Loading VnM®8 Media
1
3
5
7
IMPORTANT: To prevent smudges and fingerprints, handle media on the ends of the roll.
With printer
turned off,
open the
cover, press
down on the
printhead
and push
back the
green lever
to raise the
printhead.
Secure
the media
spindle with
end guides,
keeping
everything
centered.
Now feed
the media
under the
green sensor
bar.
Make sure
media and
ribbon are
properly
installed.
Copyright © 2016 Cobra Systems, Inc. All rights reserved
2
4
6
8
Slide the
VnM8 vinyl
media onto
rear spindle
and center.
Feed media
under the
white bar
and through
the white
media guides.
Pull the
media from
under the
printhead
and between
the cutter gap.
With hands
on both
sides, push
down on the
printhead
until the
green latch
clicks.
