Installation Instructions and User Guide
FS 600
FS 1000
FS 1200
S/N
Please read the manual carefully before installation and use.
The installation of your new door opener must be carried out by a technically qualified
or licensed person.
Attempting to install or repair the door opener without suitable technical qualification
may result in severe personal injury, death and / or property damage.
Sectional And Tilting Door Opener
600N
1000N
1200N
WARNING
FS 600-Speed
FS 1000-Speed
600N
1000N
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ForceDoor FS 1000
Summary of Contents for ForceDoor FS 1000
- Page 1 Sectional And Tilting Door Opener Installation Instructions and User Guide FS 600-Speed 600N FS 600 600N FS 1000-Speed 1000N FS 1000 1000N FS 1200 1200N WARNING Please read the manual carefully before installation and use. The installation of your new door opener must be carried out by a technically qualified or licensed person.
-
Page 3: Table Of Contents
CONTENTS Important Safety Recommendations...…………………………….……………………………..1 Product Description & Features.....................2-3 Pre-Installation Recommendations ..................4 Installation (Wall Bracket & Door Bracket) ................4 Installation (Steel Track)……………………………………………………………………… .…...5 Installation (Sectional Steel Track Assembly)................6 Battery Backup Assembly (optional)..............7 Display Menu Instructions (Plus II)......................8 Programming Instructions....................9-19 Terminal Introduction and Application.................20-21 Manual Disengagement......................22 Maintenance………………………………………………………….………………………..….….22 Technical Specifications………………………………………………………………………..23-24... -
Page 5: Important Safety Recommendations
IMPORTANT SAFETY RECOMMENDATIONS FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS MAY RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR PROPERTY DAMAGE. 1. PLEASE READ CAREFULLY AND ADHERE TO ALL SAFETY AND INSTALLATION RECOMMENDATIONS. 2. The opener is designed and manufactured to meet local regulations. The installer must be familiar with local regulations required in respect of the installation of the opener. -
Page 6: Product Description & Features
PRODUCT DESCRIPTION & FEATURES 1. Obstruction force adjustment The minimum force display “1” and it can be adjusted upward. Display “5” means the maximum force. 2. Travel speed adjustment “8” appears on the display means the 80% of the travel speed. Display “A” means the full speed 160mm/s or 200mm/s. - Page 7 15. Battery backup available Openers could be supplied power with our battery backup once the power failure at your home. 16. Self-Lock in gear motors Gear motor will self-lock with its disengagement systems. 17. Manual release Don't worry about the power failure, the manual release system is a solution for operation the door at any time.
-
Page 8: Pre-Installation Recommendations
PRE-INSTALLATION RECOMMENDATIONS 1. Garage door must be able to be lifted and closed easily by hand and without much effort. A well balanced & sprung door is critical for proper installation. 2. The garage door opener can’t compensate for a badly installed garage door and should not be used as a solution for a “hard to open”... -
Page 9: Installation (Steel Track)
Installation (Steel Track) Figure 3 STEP1 (Fig.3) Attach the opener head to the steel track. Assembly the 2 “U” Hanging brackets with 6mm nuts supplied. STEP2 (Fig.3) Place the steel track and opener head assembly centrally on the garage floor, with the open head furthest away from the door. -
Page 10: Installation (Sectional Steel Track Assembly)
Sectional Steel Track Assembly 2 Parts Steel Track A:1500 mm B:1500 mm Sleeve 3 Parts Steel Track D:1000 mm C:1000 mm E:1000 mm Sleeve Sleeve 1. 2-Parts Track: As Fig.6, slide the A rail into the sleeve, slide the B rail into the sleeve. 3-Parts Track: As Fig.7, slide the C rail into the sleeve, slide the D rail into the sleeve;... -
Page 11: Battery Backup Assembly (Optional)
Battery backup Assembly (optional) Option 1 - Top Fixed(For Lead-acid Battery only) STEP1 (Fig.11) Assemble the battery & the bracket like the photo, fix by screws supplied. STEP2 (Fig.12) Join the battery to opener, find the Fig.12. Figure 11 Figure 12 Option 2 - Side Fixed(For Lead-acid&Lithium Battery) STEP1 (Fig.13) Assemble the battery to the side of the opener like the photo, fix by screws... -
Page 12: Display Menu Instructions (Plus Ii)
DISPLAY MENU INSTRUCTIONS FEATURES SETTINGS: a)Press and hold SET button until “1” appears on the display then release the button. b)Press UP / Down button, then it displays the number “1-E”. c)Press Set button to confirm the feature you need to set, then it enters to the interface for detail setting of the appointed feature. -
Page 13: Programming Instructions
PROGRAMMING INSTRUCTIONS Pre- Instruction for programme buttons Short click SET button : When it standby, it will clear the error, alarm display, and return to normal display. Short click CODE button : ( In the Setting Status) Exit the current operation and return to the standby ... - Page 14 PROGRAMMING INSTRUCTIONS 1. PROGRAMMING OPEN & CLOSE LIMITS a) Press and hold SET button to enter this function setting until “1” appears on the display then release the button. b) Press the SET button again. The door opener is now in Programming Mode.
