media, including font, make sure you are
on the main menu; press and hold the ALT + EXIT keys at the same time.
A) To Change Print Settings
1. This should be the first screen you see.
SELECT MEDIA WIDTH:
Press 4,5,6,7, or 8
2. Press the DOWN arrow key until you see
VNM PRINT SETTINGS and press ENTER.
VNM PRINT SETTINGS
Press ENTER
3. Using the up and down arrows on the
keyboard, locate your desired ink and
media and press ENTER.
VNM BLACK INK 1
PRESS ENTER
Standard settings for
VnM Black ink
VNM WHITE INK 1
PRESS ENTER
Standard settings for
VnM White ink
LOOK AT VNM MANUAL
TURN CUTTER ON
Turns the cutter on
LOOK AT VNM MANUAL
TURN PARTIAL CUT ON
Turns the partial cut on
4. To manually change the print speed,
print density, and /or cutter settings,
press ENTER or VNM MANUAL SETTINGS.
VNM MANUAL SETTINGS
Press ENTER
5. Enter the Printer speed and press ENTER.
Recommended at 2.
ENTER SPEED:
2
6. Enter the print density and press ENTER.
Recommended density based on the ink
color being used:
Black: 6-9, White: 10-13
Blue: 2-4, Green: 2-4, Red: 2-4
ENTER DENSITY:
5
VNM BLACK INK 2
PRESS ENTER
High Density settings for
VnM Black ink
VNM WHITE INK 2
PRESS ENTER
High Density settings for
VnM White ink
LOOK AT VNM MANUAL
TURN CUTTER OFF
Turns the cutter off
LOOK AT VNM MANUAL
BLANK CUT
Turns the blank cut on
Copyright © 2016 Cobra Systems, Inc. All rights reserved
B) To Change Font Settings
1. This should be the first screen you see.
SELECT MEDIA WIDTH:
Press 4,5,6,7, or 8
2. Press the UP arrow key until you see
SELECT FONT/SYMBOLS and press ENTER.
SELECT FONT/SYMBOLS
Press ENTER
3. Using the up and down arrows on the
keyboard, locate your desired font and
press ENTER. To get back to the main
menu after you have selected your font,
hold down ALT and EXIT.
CHOOSE FONT/SYMBOLS:
BOLD
CHOOSE FONT/SYMBOLS:
NORMAL
CHOOSE FONT/SYMBOLS:
SYMBOLS3
CHOOSE FONT/SYMBOLS:
SYMBOLS2
CHOOSE FONT/SYMBOLS:
SYMBOLS1
CHOOSE FONT/SYMBOLS:
PIPE MAKER
CHOOSE FONT/SYMBOLS:
UTILITY
CHOOSE FONT/SYMBOLS:
ITALIC
NOTE: See pages 21-22 for fonts and symbols.