- Page 15 OBSTRUCTION FORCE ADJUSTMENT CAUTION: The obstruction force adjustment is set automatically during programming. Normally no adjustment is necessary. a) Press and hold SET Button until “1”appears on the display, next press the UP Button until “2” appears on the display to enter this function setting then release the button.
- Page 16 4. AUTOMATIC CLOSING&TIME SETTING NOTE: We recommend that Safety Photo Beams be used in any installation where the Auto Close function is enabled. a) Press and hold SET Button until “ 1 ” appears on the display, next press the UP button until “4” appears on the display to enter this function setting then release the button.
- Page 17 5. AUTOMATIC CLOSING CONDITION SETTING a) Press and hold SET Button until “1” appears on the display, next press the UP button until “ 5 ” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in automatic close condition adjustment mode.
- Page 18 7. REVERSAL HEIGHT SETTING a) Press and hold SET Button until “ 1” appears on the display, next press the UP button until “7” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in reversal height adjustment mode.
- Page 19 8. PARTIAL OPEN/HEIGHT SETTING a) Press and hold SET Button until “1” appears on the display, next press the UP button until “ 8 ” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in partial-open/height adjustment mode.
- Page 20 9. TRANSMITTER BUTTONS RECOGNITION FUNCTION SETTING a) Press and hold SET button to enter this function setting until “9” appears on the display then release the button. b) Press the SET button again. The unit is now in buttons recognition function adjustment mode.
- Page 21 b. REVERSAL HEIGHT IGNORANCE SETTING a) Press and hold SET Button until “1” appears on the display, next press the UP button until “b” appears on the display to enter this function setting then release the button. b) Press the SET button again. The unit is now in reversal height ignorance adjustment mode.
- Page 22 d. PHOTO CELL ON/OFF SETTING NOTE: Make sure the photo cell has been correctly installed and used Normally Closed contacts to the accessory terminals of the opener. Also note that the photo beam function must be disabled if NO photo beams are fitted, otherwise the door cannot be closed, and the LED display will show the letter“...
- Page 23 E. MAINTENANCE ALARM--OPERATION CYCLES COUNT SETTING a) Press and hold SET Button until “ 1 ” appears on the display, next press the UP button until “E” appears on the display to enter this function setting then release the button. b) Press the SET button again.
-
Page 24: Terminal Introduction And Application
Photo beam connection (optional) – Fig.15,Fig.16 Switch control connection (optional) – Fig.15 Remark: 1. Flash (Caution Light) Should be less than 25W. 2. PB (External Push Button) Should be “ NO”. Figure 15 Figure 16 Other terminal introduction and application 1．The O/S/C interfaces available. - Page 25 The door panel won’t be damaged. Figure 17 Figure 18...
-
Page 26: Manual Disengagement
MANUAL DISENGAGEMENT The opener is equipped with a manual release cord to disengage shuttle and move door by hand while holding the handle down (Fig 19). Pull on the handle to disengage the shuttle. To re-engage the door simply run opener in automatic mode or move door by hand until the trolley engages in the chain shuttle. -
Page 27: Technical Specifications
TECHNICAL SPECIFICATIONS FS 600 FS 1000 FS 1200 Input voltage 220 - 240V / 110 - 127V, 50–60 Hz Max. pull force 600 N 1000 N 1200 N Max. door area 10.0 15.0 18.0 ㎡ ㎡ ㎡ Max. door weight (Balanced) - Page 28 FS 600-Speed FS 1000-Speed Input voltage 220 - 240V / 110 - 127V, 50–60 Hz Max. pull force 600 N 1000 N Max. door area 10.0 15.0 ㎡ ㎡ Max. door weight (Balanced) 80 kg 100 kg Max. door height...
-
Page 29: Parts Listing
PARTS LISTING Item Description Item Description Item Description Transformer Chain wheel Top cover Chain/ Belt rail Mounting bracket L.E.D cover Chain/ Belt connection C rail- steel L.E.D light Trolley assy Click bracket PCB-1 Straight arm U hanging bracket Control panel cover-2 Bent arm Motor shaft sleeve Control panel cover-1... -
Page 30: Common Fault & Solutions
Common Fault & Solutions Fault appearance Fault cause Solutions No any working for openers 1. Power supply 1. Check whether the motor socket is energized LCD screen is not bright 2. Plug wire is loosing 2. Check whether Fuse tube is broken 3. - Page 31 The door is fully open, automatically Automatic closing function is turned on Set the automatic closing time, or turn off the automatic close after some time closing function. LED lights flash 4 times ( Refer the instruction manual) When the door stops, the caution light is The power board is broken Replace the power board always on...
